Summary of Contents for Brinkmann Pro 2300

  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. Brinkmann 2300 Owner's Manual Shop genuine replacement parts for Brinkmann 2300 Find Your Brinkmann Grill Parts - Select From 1001 Models -------- Manual continues below --------...
  • Page 2: Notice To Installer

    Gas Porcelain Outdoor Grill OWNER’S MANUAL ASSEMBLY AND OPERATING INSTRUCTIONS SAVE THIS MANUAL FOR FUTURE REFERENCE WARNING HAZARDOUS EXPLOSION MAY NOTICE TO INSTALLER: RESULT IF THESE WARNINGS AND LEAVE THESE INSTRUCTIONS INSTRUCTIONS ARE IGNORED. READ WITH THE GRILL OWNER FOR AND FOLLOW ALL WARNINGS AND FUTURE REFERENCE.
  • Page 3: Important Safety

    IMPORTANT SAFETY WARNINGS WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
  • Page 4 WARNING • Never use natural gas in a unit designed for liquid propane gas. • Never use charcoal briquets or lighter fluid in a gas grill. • Leak test all connections before first use, even if grill was purchased fully assembled and after each tank refill.
  • Page 5: Installation Information

    WARNING • FOR OUTDOOR USE ONLY. DO NOT operate in a building, garage or other enclosed area such as a shed or breezeway. • Use your grill OUTDOORS in a well ventilated space away from dwellings or other buildings to prevent dangers associated with gas accumulation and toxic vapors.
  • Page 6 The cylinder must also be equipped with: • A shut-off valve terminating in a Type 1 gas cylinder valve outlet. • A Type 1 valve that prevents gas flow until a positive seal is obtained. • An arrangement for vapor withdrawal. •...
  • Page 7: Filling The Lp Gas Cylinder

    150°C). If this should happen, remove the entire regulator assembly and dispose of properly. A replacement regulator assembly can be purchased by contacting Brinkmann at 1-800-527-0717. The cause of the excessive heat should be determined and corrected before using your grill again.
  • Page 8 During assembly and/or replacement of the gas cylinder, keep the gas supply hose free of kinks and/or damage. Visually inspect the hose assembly prior to each use for evidence of damage, excess wear, or deterioration. If found, replace the assembly before using your grill. Only the Brinkmann supplied replacement should be used. WARNING CONNECTING HOSE AND REGULATOR TO AN LP GAS CYLINDER •...
  • Page 9: Leak Testing

    DANGER LEAK TESTING: To prevent fire or explosion hazard: • DO NOT smoke or permit ignition sources in the area while conducting a leak test. • Perform test OUTDOORS only in a well ventilated area. • Never perform a leak test with a match or open flame. •...
  • Page 10: Pre-Start Checklist

    Replace with hose and regulator, Model No. 155-2400-0, which can be obtained by contacting Brinkmann at 1-800-527-0717. • Leak check all gas connections and hose. See section on "Leak Testing".
  • Page 11: Lighting Instructions

    WARNING LIGHTING INSTRUCTIONS: Follow the instructions exactly. 1. OPEN THE GRILL LID before attempting to light a burner so that fumes do not accumulate inside the grill. An explosion could occur if grill lid is down. 2. Check that all burner control knobs and the cylinder valve are turned to the OFF position. 3.
  • Page 12: Lighting The Side Burner

    LIGHTING THE SIDE BURNER: 1. Open lid to the side burner before lighting. 2. Turn on the side burner by pressing in and rotating the control knob to the HIGH position. 3. Press and hold the igniter button on the main control panel for 3-5 seconds until the burner ignites.
  • Page 13 WARNING OPERATING THE GRILL: Never use Charcoal or Lighter Fluid inside your Gas Grill. Read and follow all warnings and instructions contained in the preceding sections of this manual. BREAKING IN YOUR GRILL: • In manufacturing and preserving the components of your grill, oil residue may be present on the burner and cooking surfaces of your grill.
  • Page 14: Rotisserie Cooking

    ROTISSERIE COOKING: • Your grill was pre-drilled from factory to include mounting holes for a Brinkmann rotisserie (sold separately). Do not use a rotisserie not specifically manufactured for this grill. • Read and follow all instructions provided with the rotisserie. Save instructions for future reference.
  • Page 15: Transporting And Storage

    • If storing the grill outdoors, cover the grill with a grill cover for protection from the weather. A grill cover can be purchased by contacting: The Brinkmann Corporation at 1-800-527-0717. CLEANING AND MAINTENANCE: • Keep grill area clear and free from combustible materials, gasoline or other flammable vapors and liquids.
  • Page 16: Cooking Grills

    BURNER ASSEMBLY/MAINTENANCE • Although your burners are constructed of cast iron, they may rust as a result of the extreme heat and acids from cooking foods. Regularly inspect the burners for cracks, abnormal holes, and other signs of corrosion damage. If found, replace the burner. DO NOT obstruct the flow of combustion and ventilation air.
  • Page 17: Troubleshooting

