- Page 1 User manual V2.O IRay Technology Co., Ltd. Zoom Series Add.: 11th Guiyang Street, YEDA, Yantai, P.R. Thermovi China Tel: 0086-400-998-3088 sion Email: infirayoutdoor@infiray.com Website: www.infirayoutdoor.com ZL38/ZH38/ZH5O...
-
Page 2: Important Safety Information
IMPORTANT SAFETY • The device must only be connected to a USB Type-C cable. • If the device has been damaged or the battery is faulty, please INFORMATION send the device to our after-sales service for repair. Safety instructions for the power supply Environmental influences •... - Page 3 Installing/removing the battery for improper disposal of this type of waste. The ZOOM series thermal imaging rifle scope is equipped with a battery set. The battery pack can be moved and charged, see section 7 - Battery For business customers within the European Union pack for details.
-
Page 4: Specifications
Display Type FHD OLED Specifications Resolution, pixels 1440×1080 Model ZL38 ZH38 ZH50 Dimensions, inch Detector specifications Batteries Uncooled Vox Type Batteries Li-ion Battery Pack / 4400mAh / DC 3.7V 384×288 640×512 Resolution，pixels Operating voltage, V 3 ~ 4.2 Pixels, μm 5 (USB Type-C) External voltage, V NETD, mK... - Page 5 Package Product description contents The ZOOM series thermal imaging riflescopes are thermal imaging devices integrating observation, thermal spot tracking, photography and • ZOOM series thermal imaging rifle scope video recording, Wi-Fi connectivity, etc. The dual field of view lens allows •...
-
Page 6: Components And Buttons
• Eyepiece supporting 20× zoom • Digital zoom: 1×/2×/3×/4× • Built-in 32 GB memory, supporting photo and video recording • Built-in Wi-Fi module, supporting the InfiRay Outdoor app • Built-in digital compass and motion sensor 1. Lens cap7 . Menu button (M) •... -
Page 7: Button Control
Button control Button Default state Press briefly Hold Switch on the device Home screen Device standby mode Turn off the device Power button Standby mode Waking up the device Main menu interface Return to the top menu without saving changes Defective pixel correction interface Add/Remove defective pixels Home screen... - Page 8 If the indicator flashes red, the battery charging bracket is connected to a power source but the battery module is not installed. ZOOM series devices use a rechargeable lithium-ion battery IBP-1, with a ⮚ When fully charged, remove the battery from the battery charger (13).
- Page 9 While the battery is charging via the Type C port, the status light 3. When the battery (9) is fully inserted into the Zoom Thermal Imager (3) on Zoom series devices will also change to show the battery body, turn the ring (12) 90 degrees counterclockwise to lock the status.
-
Page 10: External Power Supply
14. The battery capacity may decrease when using the battery in negative Safety precautions for the battery temperature, which is normal, it is not a fault. 1. Use only the battery charger (13) supplied with the battery 15. Do not use the battery at a temperature higher than the temperature (9). -
Page 11: Digital Zoom
Switching on and adjusting the Calibration picture Thanks to the shutterless thermal imaging of the Zoom series, high-quality images can be captured without a mechanical shutter. ⮚ Remove the lens cap (1). Rare cases, once image degraded ⮚ Press and hold the power button (5) to switch on the device. The home screen will then appear after a few seconds. - Page 12 ⮚ The corresponding magnification is displayed in the status bar. synchronise the system date and time in the InfiRay Outdoor settings. For ⮚ The following table shows visual magnifications from 1× to 4×. details, please refer to the application manual on our official website...
-
Page 13: Status Bar
When the device is turned on and connected to the computer, the ⮚ There is a built-in microphone function in the Zoom Series thermal computer recognizes it as a flash memory card. You can then access the imaging camera that will automatically enabled when you start recording video, the device's memory and copy pictures and videos. - Page 14 • Ultra-bright mode status: ( : Ultra-bright mode is off; Local offer : Ultra-bright mode is on) • Current focal length of the lens From the local menu, you can quickly adjust basic configurations for • Current magnification (for example 2.0×) commonly used features, including picture mode, display brightness, •...
