- Page 1 Smappee EV Base Installation manual ² English – 1.01.1 – June 2025...
- Page 2 The specifications and other information in this document were verified to be accurate and complete at the time of its publication. Due to ongoing product improvement, this information is subject to change at any time without prior notice. For the latest information, see our online documentation: smappee.com/downloads...
-
Page 3: Table Of Contents
Table of contents Introduction ............................4 Safety instructions ........................... 5 Overview of the EV Base ........................ 7 Prepare the installation ......................... 15 Installation and configuration ......................19 Annexes ..............................35 EV Base – Installation manual – English... -
Page 4: Introduction
Any resulting damage is excluded from the warranty of the device. Any modification that is not in writing confirmed by Smappee will void the warranty. For more information, refer to smappee.com. -
Page 5: Safety Instructions
• Do not expose the charging station to heat, flame or extreme cold. • Do not attempt to open, repair, or service any parts. Contact Smappee or your service partner for • further information. Only use the charging station under the specified operating conditions. -
Page 6: Maintenance
2.2. Maintenance Observe the maintenance schedule (page 42). • Clean the outside only with a dry, clean cloth. • • Do not use abrasive agents or solvents. • May not be carried out during rain or if air humidity exceeds 95 %. 2.3. -
Page 7: Overview Of The Ev Base
3. Overview of the EV Base 3.1. Models Article no. Description EVBC-2332-B-E-W 5425036934887 EV Base White EVBC-2332-B-E-B 5425036934894 EV Base Black EVBC-2332-C5-E-W 5425036934900 EV Base White with cable EVBC-2332-C5-E-B 5425036934917 EV Base Black with cable EV Base – Installation manual – English... - Page 8 Quantity Description EV Base Concrete anchors (Ø 12 mm x 100 mm) M12 washers (Ø 50 mm) Smappee Charge Card, for the owner of the charging station QR code label Splitter Charging cable M32 cable gland Cable ties for strain relief...
- Page 9 3.3. Directional determination Image 1: Directional determination Description Front Rear Left Right Bottom EV Base – Installation manual – English...
- Page 10 3.4. Identification label of the EV Base Position of the identification label of the EV Base The identification label of your charging station is located above the connector 1. Image 2: Position of the identification label EV Base – Installation manual – English...
- Page 11 Content of the identification label of the EV Base The identification label of your charging station has the following information. Image 3: Identification label Description Manufacturer Article number Electrical rating Operating temperature Manufacturing date QR code to scan during configuration of the charging station Ingress protection rating Serial number EAN-code...
-
Page 12: Technical Specifications
3.5. Technical specifications Feature Description Socket Type 2 cables Physical properties Dimensions 1200 x 600 x 150 mm Weight (excluding packaging) Charging station with sockets: 33 kg Charging station with sockets with shutter: 33 kg Charging station with cables: 39.5 kg Socket All variants manufactured as of January 31, 2025, have a... - Page 13 Feature Description Socket Type 2 cables Rated current (I 32 A Rated current (I ) of a circuit 32 A Rated peak withstand current 6 kA Rated conditional short-circuit 6 kA current (I EMC classification Class B Connection method AC, permanently connected Interfaces &...
- Page 14 NOTE The operating temperate assumes the ambient temperature of a product delivered in the default enclosure colours RAL 9016 (star white) or RAL 7021 (black grey). Direct exposure to sunlight may have an adverse effect on the temperature range. NOTE If the product is exposed to lower or higher ambient temperatures, continuous operation cannot be guaranteed.
-
Page 15: Prepare The Installation
4. Prepare the installation For overload protection or optimised self-sufficiency, additional Smappee Infinity components must be installed to measure the Grid and Solar, Battery or other submetering if applicable. NOTE For more information, refer to the Smappee Academy. The first step is to prepare the physical installation of the EV Base as described in this chapter. - Page 16 4.2. Tools (not included) Screwdrivers and a 2.5 mm Hex screwdriver • Multimeter and earth ground meter • • Wire stripper and cutter • Needle-nose pliers Ferrules crimper (when using stranded power supply cables) • RJ45 crimping tool • Drill and rock drill diameter 12 mm •...
- Page 17 Instructions Proceed as follows. Make a foundation hole large enough. Depending on the subsoil, the size may vary. Please refer to the technical specifications of size and weight to determine and construct a solid foundation for the EV Base. When dimensioning the foundation, it is advisable to carry out a static load capacity analysis according to the relevant standards.
- Page 18 3. If applicable, remove the charging cables. 4. Remove the rear plate. The rear side of the EV Base is the side without the Smappee logo. Use a 2.5 mm key to loosen the six hexagon socket screws of the rear plate.
-
Page 19: Installation And Configuration
5. Connect the EV Base to the internet (page 26) After the physical installation, these are the last steps to have the EV Base ready for use: 6. Configure the EV Base with the Smappee App (page 32) 7. Complete the installation of the EV Base (page 33) 8. - Page 20 5.1. Install the floorplate of the EV Base Context The EV Base is designed to be installed at ground level using the floorplate. Instructions Proceed as follows. Put the floorplate on the location of the EV Base. Route the two power supply cables and one network cable through the central opening of the floorplate.
