- Page 1 Installation / User Manual Photovoltaic Grid-connected Microinverter(Built-in WIFI-G4) SUN-M130/160/180/200/220G4-EU-Q0-I Ver:3.0.2...
-
Page 2: Table Of Contents
Table of Contents Important Safety Instructions Safety Instructions Radio Interference Statement The Meaning of Symbols Microinverter System Introduction Microinverters Maximize PV Energy Production More Reliable than Centralized or String Inverters Simple to Install Microinverter Introduction Microinverter System Installation Required Parts and Tools from You Parts list Installation Procedures Microinverter System Operating Instructions... -
Page 3: Important Safety Instructions
Important Safety Instructions This manual contains important instructions to follow during installation and maintenance Microinverter of the Photovoltaic Grid-connected Inverter( ).To reduce the risk of Microinverter electrical shock and ensure the safe installation and operation of the following symbols appear throughout this document to indicate dangerous conditions and important safety instructions. -
Page 4: Radio Interference Statement
but maintain the protective earthing conductor in the branch circuit breaker connect to the inverter ,then disconnect the DC inputs. In any circumstance, do not connect DC input when AC connector is unplugged. Please install isolation switching devices on the AC side of the inverter. Radio Interference Statement The equipment could radiate radio frequency energy and this might cause harmful interference to radio communications if not following the instructions when installing... -
Page 5: The Meaning Of Symbols
The Meaning of Symbols Labels Description Caution, risk of electric shock. Caution, risk of burn - Do not touch. Caution, hot surface. Symbol for the marking of electrical and electronics devices according to Directive ����/��/EC. Indicates that the device, accessories and the packaging must not be disposed as unsorted municipal waste and must be collected separately at the end of the usage. - Page 6 130/160/180/200/220G4 Meter Module Module Module Module Module Module Micro- Micro- Micro- inverter inverter inverter Module Module Module Module Module Module WIFI Boost Neutral Ground Router Monitoring system Distribution Box Inverter Model SUN-M���G�- SUN-M���G�- SUN-M���G�- SUN-M���G�- SUN-M���G�- EU-Q�-I EU-Q�-I EU-Q�-I EU-Q�-I EU-Q�-I PV Input Voltage ��.�V (��V-��V)
-
Page 7: Microinverters Maximize Pv Energy Production
This integrated system improves safety; maximizes solar energy harvest;increases system reliability, and simplifies solar system design, installation,maintenance, and management. Microinverters Maximize PV Energy Production Each PV module has individual Maximum Peak Power Tracking (MPPT) controls, which ensures that the maximum power is exported to the utility grid regardless of the performance of the other PV modules in the array. -
Page 8: Microinverter System Installation
Model Max. # AC grid Number Per branch SUN-M���G�-EU-Q�-I ��/��Hz, ���/���V � for ��A breaker ��/��Hz, ���/���V SUN-M���G�-EU-Q�-I � for ��A breaker ��/��Hz, ���/���V SUN-M���G�-EU-Q�-I � for ��A breaker SUN-M���G�-EU-Q�-I ��/��Hz, ���/���V � for ��A breaker SUN-M���G�-EU-Q�-I � for ��A breaker ��/��Hz, ���/���V Microinverter System Installation A PV system using Microinverters is simple to install. -
Page 9: Parts List
Parts list Please check the following table, to see whether all the parts are included in the package： User manual AC extension cable Microinverter x� User manual x� (optional) x N-� Bus AC connector T-connector Clip x� (optional) x� (optional) x N-� * Choose either Bus AC connector or Extension cable with European standard plug, can't use them in the same project. -
Page 10: Installation Procedures
Installation Procedures Step 1 - Install the AC branch circuit junction box a. Install an appropriate junction box at a suitable location on the PV racking system (typically at the end of a branch of modules). b. Connect the open wire end of the AC cable into the junction box using an appropriate gland or strain relief fitting. - Page 11 Step 2 - Attach the Microinverters to the racking or the PV module frame a. Mark the location of the Microinverter on the rack, with respect to the PV module and junction box or any other obstructions. b. Mount one Microinverter at each of these locations using hardware recommended by your module racking vendor.