- Page 15 ⮚ Press and hold the M button (7) to save your changes and top menu or submenu; return to the home screen. 6. In any menu interface, press the power button (5) to return to the top Note: If no operation occurs in the local menu within 5 seconds, the menu or home screen without saving changes, press and hold the M device automatically saves the changes and returns to the home screen.
- Page 16 Main menu options and description Turning Ultra-bright mode on/off • Press and hold the M button (7) to enter the main menu. Ultra-bright mode • Select the "Ultra-clear" option using the up (6) / down (8) button. • Turn Ultra-bright mode on/off by briefly pressing the M button (7), during which you will hear the shutter calibration click. •...
- Page 17 • Press the up (6) / down (8) button to select the altimeter option. • Press the M button (7) to switch the altimeter on/off. • When the function is switched on, the altimeter values are displayed in the status bar at the top. Switching the digital compass on/off •...
- Page 18 • The status light will flash steady green during normal operation and will flash red during standby mode. Fix defective pixels When using thermal imaging, you can see defective pixels such as visible bright spots or dark spots with stable brightness. To solve this problem, use the defective pixel correction function.
- Page 19 • Press the power button (5) to add the defective pixel. The word "Add" appears in the PIP window and the defective pixel is added. • At the same position, you can undo the correction of the defective pixel by pressing the power button (5) again.
- Page 20 General settings • Press and hold the M button (7) to enter the main menu. • Press button / down (8) Select option "General Settings". • Press the M button (7) briefly to enter the submenu. • This menu item allows you to configure the following settings: Setting the system date •...
- Page 21 • The time format is displayed as HH:MM in 24-hour format. • Press the M button (7) briefly to activate the Date submenu. Two triangle icons will appear above and below the value. • Select the correct value for the hour and minute by briefly pressing the up (6) / down (8) button.
- Page 22 Firmware Before updating, you must copy the downloaded firmware program to the Zoom's embedded storage. Actualizati • Connect Zoom to your computer and turn Zoom on. • Open the ZOOM_Storage folder and create new "update" folder names on your computer. •...
- Page 23 • Confirm your selection by briefly pressing the M button (5). • If Yes is selected, the thermal imaging system will automatically restart. • If No is selected, the operation is cancelled and the screen returns to the main menu. When you select Factory Reset, the following functions will be restored to their default settings: •...
-
Page 24: Pip Function
Stadiametric rangefinder PIP function • From the home screen, simultaneously press and hold the Up (6) + M (7) buttons to turn the stadiameter function on/off. Picture-in-Picture (PIP) provides a floating window independent of the • When this function is enabled, two horizontal lines used for entire screen. - Page 25 Monitoring of thermal points serial number of the device. • Select Wi-Fi, enter your password and connect. The initial Zoom Series devices provide a heat password is 12345678. spot tracking feature that allows you • Once a Wi-Fi connection is established, you can to track the hottest object in the control the device via the mobile app.
- Page 26 If your device has been connected to a mobile device, turn on or laptop via Wi-Fi. mobile data on the mobile device. Once connected, the app will The InfiRay Outdoor User Guide is available for download on our official automatically prompt you to update. Click on the website (www. infirayoutdoor.com).
-
Page 27: Troubleshooting
method). Use a special wiper tool and solvent to clean optical surfaces. Technical inspection Troubleshooting Before using the equipment, perform a technical check and check the following items each time: • Outside of the device (no crack on the cover). The following table lists all the problems that may occur during use. - Page 28 Failure Possible causes Solution Thermal imaging cannot be started. The battery is dead Charge the battery Facilities Cannot powered USB cable is damaged Replace the USB cable external power supply External power supply is insufficient If necessary, check the external power supply The picture is too dark Display not bright enough Adjust the brightness of the display...
-
Page 29: Legal And Regulatory Information
InfiRay Technology Co., Ltd. hereby declares, Information for users that the ZOOM series thermocouples comply with Any changes or modifications not expressly approved by the party Directives 2014/53/EU and 2011/65/EU. The full EU... - Page 30 in accordance with the instructions, may cause harmful interference to high-frequency radiation and should be avoided. Use only the supplied or radio approved antenna. communications. However, there is no guarantee that interference will not occur within the installation of the equipment. If the equipment causes harmful interference to radio or television reception (which can be detected by switching the device off and on), the user is advised to attempt to remedy...
