ABSCO SHEDS CG34552N2 Manual

Absco compact garage
Hide thumbs Also See for CG34552N2:

Advertisement

Table of Contents

AU: 1800 029 70 1
NZ: 0800 466 444
For construction in non-cyclonic areas
Wind rating: N2 as per AS4055-2021.
If you require a higher wind rating please contact
us: admin@absco.com.au or 1800 029 701
DOWNLOAD
OUR APP FOR
ASSEMBLY
VIDEOS
Absco Industries
Assembly Instruction Manual
ABSCO COMPACT GARAGE
MODEL: CG34552N2
3.4m W x 5.5m D x 2.48m H
admin@absco.com.au
www.abscosheds.com.au
Model: CG34552N2
Opening width: 2470mm
Opening height: 2180mm
Internal wall height: 2170mm
*You will need to contact a suitably qualified
professional to specify concrete slab or footings
for your site.
Brackets for securing the frame to either a
concrete slab or footings are included in this kit.
Anchors are not supplied.
Local authority approval must be obtained prior
to construction. Once you have selected your
site, draw a site plan and lodge your application
together with a copy of the engineering plans
located at the back of these instructions.
PLEASE LEAVE A REVIEW
Tell us about your experience!
Visit www.abscosheds.com.au/review
16/06/2025
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CG34552N2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ABSCO SHEDS CG34552N2

Summary of Contents for ABSCO SHEDS CG34552N2

  • Page 1 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H AU: 1800 029 70 1 admin@absco.com.au NZ: 0800 466 444 www.abscosheds.com.au Opening width: 2470mm Opening height: 2180mm Internal wall height: 2170mm *You will need to contact a suitably qualified professional to specify concrete slab or footings for your site.

  • Page 2: Tools Required

    ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Tools Required Tools Recommended BUILDERS’ STRING Safety Notes • Some parts and assemblies have sharp edges and/ or sharp corners. • The use of gloves and safety shoes is highly recommended.

  • Page 3: Helpful Hints

    ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Steps To Construct Your Garage Identification of parts ................4 Concrete slab/ footing details ............9 Rear frame assembly ................Center frame assembly ............... Front frame assembly ................15 Frame layout ..................
  • Page 4 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H 4. Missing parts To prevent damage in transit, some items are packed inside others. eg. some flashings may be inside channel sections, other items may be packed inside gutters, some roof sheets packed on top, some on the bottom etc.
  • Page 5 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H 80mm x 40mm Galvanized Channel Framing Sections TWO SECTIONS SINGLE SECTION BOXED TOGETHER 8 8 0 0 One leg of the channel section is 2mm shorter than the other leg to allow two channel sections to be boxed together.
  • Page 6 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H ROOF GUTTER 'L' ANGLE SHEET RIDGE FLASHING EDGE CAPPING BARN DOOR TRIM FLASHING SHEET PACK COMPONENT PART COMPONENT PART CHK QTY DESCRIPTION DESCRIPTION STEEL SHEET *STEEL SHEET...
  • Page 7 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H E E X X T T E E R R N N A A L L T T R R I I M M Q Q T T Y Y...
  • Page 8 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H B B R R A A C C K K E E T T S S , , P P L L A A T T E E S S A A N N D D A A C C C C E E S S S S O O R R I I E E S S ( ( C C O O N N T T . . ) )
  • Page 9 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H CONCRETE SLAB AND FRAME LAYOUT DETAILS 3388 1634 1634 ATTENTION EXTERNAL FRAME SIZE: 3388 x 5460 SLAB SIZE: This slab detail is used for 3388 x 5460 x 100mm THICK...
  • Page 10 (EG. Pozi drive) increases the risk of stripping the head of these screws. Some holes are pre-punched in Absco sheds’ frame sections, however the wide range of positions that most fasteners are required for means that the...
  • Page 11 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Rear Frame Parts required: 80 x 40 Channel 2) PART K1010 MIDWALL UPRIGHT LOWER 4) PART K1674 HORIZONTAL GIRTS 2) 2) PART M1705 TOP CHORDS 2) PART C0100 BRACKET CONNECTORS...
  • Page 12 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Absco Industries Assembly Instruction Manual Model: CG34552N2 16/06/2025...

  • Page 13: Internal Frame

    ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Internal Frame (2x required) Parts required: 80 x 40 Channel PART No. LENGTH C2069 2069 C1705 1705 APEX PLATES KNEE PLATES C1705 8 8 0 0 ONLY UPRIGHTS ARE...
  • Page 14 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Internal Frame (continued) (2x required) SECURE APEX PLATES AND KNEE PLATES TO EACH SIDE OF THE FRAME AS SHOWN. USE SELF DRILLING SCREWS AT EVERY PRE-PUNCHED LOCATION IN BOTH KNEE AND APEX PLATES WHERE CONNECTION TO THE FRAME IS POSSIBLE.
  • Page 15 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H 80 x 40 Channel 2) Type 'H' Channel 2205mm for door mullions 2) Purlin connection plates Front Frame Parts required: 80 x 40 Channel 2) S1705 Top chords...
  • Page 16 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Front Frame (continued) others, including some pieces with different notching patterns. Apply ZACO222 to both sides, see engineering plans for further detail Same both sides Absco Industries...