- Page 12 As to parallel connection, please refer to page (P��-P��), use the T-connector, AC extension Microinverter in each branch. cable, Bus AC connector to connect the Male connector Model Wire Size Cable(mm) Torque value(max) Max cable length 10AWG 1.0Nm SUN-M130G4-EU-Q0-I 10AWG 1.0Nm SUN-M160G4-EU-Q0-I Outside cable 10AWG 1.0Nm SUN-M180G4-EU-Q0-I (L+N+PE)20m 10AWG 1.0Nm...
-
Page 13: Junction Box
Step 4 - Connect the wire open of branch end to the junction box. Junction Box Step 5 - Connect Microinverter to the PV Modules General Guidelines: Microinverter . a. PV modules should be connected to DC input ports of a b. -
Page 14: Troubleshooting
�. The units should start blinking red one minutes after turning on the AC circuit breaker. Then blue led blinking. This means they are producing power normally, the faster blinking of the blue led means more power generated. �. Configure the internal wifi module according to its user manual. �. -
Page 15: Troubleshooting A Non-Operating Microinverter
GFDI Error A four time red LED indicates the has detected a Microinverter Ground Fault Detector Interrupter (GFDI) error in the PV system. Unless the GFDI error has been cleared, the LED will remain four times blinking. Other Faults All other faults can be reported to the website and APP. WARNING: Never disconnect the DC wire connectors under load. - Page 16 To troubleshoot a non-operating Microinverter, Follow the steps below in order: �. Verify the utility voltage and frequency are within ranges shown in the Technical Data section of this manual. �. Check the connection to the utility grid.Disconnect AC firstly,then disconnect DC and make sure the utility grid voltage can be measured at AC connector.
-
Page 17: Replacement
Replacement Follow the procedure to replace a failed Microinverter Microinverter from the PV Module, in the order shown below: A. Disconnect the �. Disconnect the AC by turning off the branch circuit breaker. Microinverter . �. Disconnect the AC connector of the �. -
Page 18: Equipment Protection
M130/160/180G4 Microinverter Datasheet SUN-M���G�- SUN-M���G�- SUN-M���G�- Model EU-Q�-I EU-Q�-I EU-Q�-I PV String Input Data Max. PV Input Power(W) 210-460(4 Pieces) 210-560(4 Pieces) 210-630(4 Pieces) Max. PV Input Voltage(V) Start-up Voltage(V) PV input voltage range(V) 20-60 MPPT voltage range(V) 25-55 Full Load MPPT Voltage Range(V) 29-55 31.5-55 33-55... - Page 19 M130/160/180G4 Microinverter Datasheet SUN-M���G�- SUN-M���G�- SUN-M���G�- Model EU-Q�-I EU-Q�-I EU-Q�-I Interface Communication Interface WiFi General Data Operating Temperature Range (°C) -40℃to +65℃, >45℃ derating 0-100% Permissible Ambient Humidity Permissible Altitude (m) 2000m Noise (dB) ≤ 25 dB Ingress Protection(IP) Rating IP 67 Inverter Topology Isolated...
