ORIGINAL INSTRUCTIONS

IMPORTANT - These instructions are for your safety.

Please read through them thoroughly prior to handling

the product and retain them for future reference.

V20724_BX220IM

MNL_Erbauer_2x36V Chain Saw_V02_240712.indd 1

EN Cordless Chain Saw

2x36V 35cm / 40cm

ERT1039CHN

5059340904856

(UK)

5059340904672

(EU)

ERT1040CHN

5059340904818

(UK)

5059340904511

(EU)

7/12/24 3:14 PM

Table of Contents

Need help?

Do you have a question about the ERT1039CHN and is the answer not in the manual?

Questions and answers

Summary of Contents for Erbauer ERT1039CHN

Page 1 EN Cordless Chain Saw 2x36V 35cm / 40cm ERT1039CHN 5059340904856 (UK) 5059340904672 (EU) ERT1040CHN ORIGINAL INSTRUCTIONS IMPORTANT - These instructions are for your safety. 5059340904818 Please read through them thoroughly prior to handling (UK) the product and retain them for future reference.
Page 2: Table Of Contents
EN Parts 01. x1 02. x1 03. x1 04. x1 EN You will need EN Contents Product description Safety information Technical specifications Before you start Assembly Functions & Settings Operation Care and maintenance Troubleshooting Guarantee Customer care and technical helpline Declaration of conformity MNL_Erbauer_2x36V Chain Saw_V02_240712.indd 2 7/12/24 3:14 PM...
Page 3: Product Description
EN Product description 1. Rear handle b. Lubrication hole 16. Rear safeguard 2. Front handle c. Turning wheel* 17. Battery docking port (x2) 3. Front safeguard (chain brake 10. Chain tension wheel 18. Oil level window lever) 11. Locking wheel 19.
Page 4: Safety Information
NOTE: Parts marked with * are not shown in this overview. Please refer to the respective part in the instruction manual. EN Safety information General machine safety warning WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this machine.
Page 5: Personal Safety
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. c) Do not expose machines to rain or wet conditions. Water entering a machine will increase the risk of electric shock.
Page 6 Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
Page 7 g) Use the machine, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the machine for operations different from those intended could result in a hazardous situation.
Page 8 6) Service a) Have your machines serviced by a qualified repair person using only identical replacement parts. This will ensure that safety of the machine is maintained. b) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.
Page 9 h) Use extreme caution when cutting brush and saplings. The slender material may catch the saw chain and be whipped toward you or pull you off balance. Carry the chain saw by the front handle with the chain saw switched off and away from your body. When transporting or storing the chain saw, always fit the guide bar cover.
Page 10 Kickback is the result of chain saw misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below: a) Maintain a firm grip, with thumbs and fingers encircling the chain saw handles, with both hands on the saw and position your body and arm to allow you to resist kickback forces.
Page 11 Additional safety warnings for battery pack a) Battery pack needs to be charged before use. Always refer to the charger’s instruction and charge it properly. b) Remove the battery pack from the product when not in use. c) Don’t maintain the battery pack on the charger when not in use.
Page 12: Vibration And Noise Reduction
VIBRATION AND NOISE REDUCTION To reduce the impact of noise and vibration emission, limit the time of operation, use low-vibration and low-noise operating modes as well as wear personal protective equipment. Take the following points into account to minimise the vibration and noise exposure risks: a) Only use the product as intended by its design and these instructions.
Page 13: Residual Risks
RESIDUAL RISKS Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product: a) Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained.
Page 14 Always wear ear protection. Always wear eye protection. Wear a dust mask. Wear protective gloves. Wear face shield. Wear protective, slip-resistant footwear. Wear head protection, where there is a risk of falling objects. Wear tight-fitted protective clothes. Use appropriate protection for foot-leg and hand-arm. Switch the product off and remove battery pack before assembly, cleaning, adjustments, maintenance, storage and transportation.
Page 15: Technical Specifications
The product complies with the applicable European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed. Rating label explanation ERT1039CHN = Model number ERT1040CHN = Model number ERT = Erbauer (brand) ERT = Erbauer (brand)
Page 16 , 12 A > Ambient temperature range for machine charger and battery use : 5 - 40ºC NOTE: This equipment is compatible with the Erbauer EXT 18V/36V dual-voltage lithium-ion battery range. For optimal performance, use 2 x 4.0Ah batteries for 72V tools.
Page 17: Before You Start
EN Before you start Unpacking 1. Unpack all parts and lay them on a flat, stable surface. 2. Remove all packing materials and shipping devices if applicable. 3. Make sure the delivery contents are complete and free of any damage. If you find that parts are missing or show damage do not use the product but contact your dealer.
Page 18 WARNING! Always use a saw chain designed as “low-kickback” or a saw chain which meets the low-kickback requirements! A standard saw chain (a chain which does not have the kickback reducing guard links) should only be used by an experienced professional operator. Nevertheless, a low-kickback saw chain does not completely eliminate kickback! A low-kickback or “safety”...
Page 19: Saw Chain Tensioning
Fig. 3 Fig. 4 8. Align and place the chain saw cover (12) over the mounting bolt (6); Flip the locking ring (11a) up and hold it, then slightly tighten the locking wheel (11) clockwise (Fig. 6, steps 1, 2, 3). Ensure that the spigot (12a) engages correctly in the slot.
Page 20: Chain Lubrication
