- Page 1 Smappee EV Wall Installation manual English – 1.01.1 – June 2025...
- Page 2 The specifications and other information in this document were verified to be accurate and complete at the time of its publication. Due to ongoing product improvement, this information is subject to change at any time without prior notice. For the latest information, see our online documentation: smappee.com/downloads...
-
Page 3: Table Of Contents
Table of contents Introduction ............................4 Safety instructions ........................... 5 Overview of the EV Wall ......................... 7 Preparing the installation ....................... 15 Installation and configuration ......................19 Annexes ..............................34 EV Wall – Installation manual – English... -
Page 4: Introduction
Any resulting damage is excluded from the warranty of the device. Any modification that is not in writing confirmed by Smappee will void the warranty. For more information, refer to smappee.com. -
Page 5: Safety Instructions
Do not immerse the charging station in water or any other liquids. Do not expose the charging station to heat, flame or extreme cold. • Do not attempt to open, repair, or service any parts. Contact Smappee or your service partner for • further information. -
Page 6: Maintenance
2.2 Maintenance Observe the maintenance schedule (page 39). • Clean the outside only with a dry, clean cloth. • Do not use abrasive agents or solvents. • May not be carried out during rain or if air humidity exceeds 95 %. •... -
Page 7: Overview Of The Ev Wall
3 Overview of the EV Wall 3.1 Models Article number Description EVWC-332-BR-E-B 5425036934849 EV Wall Black EVWC-332-C8R-E-B 5425036934863 EV Wall Black with cable EVWC-332-BR-E-W 5425036934832 EV Wall White EVWC-332-C8R-E-W 5425036934856 EV Wall White with cable EV Wall – Installation manual – English... - Page 8 If the EV Wall has a charging cable, there is a Charging cable box attached to the EV Wall box. EV Wall box Image 1: Content of the box with the charger Quantity Description Smappee EV Wall EV Wall mounting plate Screw and plug (Ø 6 mm x 50 mm) Small screw (M4 x 6 mm) Quick Install Guide...
- Page 9 Charging cable box Image 2: Content of the box with the charging cable Quantity Description Charging cable Cable tie for strain relief Cable holder Screw and plug (Ø 6 mm x 50 mm) M32 cable gland EV Wall – Installation manual – English...
- Page 10 3.3 Directional determination Image 3: Directional determination Description Front Rear Left Right Bottom 3.4 Identification label of the EV Wall Position of the identification label of the EV Wall The identification label is on the bottom of the charging station. Image 4: Position of the identification label EV Wall –...
- Page 11 Identification label of the EV Wall Image 5: Identification label Description Manufacturer Article number Electrical rating Operating temperature Manufacturing date QR code to scan during configuration of the charging station Ingress protection rating Serial number EAN-code Waste disposal symbol EV Wall – Installation manual – English...
-
Page 12: Technical Specifications
3.5 Technical specifications Feature Description Socket Type 2 cable Physical properties Dimensions 300 mm x 300 mm x 110 mm Weight (excluding packaging) 7.4 kg 12.4 kg (including cable holder) Socket All variants manufactured as of January 31, 2025, have a socket with shutter. Charging cable length 1 x 8 m Supply line connection... - Page 13 Feature Description Socket Type 2 cable Rated peak withstand current 6 kA Rated conditional short-circuit 6 kA current (I EMC classification Class B Connection method AC, permanently connected Interfaces & Connectivity Information status RGB LED Session activation Plug and charge, Swipe RFID, Scan QR code, optional Pay Station Connectivity Ethernet 100BASE-T, Wi-Fi 2.4 GHz...
- Page 14 NOTE The operating temperate assumes the ambient temperature of a product delivered in the default enclosure colour RAL 7021 (black grey). Direct exposure to sunlight may have an adverse effect on the temperature range. NOTE If the product is exposed to lower or higher ambient temperatures, continuous operation cannot be guaranteed.
-
Page 15: Preparing The Installation
4 Prepare the installation For overload protection or optimised self-sufficiency, additional Smappee Infinity components must be installed to measure the Grid and Solar, Battery or other submetering if applicable. NOTE For more information, refer to the Smappee Academy. The first step is to prepare the physical installation of the EV Wall as described in this chapter. - Page 16 • Route the power supply cable and the network cable, if applicable, to the position where the charging station will be installed. NOTE Make sure that there is at least 30 cm power supply and 30 cm network cable length available at the location of the EV Wall to be able to connect it easily.
- Page 17 4.4 Prepare the EV Wall Context For safe and compact transport of the EV Wall: The EV Wall mounting plate is in the same box as the EV Wall, together with the supplies. • The charging cable is in a separate box, together with the cable holder, 2 screws and 2 plugs. •...
- Page 18 4.5 Install the EV Wall mounting plate Context The EV Wall mounting plate lets you smoothly attach the charging station to a wall. Image 7: View on the EV Wall mounting plate Instructions Proceed as follows. Put the mounting plate on the position where the EV Wall will come. Make sure the mounting plate is positioned with the 2 insert holes on the bottom.
