- Page 1 INSTALLATION MANUAL Topline 260 series...
-
Page 2: Table Of Contents
1. Introduction General This is the installation manual for the Thetford SHB269. The manual is meant for qualified installers who will install the appliance in a caravan, camper or holiday home. Read the information and instructions carefully and follow them strictly to install the appliance safely and correctly. -
Page 3: Safety
Attention. Important information. Note. Additional information. Video. Additional instruction video available. 2. Safety READ THESE INSTRUCTIONS FOR USE CAREFULLY . FAMILIARISE YOURSELF WITH THE APPLIANCE. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. General Risk of serious injury through burning, explosion, clamping, electrocution, suffocation and poisoning or damage to the product. - Page 4 ■ The surrounding surfaces must be able to withstand the allowable temperature rise of 65°C above ambient temperature, as specified in the EN30-1-1 standard and in accordance with the design of this unit. ■ The temperature of the surrounding surfaces may rise if there are other additional devices besides the appliance.
-
Page 5: Serviceability
In terms of serviceability, this means that a dealer or authorised Thetford service partner must be able to remove and re-install the Thetford product within the time that is allowed according to the Thetford time-list, using standard tools and equipment. -
Page 6: Technical Specifications
2 x 104 0.61 Total 5.18 Electrical 12V DC supply Table 2: Dimensions and weight SHB269 series Dimensions Appliance 11kg weight This appliance is suitable for use with LPG [Liquefied Petroleum Gas] and should not be used with any other gas. -
Page 7: Before Installation
Table 3: Gas category Class 3 Appliance Gas category & Pressure CAT I CAT I 3 + (28-30/37) 3 B/P (30) BUTANE (G30) 28 – 30mbar BUTANE (G30) 30mbar PROPANE (G31) 37mbar PROPANE (G31) 30mbar For installation in BE, CH, CY, CZ, ES, FR, GB, AT, BE*, CH, CY, CZ, DE, DK, GR, IE, IT, LT, PT, SI, TR EE, FI, FR, GB*, GR, HR, HU,... -
Page 8: Cabinet Requirements
Cabinet requirements The location must provide: ■ Wood cabinetry and worktop. ■ Support for at least the weight of the appliance as stated in Technical specifications plus any items placed on top. The total weight placed on top of the hob should not exceed 10kg. ■... - Page 9 ② ③ ④ Dimension (mm) SHB269 For models with a glass lid, the distance from the edge of the burner to the rear wall can be reduced to 110mm. Cabinetry ventilation and protection dimensions Maintain provision for the dispersal of unburnt gas beneath the appliance.
-
Page 10: Installation Dimensions
■ Position the unit so it is centred and level in the cut-out. There must also be a gap of 2-3mm between the appliance and sides of the cut-out. SHB269 cut-out: 200 . 8 210 . 2 210 . 2... - Page 11 Schematic overview of surface mounting the appliance into the cabinet 1. Edge seal 2. Worktop 3. Nut and washer 4. M4 threaded stud...
- Page 12 Position the unit so it is centred and level in the cut-out. ■ There must also be a gap of 2-3mm between the appliance and sides of the cut-out. Rebate depth for flush mount is 6mm. SHB269 cut-out: 150 . 8 200 . 8 59 . 8 210 .
-
Page 13: Installation
Schematic overview of mounting the appliance into the cabinet 1. Edge seal 2. Worktop 3. Nut and washer 4. M4 threaded stud 6. Installation Read the applicable instructions in chapter Safety first. Prepare See chapters 'Technical specifications' and 'Before installation' for more information. -
Page 14: Connect The Gas Supply
■ Place the appliance into the opening. ■ Fix the appliance in place using the fastener positions as shown in chapter 'Before installation'. Make sure the appliance is located correctly in the aperture. Check the position of the Hob in the worktop and perimeter seal before tightening the fasteners. -
Page 15: After Installation
7. After installation Read the applicable instructions in chapter Safety first. Visual checks Check if: ■ All packaging materials have been removed. ■ The appliance is placed, mounted and levelled on a stable structure. ■ Vents and gas dispersal hole are not blocked/obstructed. ■... -
Page 16: Service & Questions
For our warranty clause, please refer to the conditions mentioned on www.thetford.com. Declaration of Conformity Thetford hereby declares that this product is in compliance with the essential requirements and other relevant provisions of the applicable Regulations, Directives and Standards. A copy of the Declaration of Conformity can be found at www.thetford.com. - Page 17 T +61 3 9358 0700 T +86 755 8627 1393 T +46 31 336 35 80 F not available F +86 755 8627 1673 F not available E infoaus@thetford.com.au E info@thetford.cn E infos@thetford.eu www.thetford.com.au www.thetford.cn Copyright 2017-2025 Thetford B.V. All rights reserved. SINS2118/0125-V04...
