Revoria Press SC285S
Revoria Press SC285
User's Manual
Before using the machine, please read this manual thoroughly. Be sure to keep this manual for future reference.
This manual may not be edited, modified or copied in whole or part without the written consent of the publisher.
■
Parts of this manual is subject to change without prior notice.
■
The screen shots and the illustrations in this manual are used as examples. They may differ from yours
■
depending on the model, the software, or the OS.
Control Panel
„ Features of Control Panel
Pressing the Home button displays the Home
screen.
1.
Power/Power Saving button
The power switches on.
Note
When "Please wait..." is displayed, the machine
■
is warming up. The use of machine is not avail-
able during this time.
If the power does not switch on, confirm that the
■
power plug is connected.
2.
NFC touch area
This is an area for you to hold up your NFC-supported
mobile devices over. To communicate interactively, the
NFC function of this machine needs to be enabled.
3.
Data indicator
This indicator blinks while data is being sent from the
machine or data is being received from the client com-
puter.
Also, this indicator lights up when documents are saved
in the machine.
4.
Status display lamp
The lamp lights up in green at an instant of operation
reception. When an error occurs, the lamp blinks in
orange.
5.
Login
The user is authenticated when the user enters the
User ID and logs in.
When the user is logged in with the administrator
rights, [Administrator] is shown in this area. While the
user is authenticated, tapping on the authentication
information display area logs out the user, and the state
becomes as unauthenticated.
6.
Opening menu
Tap this to open the menu for change and check of the
settings of the machine.
Tap on [<] to close the menu.
The PDF manual is available by clicking "PDF Manuals" on the help
of Internet Services.
https://product1.iotconnectup.com/webui_help/global/revoria_press_sc285/en/top.html
[Apps]
5
1
6
Home Button
[Pause]
2
3
4
7.
Home Screen
Apps/Pins/Address Screens can be displayed.
• [Apps]: You can tap on any of the application icons
• [Pins]: You can execute a job again using Job Direc-
• [Address]: You can register addresses and other
March 2025 GM1925E5-3
[Pins] [Address]
and use its functions.
tion History and the job direction history of which pin
is created with [Create Pin] by user. If you create a
pin of the job direction history, you can also directly
activate a job without opening an application.
information. You can activate an application from a
registered address.
After activating an application, the selected address
is set as the destination of the application.
Edition 1