- Page 20 M200/220G4 Microinverter Datasheet SUN-M���G�- SUN-M���G�- Model EU-Q�-I EU-Q�-I PV String Input Data Max. PV Input Power(W) 210-700(4 Pieces) 210-770(4 Pieces) Max. PV Input Voltage(V) Start-up Voltage(V) PV input voltage range(V) 20-60 MPPT voltage range(V) 25-55 Full Load MPPT Voltage Range(V) 36.5-55 37.5-55 Rated PV input voltage(V)
-
Page 21: General Data
M200/220G4 Microinverter Datasheet SUN-M���G�- SUN-M���G�- Model EU-Q�-I EU-Q�-I Interface Communication Interface WiFi General Data Operating Temperature Range (°C) -40℃to +65℃, >45℃ derating 0-100% Permissible Ambient Humidity Permissible Altitude (m) 2000m Noise (dB) ≤ 25 dB Ingress Protection(IP) Rating IP 67 Inverter Topology Isolated Over Voltage Category... -
Page 22: Wiring Diagram
Wiring Diagram Sample Wiring Diagram Three Phase - �� -... -
Page 23: Sample Wiring Diagram Single Phase
Sample Wiring Diagram Single Phase - �� -... -
Page 24: Monitoring Platform
Monitoring Platform This series Microinverter has built-in WIFI modular which is able to connect router directly. For WIFI configuration, please check the manual of “Built-in WIFI modular Microinverter WIFI configuration Manual ”. Web monitoring address: (for Solarman distributor account) https://pro.solarmanpv.com; (for Solarman end user account) https://home.solarmanpv.com For mobile phone monitoring system, scan the QR code to download the APP. -
Page 25: How To Connect The Microinverter To The Router Via Web
Microinverter SN: 2302202012 Built-in datalogger :3907047089 Also, the default password can be changed. If forgetting the modified password, please contact service@deye.com.cn for help. �. Open a browser and enter ��.��.���.���. Both username and password are "admin". (Recommended browser: IE �+, Chrome ��+, Firefox �� + ). - Page 26 Status Help Inverter information Wizard Inverter serial number Quick Set Firmware version(main) The device can be used as Advanced Firmware version(slave) a wireless access point(AP mode) to facilitata users to Upgrade Inverter model configure the device, or it can also be used as a Rated power Restart wireless information terminal...
- Page 27 �. Enter the password and click Next. Status Help Wizard Quick Set Please fill in the following information: Most systems support the Advanced function of DHCP to obtain IP address automatically. Upgrade Please select disable and Password(8-64 bytes) add it manually if your router Restart (Note: case sensitive) does not support such...
- Page 28 Status Help Wizard Setting complete! Quick Set After clicking OK,the system will restart Advanced Click OK, the settings will take effect and the system will immediately. Upgrade restart immediately. Restart If you leave this interface without clicking OK, the settings will Reset be ineffective.
-
Page 29: How To Connect In App
How to connect in APP 1. Registration Open the app of SOLARMAN Smart and register an account. Click "Register" and create your account here. Register English SOLARMAN Smart Phone Number E-mail E-mail Phone Number Username E-mail E-mail Please enter E-mail E-mail Password Verification Code... - Page 30 3. Add a Logger Optional �: Enter the logger SN manually. Optional �: Click the icon in the right and scan the QR code to enter logger SN. You can find logger SN on the carton packaging or on the logger body. MY Plants Logger hinzufugen Create a Plant...
-
Page 31: Maintenance
Maintenance Deye microinverters do not require any specific regular maintenance. Troubleshooting If you have any question you can't handle during using Deye products,please contact with our after services by email:service@deye.com.cn,details can refer to products' warranty. EU Declaration of Conformity within the scope of the EU directives ·... -
Page 32: Eu Declaration Of Conformity
Models: SUN-M130G4-EU-Q0-I; SUN-M160G4-EU-Q0-I; SUN-M180G4-EU-Q0-I; SUN-M200G4-EU-Q0-I;SUN-M220G4-EU-Q0-I; Name and address of the manufacturer: Ningbo Deye Inverter Technology Co., Ltd. No. 26 South YongJiang Road, Daqi, Beilun, NingBo, China This declaration of conformity is issued under the sole responsibility of the manufacturer. Also this product is under manufacturer’s warranty. - Page 33 NINGBO DEYE INVERTER TECHNOLOGY CO., LTD. Add.: No.26 South YongJiang Road, Daqi, Beilun, NingBo, China. Tel.: +86 (0) 574 8622 8957 Fax.: +86 (0) 574 8622 8852 E-mail: service@deye.com.cn Web.: www.deyeinverter.com...
