WOODPLAY PG123MRW Quick Start Manual

Monkey room
Hide thumbs

Advertisement

Quick Links

Download this manual
PG123MRW
MONKEY ROOM
PG-MA-0024-02
817 Maxwell Avenue • Evansville, IN 47711 • 1-800-GO-SWING • www.escaladesports.com • ©2016 Escalade Sports

Advertisement

loading
Need help?

Need help?

Do you have a question about the PG123MRW and is the answer not in the manual?

Questions and answers

Related Manuals for WOODPLAY PG123MRW

Summary of Contents for WOODPLAY PG123MRW

  • Page 1 PG123MRW MONKEY ROOM PG-MA-0024-02 817 Maxwell Avenue • Evansville, IN 47711 • 1-800-GO-SWING • www.escaladesports.com • ©2016 Escalade Sports...
  • Page 2 S T A N D A R D P A R T S L I S T ITEM PART NUMBER DESCRIPTION QTY. PG-54-0006 Picnic Table Board Long PG-54-0012 Enclosure Window Front PG-54-0013 Enclosure Door Front PG-54-0014 Enclosure Rail Opened PG-54-0016 Enclosure Rail PG-14-0010 28 1/2"...
  • Page 3 H A R D W A R E I D E N T I F I C A T I O N Measurement taken from bottom of bolt head to the bottom of bolt PG-HW-L003 5/16" X 2.5" LAG SCREW QTY (24) PG-HW-W003 5/16"...

  • Page 4: Parts Identification

    P A R T S I D E N T I F I C A T I O N PG-54-0013 PG-54-0014 PG-54-0006 PG-54-0012 Enclosure Rail Opened Enclosure Door Front Picnic Table Board Long Enclosure Window Front QTY (2) QTY (2) QTY (1) QTY (2) PG-14-0010...
  • Page 5 I N S T A L L F L O O R S U P P O R T Note: All parts and hardware for this step are from base set kit. Remove Corner Braces from playset. Turn them on edge and slide them up in between Fascia Board and Main Beam.
  • Page 6 I N S T A L L F L O O R Note: All parts for this step are from base set kit except 2 Long Picnic Table Boards #1. Layout and evenly space 2 Short Picnic Table Boards in between corner posts as shown. Secure using 4 #8 x 2"...
  • Page 7 I N S T A L L E N C L O S U R E R A I L S Secure Enclosure Rails #4, #5 and #8 to Corner Posts using Hardware # 11 and #12. Note Swing Beam side in relation to Enclosure Rail #5.
  • Page 8 I N S T A L L W I N D O W & D O O R F R O N T Secure Window Front #2, Door Front #3 and Enclosure Rail #5 to Corner Posts using Hardware # 13 and #12.

  • Page 9: Door Opening

    D O O R O P E N I N G Secure 43 3/4" Enclosure Slat #7 to Door Front #3 at top and Enclosure Rail #4 at bottom using Hardware #9. Note: Door opening should be 24" at top and bottom. Make sure Enclosure Rail #4 is flush with front of sandbox side and attach Bracket #13 as shown with hardware #15 and#14.
  • Page 10 I N S T A L L E N C L O S U R E R A I L S Attach Enclosure Rails #4, #5 and #8 to Corner Posts as shown using Hardware # 11, #12 and #9. Top of Enclosure Rails should be 26 1/4"...
  • Page 11 E N C L O S E B A C K Inside View Secure Enclosure Slats #6 and #7 from inside set to enclose the back of the playset as shown using hardware #9.
  • Page 12 E N C L O S E S W I N G B E A M S I D E Inside View Secure Enclosure Slats #7 from inside set to enclose the swing beam side of the playset as shown using hardware NOTE: This hole goes towards the top of part.
  • Page 13 E N C L O S E F R O N T Inside View Secure Enclosure Slats #6 and #7 from inside set to enclose the front of the playset as shown using hardware...
  • Page 14 E N C L O S E S I D E Inside View Secure Enclosure Slats #6 and #7 from inside set to enclose the side of the playset as shown using hardware...
  • Page 15 This warranty is expressly in lieu of all other warranties, expressed or implied, including warranties of merchantability or fitness for use. Woodplay does not assume or authorize any person to assume for us, any other liability in connection with the sale of our products.