  • Page 17: Frame Configuration

    ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Frame Configuration Fasten the MPB Brackets to the frames as shown below, while the frames are still laying on the ground Secure brackets to frame uprights with six self-drilling screws each.
  • Page 18 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Frame Construction 1. Rear Frame To secure each frame to the slab, move the frame to its marked position. Whilst one other person holds the frame in position. Mark the hole position of each upright, move the frame away enough to drill the slab for each anchor, move the frame back and secure in position.
  • Page 19 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Frame Construction (continued) 1. Secure Front Frame Secure the front frame and side wall girts in place. Fit the sidewall girts in the same manner as the rear frame.
  • Page 20 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Secure Roof Purlins (18x Part K1780) PURLIN REAR REAR FRAME PURLIN FRAME PURLIN CENTRE FRAME Fit the roof purlins between each frame as shown, so the top...
  • Page 21 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Fit Strapping Check the diagonal roof measurements to ensure the frame is exactly square. Fit the strapping diagonally over the top of the frame, (refer to engineering plans), pulling and secure to each frame with three screws per connection.
  • Page 22 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Corner Sheets The four corner sheets of the garage are to be folded as Rear Wall Sheets shown below. Fold ONE pan sections as shown See the following page to understand where the sheets are below.
  • Page 23 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Fit Wall Sheets Corner Sheets Secure the four corner sheets in place as shown. CLA-2 226L CRA-2 226L • Position each sheet flush with the top of the frame, with the bottom end overlapping the concrete slab by 30mm to form a weather tight seal.
  • Page 24 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Roof Sheets Fitting sheet only by three pans 8 sheets per side. Turn pans up Roof sheets to with front and rear wall Length of hardwood with...
  • Page 25 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Fit Gutter And Downpipe Join lengths of gutter to match the length of the garage by notching the rolled edge of one to allow the other to slide into it. Put silicone in the joint then use rivets to fasten the sections together.
  • Page 26 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Fitting Trim / Flashing Ridge Capping 2x Ridge Capping (TR08) - 3030mm Long. Working from the garage towards the center, lay the ridge capping on the ridge of the roof sheets, overlapping sections to suit the length.
  • Page 27 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Barn Door Assembly P P a a r r t t s s r r e e q q u u i i r r e e d d p p e e r r d d o o o o r r : :...
  • Page 28 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Barn Door Assembly (continued) 1) 2145 X 773 Sheet 1) 2145 X 480 Sheet Use rivets (FAST009) to fix the inside face of the L flashing to the framing.

  • Page 29: Barn Door Installation

    ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Barn Door Installation View from inside looking outside 'L' Flashing Before hanging doors, fit one 'L' flashing to each door mullion and wall sheet with rivets to neatly trim these edges. Secure hinges to door mullions with screws as shown Secure both padbolts with screws as shown.
  • Page 30 ABSCO COMPACT GARAGE MODEL: CG34552N2 3.4m W x 5.5m D x 2.48m H Barn Door Installation (continued) Front View The top padbolt for the LH door should be placed along the top edge of the door so that when it is fully extended upwards the bolt does not hit on the rib of the sheeting above it.
  • Page 33 Absco Sheds Storage Guidelines • Absco Sheds are designed to be weatherproof for normal weather conditions. In the event of extreme weather conditions such as heavy rain, combined with high wind gusts, the ridge capping, sheeting joins, screw fi xings etc., may exhibit minor deformations which may allow some water entry. These areas should be checked regularly to ensure that maximum strength and protection is maintained.
  • Page 34 Lifetime Warranty Statement 1. DEFINITIONS 3. WARRANTY CLAIM PROCEDURE In this document, capitalised terms have the following meaning: 3.1. If, during the Lifetime Warranty Period, You believe the Product has a “ABSCO” means John Scholtes Investments (No. 1) Pty Ltd trading Defect, You must comply with the procedure set out in this clause 3.
  • Page 35 4. WARRANTY LIMITATIONS / EXCLUSIONS 4.1. To the extent permitted by law, this warranty will not apply where: the Product has been installed or used for a purpose that is not an Authorised Purpose; the Product has not been installed, assembled, maintained and/or special, indirect or consequential loss or damage of any nature operated in complete compliance with ABSCO’s Product Guide;...