-
Page 19: Installation And Configuration
6. Install the front plate (page 30) After the physical installation, the configuration can be done. For more information, refer to: 7. Configure the EV Wall with the Smappee App (page 31) 8. Complete the installation of the EV Wall (page 32) 9. - Page 20 5.1 Attach the EV Wall to the mounting plate Context The EV Wall mounting plate lets you smoothly attach the charging station to a wall. Image 8: View on the EV Wall Instructions Proceed as follows. Position the EV Wall in front of the mounting plate. 2.
- Page 21 5.2 Connect the power supply of the EV Wall Context Each EV Wall has a MID meter that measures the power supplied to the charging station. No other components must be installed to measure the charging station consumption. Each EV Wall has must have its own circuit breaker. For more information, refer to Installation prerequisites (page 15).
- Page 22 • Put the phase conductors in the necessary connection point of the residual current device. NOTE L1 = brown phase 1-conductor • L2 = black phase 2-conductor, if applicable • L3 = grey phase 3-conductor, if applicable • For a 3 x 230 V without a transformer, and thus no neutral conductor, put the grey conductor in the neutral connection point.
- Page 23 5.3 Connect the charging cable Context NOTE This section is only relevant if the EV Wall comes with a fixed charging cable. If you have a socket-variant, go to Connect the EV Wall (page 25). The charging cable is delivered in a separate box. Image 10: View on the cable connections Instructions Proceed as follows.
- Page 24 5.4 Install the cable holder Context NOTE This section is only relevant if the EV Wall comes with a fixed charging cable. If you have a socket-variant, go to Connect the EV Wall (page 25). The charging cable can be stored in a cable holder to keep it tidy. Image 11: View on the stored cable holder Instructions Proceed as follows.
- Page 25 Smappee Connect must be replaced with a Smappee 4G Connect inside the building. NOTE The charging station comes with a Smappee Splitter, which is only used if you put the Connect or the 4G Connect in the building. If the wired connection goes directly to the charging station, you don’t need the Smappee Splitter.
- Page 26 Image 14: View on the A+B port of the relay board 4. Route the UTP cable into the building. 5. Connect the RJ45 connector of the UTP cable to the A+B port of the Smappee Splitter inside the building. EV Wall – Installation manual – English...
- Page 27 The Smappee Splitter is included with the charging station and manages the communication between the charging station and the building. 6. Check whether the RJ10 cable from the Smappee Connect is plugged into one of the two B ports and reconnect it if necessary.
- Page 28 Image 19: View on the A+B port of the relay board 4. Route the UTP cable into the building. 5. Connect the RJ45 connector of the UTP cable to the A+B port on the Smappee Splitter inside the building. EV Wall – Installation manual – English...
- Page 29 The Smappee Splitter is included with the charging station and manages the communication between the charging station and the building. 6. Connect the supplied RJ10 cable from the Smappee 4G Connect to one of its two B ports. Image 21: View on the B ports of the Smappee 4G Connect 7.
-
Page 30: Install The Front Plate
Make sure no tools are in the charging station and people stand free from the charging station. Context The front plate has a PCB with RFID reader and LED for the Smappee Avatar. Image 23: View on the 12-pin cable Instructions Remove the nuts from the threaded rods of the front plate. - Page 31 Figure 24: QR code on the front of the charging station 2. Follow the steps shown in the Smappee App. Post-requisites The settings of your charging station can be adjusted in the Smappee App or the Smappee Dashboard. • Name •...
- Page 32 5.8 Complete the installation of the EV Wall Instructions Proceed as follows. Put the M4 nuts on the threaded rods and tighten them. Image 25: View on the inner nuts As a result, the EV Wall is ready for use. For more information, refer to the annex Status of the charging station (page 38).
- Page 33 5.9 Give the owner a smooth start Give the Smappee Charge Card to the charger owner. 2. Tell them to scan the QR code on the front of the charger. Figure 26: QR code on the front of the charging station...
-
Page 34: Annexes
• • During the configuration with the Smappee App you need to set the phase mapping Example of phase rotation When you have an EV Wall and an EV One, connect the power supply as indicated with the bold Xs. -
Page 35: Declaration Of Conformity
Declaration of conformity EV Wall – Installation manual – English... - Page 36 Colour code explanation Status of the Smappee Connect This status is relevant during the configuration and use of the charging station. Image 27: Position of the LED on the Smappee Connect Colour Status Meaning More information Blue continuous Starting up The Connect is starting up.
- Page 37 Status of the Smappee 4G Connect This status is relevant during the configuration and use of the charging station. Image 28: Position of the LED on the Smappee 4G Connect (antenna not shown) Color Status Meaning More information Cyan pulsing...
- Page 38 Charging station Something is wrong or the charging is unavailable. station has been disabled. Enable the charging station with the Smappee App or contact your installer. White continuous Charging station Connect your electric vehicle (EV) with is available. the charging station.
-
Page 39: Maintenance Schedule
Maintenance schedule To ensure safe and reliable operation, periodic maintenance and inspections are recommended. The frequency depends on usage and environmental conditions. WARNING Before starting maintenance activities, consider all safety precautions as listed in Safety instructions (page 5). NOTE For publicly accessible charging stations, periodic inspections may be required by local regulations.
