- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 202993 Dresser REVISION 0 : 06/18/2012 REVISION 1 : 09/11/2018 PAGE 1 OF 4 COASTERFURNITURE.COM REVISION 2 : 12/04/2019 REVISION 3 : 07/05/2024...
-
Page 2: Parts Identification
202993 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. WARNING! 1. - Page 3 202993 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 COMPLETE COASTERFURNITURE.COM PAGE 3 OF 4...
- Page 4 202993 ITEM : ANTI-TIPPING INSTALLMENT INSTRUCTIONS FURNITURE TIPPING RESTRAINT WARNING Injury may result from tipping furniture. This restraint may protect against tipping furniture. Do not allow children to climb on furniture. This restraint is not a substitute for proper adult supervision. Failure to detach this restraint before moving the furniture may result in injury and damage.
- Page 5 202993 ITEM : Inner Size of Drawer : 26.50"W x 12.75"D x 5.50"H x 0.50"T 7.75" 8.50" 29.50" 32.50" 2.50" 51.00" 4.00" 64.00" 16.25" Note: Dimension tolerance ±5% COASTERFURNITURE.COM...
- Page 6 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 202994 Mirror REVISION 0 : 06/18/2012 REVISION 1 : 09/11/2018 REVISION 2 : 12/04/2019 PAGE 1 OF 4 COASTERFURNITURE.COM REVISION 3 : 08/04/2020 REVISION 4 : 09/09/2023...
-
Page 7: Assembly Tips
202994 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. WARNING! 1. - Page 8 202994 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Back View STEP 2 (OPTIONAL) Align and hang the mirror against the wall in landscape orientation with both left and right pre-fixed metal bracket in correct orientation. Note : Screws or fittings to fix the mirror to the wall are not included. Choose screws or fittings that are suitable to the wall material and have sufficient holding power.
- Page 9 202994 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 COMPLETE COASTERFURNITURE.COM PAGE 4 OF 4...
- Page 10 202994 ITEM: 35.00" 29.50" 34.25" 39.75" 32.50" 51.00" 4.00" 64.00" 16.25" ± Note : Dimension tolerance COASTERFURNITURE.COM...
