Pyro MKIII Cast Range
DEDICATED EXTERNAL AIR SUPPLY KIT
USER INSTRUCTIONS AND INSTALLATION
Version 1 26/12/23
Contents of manual may be updated without notice.
For the latest version of this manual please refer
to our website: www.livingfire.com.au
MKIII 750 GF
MKIII 750 GF2L
MKIII 750 GF2LR
MKIII 750 GF3
Advertisement
Related Manuals for Paul Agnew MKIII 750 GF
Summary of Contents for Paul Agnew MKIII 750 GF
- Page 1 Pyro MKIII Cast Range DEDICATED EXTERNAL AIR SUPPLY KIT USER INSTRUCTIONS AND INSTALLATION MKIII 750 GF MKIII 750 GF2L MKIII 750 GF2LR MKIII 750 GF3 Version 1 26/12/23 Contents of manual may be updated without notice. For the latest version of this manual please refer...
- Page 2 TABLE OF CONTENTS General and Installation requirements Installation and Comissioning Dedicated External Air Supply Kit ATTENTION: Your wood heater must be installed by a qualified person whose work conforms with local council regulations, Australian standards & manufacturers recommendations. Failure to do so will void your warranty and could possibly void any home insurance.
- Page 3 GENRAL AND INSTALLATION REQUIREMENTS GENRAL INFORMATION Dedicated External Air SupplyKit (DEASK) A fixed ducted air supply may be used as an alternative to the traditional method of using a permanent open vent into a room to supply air for combustion. This gives increased comfort and efficiency by cutting down the number of air changes in the room.
-
Page 4: Installation And Comissioning
INSTALLATION AND COMISSIONING INSTALLATION The ducting should be run in non-combustible, semi-rigid material - normally spirally wound aluminium. Bends should be kept to a minimum and there must be no more than five 90° bends in the duct with a maximum length of 5m. The ducting must be permanently open, with no valves or dampers fitted. - Page 5 DEDICATED EXTERNAL AIR SUPPLY KIT Pyro Cast Range...
- Page 6 Distributed By: PAD Fires Please contact your authorised dealer...