    See section on Connection to the LP Cylinder. • Grill is Too Hot 1. Excess grease build-up causing grease fires. 2. Damaged or faulty regulator. Replace with Brinkmann parts. 3. Cook on a lower temperature setting.
  • Page 18: Proper Care And Maintenance

    • To protect your grill from excessive rust, the unit must be kept clean and covered at all times when not in use. A grill cover may be ordered directly from Brinkmann by calling 1-800-468-5252 or 1-800-527-0717. • Wash cooking grills and heat shields with hot, soapy water, rinse well and dry. Lightly coat cooking grill with vegetable oil or vegetable oil spray.
  • Page 19: Parts List

    READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT. The following provided tools are required to assemble this Brinkmann ProSeries 2300 Grill: • Flathead Screwdriver • Hex Nut Wrench...
  • Page 20 FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 1-800-527-0717. (Proof of purchase will be required.) Inspect contents of the box to ensure all parts are included and undamaged.
  • Page 21: Parts Bag Contents

    PARTS BAG CONTENTS Make sure you have all items listed under PARTS LIST and PARTS BAG CONTENTS before you begin the installation process. Your Parts Bag will include: Qty. Qty. 24 M6 X 12mm bolts Wheel washers AA /1.5V Alkaline battery Wheel axle bolts Screwdriver Star Washers...
  • Page 22 Choose a good, cleared assembly area and get a friend to help you put your grill together. Lay cardboard down to protect grill finish and assembly area. Step 1 Attach cart base to side panels. Insert four M6 X 12mm screws through cart base and into legs and tighten securely.
  • Page 23 Step 5 Install the wheels as illustrated, by inserting the wheel axle bolts Tire through the wheels, washers and right side panel axle holes. Tighten Hubcap axle bolts securely using hex nut Wheel axle wrench provided in parts pack. Washer bolt Step 6 Hubcap...
  • Page 24 Step 9 Attach tank heat shield to heat shield plate using one #8 self-tapping screw. Heat Shield Plate Tank Heat Shield Step 10 Attach heat shield plate to cart Heat Shield Plate frame assembly using four M6 X 12mm bolts and star washers.
  • Page 25 Note: When performing Step 12, Lift grill body from front and Grill Body Assembly rear panels to avoid injury to hands and fingers. Step 12 With the help of a friend, place grill body assembly on cart frame. Grill body will rest on angled base of vertical supports.
  • Page 26 Step 14 Attach side table to left side of cart frame assembly. Insert two M6 X 12mm bolts into each left leg. Place table over bolts and slide toward front of grill, then tighten securely. Step 15 Attach side burner assembly to right side of cart frame assembly.
  • Page 27 Step 16 Attach the hose heat shield to the right side of the cart frame using Hose two #8 self-tapping screws. Heat Shield Step 17 Remove two bolts and washers Burner Venturi from the side burner valve. Insert the side burner valve assembly through the hole in the side burner table base, then firmly seat the Side...
  • Page 28 Step 19 Attach side burner igniter lead wire to the electrode as illustrated. Side Burner Igniter Lead Electrode Step 20 Insert grease tray into opening on backside of grill. Make sure to slide tray onto tracks as illustrated. Grease Tray Step 21 Slide grease tray into grease tray bracket located under grill bottom...
  • Page 29 Step 22 Warming Rack Place the porcelain coated heat tents on lower level of grill body assembly directly above burners. Cooking Grills Porcelain Heat Step 23 Tents Place porcelain cast iron cooking grills on support ribs directly above porcelain heat tents. Step 24 Place warming rack in brackets so that it sits above the cooking grills.
  • Page 30 ProSeries 2300 (Assembled)
  • Page 31 ACCESSORIES RIB RACK PROFESSIONAL SHISH-KABOB SKEWERS Chrome-plated rack can greatly increase the cooking These heavy-duty, 18" shish-kabob skewers are extra-long for fabulous capacity of your grill. Holds ribs, chicken halves, restaurant style kabobs. Made of rust resistant stainless steel to last for years. potatoes and corn vertically to triple cooking capacity.
  • Page 32 Restaurant-style aluminum fry pan with nickel plated wire straining basket is an essential tool for frying fish, chicken, french fries, onion rings and more. Strainer basket holder helps drain excess oil. Use outdoors with the Brinkmann Backyard Kitchen and avoid the mess and odor of frying indoors.
  • Page 33: Warranty

    • This warranty does not cover surface scratches, rust or heat damage to the finish, which is considered normal wear. • The Brinkmann Corporation may elect to repair or replace damaged units covered by the terms of this warranty. • This warranty extends to the original purchaser only and is not transferable or assignable to subsequent purchasers.
