- Page 1 P I C N I C T A B L E Assembly Instructions PG-MAN-PIC-PH-XL-00 817 Maxwell Avenue • Evansville, IN 47711 • 1-800-GO-SWING • www.escaladesports.com • ©2017 Escalade Sports...
- Page 2 H A R D W A R E I D E N T I F I C A T I O N 1/4" Flat Washer 1/4" x 4.5" LAG SCREW PG-HW-W002 PG-HW-L002 QTY (2) QTY (2) 3/8" X 2.5" Lag Screw PG-HW-L016 QTY (8) 3/8"...
- Page 3 P A R T S L I S T NOTE: Parts will have the part number (Starts with PG-) stamped on the part itself. Picnic Table Board Picnic Table Seat Board Picnic Table Board Short Picnic Table Support PG-546-064-PIC PG-2X4-032-PT...
- Page 4 BONUS ROOM TOP FILLER BOARD This step is only if installing a Bonus Room and a Picnic table. If not installing a Bonus Room skip this page and go to step 2 on page 5. Install Window Top Filler Notched as shown...
- Page 5 ATTACH PICNIC TABLE SUPPORTS Attach two Picnic Table Supports (PG-2X4-032-PT) on each side as shown in Detail B. DETAIL B PG-HW-L016 PG-2X4-032-body-1 PG-2X4-032-body-1 PG-2X4-032-body-1 PG-2X4-032-PT PG-HW-L016...
- Page 6 MAKE TABLE AND SEAT ASSEMBLIES Make a Table top assembly and Seat Assembly as shown. PG-546-064-PIC PG-546-064-PIC PG-HW-S018 PG-2X4-016-BB PG-546-064-PIC-A PG-544-054-PIC PG-2X4-009-BB-A NOTE: Counterbore on this side PG-2X4-009-BB NOTE: Counterbore on this side PG-2X4-009-BB-A...
- Page 7 ATTACH ASSEMBLIES TO SUPPORTS Attach table top assembly with four screws in each board as shown in Detail C. Attach seat assembly with four screws in the big board. Complete securing seat with two Washers and two Lag screws as shown in Detail C. DETAIL C PG-HW-S018 PG-HW-L002...
- Page 8 This warranty is expressly in lieu of all other warranties, expressed or implied, including warranties of merchantability or fitness for use. Woodplay does not assume or authorize any person to assume for us, any other liability in connection with the sale of our products.