- Page 21 5.2. Attach the EV Base to the floorplate Context The concrete anchors in the floorplate give the position where you attach the EV Base to the floorplate. Instructions Proceed as follows. Position the EV Base above the floorplate. Lift the EV Base with at least two people. Make sure no cable can be crushed during lowering the EV Base.
- Page 22 5.3. Connect the charging cables Context NOTE This section is only relevant if the EV Base comes with a fixed charging cable. If you have a socket-variant, go to Connect the power supply of the EV Base (page 24). Instructions Proceed as follows.
- Page 23 4. Connect each wire to the corresponding connection point as indicated with a label. Do not forget to connect the CP data wire of the charging cable to the CP connection point. Image 10: View on the cable connections 5. Tighten the cable gland. 6.
- Page 24 5.4. Connect the power supply of the EV Base Context Each charging point has an MID meter that measures the power supplied to the charging station. No other components must be installed to measure the charging station consumption. Each connector must have a dedicated own circuit breaker. For more information, refer to Installation prerequisites (page 15).
- Page 25 Image 11: View on the power supply connection for each grid type Put the green/yellow conductor in the corresponding terminal block for the protective earth • conductor. Put the blue conductor, if applicable, in the corresponding connection point for the neutral of •...
- Page 26 Smappee Connect must be replaced with a Smappee 4G Connect inside the building. NOTE The charging station comes with a Smappee Splitter, which is only used if you put the Connect or the 4G Connect in the building. If the wired connection goes directly to the charging station, you don’t need the Smappee Splitter.
- Page 27 2. Cut the network cable to the necessary length. The network cable from your router goes to the RJ45 port of the Connect. Image 5 View on the RJ45 port on the Connect 3. Attach the RJ45 connector (not supplied). 4.
- Page 28 Image 12: View on the A+B port of the relay board 4. Route the UTP cable into the building. 5. Connect the RJ45 connector of the UTP cable to the A+B port of the Smappee Splitter inside the building. Image 13: View on the A+B port of the Smappee Splitter The Smappee Splitter is included with the charging station and manages the communication between the charging station and the building.
- Page 29 6. Check whether the RJ10 cable from the Smappee Connect is plugged into one of the two B ports and reconnect it if necessary. Image 14: View on the B ports of the Smappee Connect 7. Connect the other end of the RJ10 cable to the B port of the Smappee Splitter.
- Page 30 Via 4G NOTE The position of the antenna of the Smappee 4G Connect (upright or angled) does not affect the signal strength. Proceed as follows: Unplug the RJ10 cable from the Smappee Connect and remove the Smappee Connect from the EV Base.
- Page 31 5. Connect the RJ45 connector of the UTP cable to the A+B port on the Smappee Splitter inside the building. Image 18: View on the A+B port of the Smappee Splitter The Smappee Splitter is included with the charging station and manages the communication between the charging station and the building.
- Page 32 Figure 21: QR code on the front of the charging station 2. Follow the steps shown in the Smappee App. Post-requisites The settings of your charging station can be adjusted in the Smappee App or the Smappee Dashboard. Name •...
- Page 33 5.7. Complete the installation of the EV Base Context CAUTION Risk of electric shock. Make sure no tools are in the charging station and people stand free from the charging station. Image 22: View on the bolts that hold the rear plate and floorplate Instructions Proceed as follows.
- Page 34 5.8. Give the owner a smooth start Give the Smappee Charge Card to the charger owner. 2. Tell them to scan the QR code on the front of the charger. Figure 23: QR code on the front of the charging station...
-
Page 35: Annexes
Annexes Declaration of conformity EV Base – Installation manual – English... -
Page 36: Phase Rotation
2 and phase 3 by doing the following: During the installation you can do the physical phase rotation. • During the configuration with the Smappee App you need to set the phase mapping. • EV Base – Installation manual – English... - Page 37 Charging Connector Internal wiring of stations number on the the phases and from the charging their colour in the 3 x 400V + N Smappee square charging station EV Line Brown Black Grey Brown Black Connector 1 Grey EV Base 1...
- Page 38 Colour code explanation Status of the Smappee Connect This status is relevant during the configuration and use of the charging station. Image 24: Position of the LED on the Smappee Connect Colour Status Meaning More information Blue continuous Starting up The Connect is starting up.
- Page 39 Status of the Smappee 4G Connect This status is relevant during the configuration and use of the charging station. Image 25: Position of the LED on the Smappee 4G Connect (antenna not shown) Colour Status Meaning More information Cyan pulsing...
- Page 40 Status of the charging station This status is relevant during the use of the charging station. Image 26: Position of the RFID readers with LED on the EV Base NOTE Each charging point can have a different status. EV Base – Installation manual – English...
- Page 41 Charging point is Something is wrong or the charging unavailable. station has been disabled. Enable the charging station with the Smappee App or contact your installer. White continuous Charging point is Connect your electric vehicle (EV) with available. the charging station.
-
Page 42: Maintenance Schedule
Maintenance schedule To ensure safe and reliable operation, periodic maintenance and inspections are recommended. The frequency depends on usage and environmental conditions. WARNING Before starting maintenance activities, consider all safety precautions as listed in Safety instructions (page 5). NOTE For publicly accessible charging stations, periodic inspections may be required by local regulations.