WARNING! Remove the battery packs (21) from the product before adjusting saw chain tension! The cutting edges of the saw chain (8) are sharp! Always wear protective gloves when handling chain! Always maintain proper chain tension! A loose chain increases the risk of kickback! A loose chain may jump out of the guide bar groove! This may injure the operator and damage the chain! A loose chain will cause rapid wear to the chain, guide bar and sprocket!
Page 21 1. Place the product on a stable, level surface with the oil tank cap (13) facing upward. We recommend laying a non-flammable sheet under the product. 2. Flip the locking ring (13a) up and hold it, then unscrew it anticlockwise and remove the oil tank cap (13) (Fig.
Page 22 Fig. 11 Fig. 12 Battery pack (not included) Attaching / releasing the battery pack 1. Align the battery pack (21) with the sliding slots of the battery docking port (17) and slide the battery pack (21) in to attach it. Ensure it clicks in place (Fig. 13). Repeat this step to attach another battery pack (21). 2.
Page 23: Functions & Settings
. It is designed only to be used with the battery pack which is listed in the chapter of “Technical specifications”. The product is intended for cutting logs and limbs with a thickness of max. 35cm (ERT1039CHN) or 40cm (ERT1040CHN).
Page 24: Overload Protection
1. Make sure the chain brake is disengaged. Disengage the chain brake by pulling the front safeguard (chain brake lever) (3) back towards the front handle (2). 2. Place the product on any suitable flat surface, make sure the saw chain (8) is not touching the surface or other objects.
Page 25: General Operation
WARNING! The product will continue to work for some time even after the motor has been switched off! Wait until it comes to a complete stop before you put the product down! EN Operation General operation 1. Check the product, its battery pack and charger as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear.
Page 26 1. To become proficient attend a recognised chain saw training course to learn how to operate chain saws safely and effectively. Familiarise yourself with all the controls and switches. Practise all movements with the product switched off. 2. Always hold the product firmly with both hands; front handle (2) with the left hand and rear handle (1) with the right hand.
Page 27 Kickback may occur when the nose or tip of the guide bar touches an object, or when wood pinches the saw chain in the cut. In some cases, contact with the tip of the guide bar (9) may cause a lightning-fast reverse reaction, kicking the guide bar up and back toward the operator (Fig.
Page 28: Felling A Tree
Felling a tree WARNING! Before commencing work or attempting to fell any tree, check with your Local Council to ensure you have permission! Even in your own garden you may be in a conservation area, the tree you wish to fell may have a conservation order against it or the tree may be visible on the plans of your house –...
Page 29: Limbing And Pruning
Limbing and pruning Limbing is removing the branches from a fallen tree. When limbing leave larger lower limbs to support the log off the ground. Remove the small limbs in one cut (Fig. 28). Branches under tension should be cut from the bottom up to avoid binding the product.
Page 30: After Use
1. Follow the simple directions for easy cutting. When the log is supported along its entire length (Fig. 30), it is cut from the top (overbuck). 2. When the log is supported on one end (Fig. 31), cut 1/3 the diameter from the underside (underbuck).
Page 31: Care And Maintenance
EN Care and maintenance The golden rules for care WARNING! Always switch the product off, remove the battery pack (21) and let the product cool down before performing inspection, maintenance and cleaning work! Only perform care and maintenance work according to these instructions! All further works must be performed by a qualified specialist! 1.
Page 32 saw chain which is too tight, this will contribute to rapid bar wear. To help minimise bar wear, maintenance of the guide bar as well as the saw chain is recommended. 1. Disassemble the guide bar (9) and saw chain (8) in reversed order from assembly.
Page 33 2. The height difference between the tooth and the ridge Left-hand is the cutting depth. When sharpening the saw chain cutter Right-hand (8) you have to consider the following points (Fig. 40). cutter - File angle Bumper tie - Cutting angle strap - File position - Diameter of round file...
Page 34: Troubleshooting
4. Store the product and its accessories in a dark, dry, frost-free, well-ventilated place. 5. Always store the product in a place that is inaccessible to children. The ideal storage temperature is between 10°C and 30°C. 6. We recommend using the original package for storage or covering the chain saw (without battery pack) with a suitable cloth or enclosure to protect it against dust.
Page 35: Recycling And Disposal
5. Excessive vibration 5.1. Saw chain is dull/damaged 5.1. Replace with a new one or noise 5.2. Bolts/nuts are loosen 5.2. Tighten bolts/nuts 5.3. Chain oil is incorrect 5.3. Drain out unused oil and refill with correct oil Recycling and disposal Waste electrical products should not be disposed of with household waste.
Page 36: Guarantee
EN Guarantee At Erbauer we take special care to select high quality materials and use manufacturing techniques that allow us to create ranges of products incorporating design and durability. We carry out stringent testing procedures on all our machines and are confident that the can provide regular, sustained daily use during the period covered.
Page 37: Customer Care And Technical Helpline
EN Customer care and technical helpline A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the guarantee, the Customer Care and Technical Helpline can support with technical assistance or if required, arrange a free courier collection from your home, assess your garden power tool for fault, repair it, and return it.
Page 38: Declaration Of Conformity
EN Declaration of conformity MNL_Erbauer_2x36V Chain Saw_V02_240712.indd 38 7/12/24 3:15 PM...
Page 39 Manufacturer : EN www.diy.com UK Manufacturer : International Products Limited, To view instructio n manuals online, 1 Paddington Square, London, W2 1GG, United Kingdom EU Manufacturer : International Products B.V. Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands MNL_Erbauer_2x36V Chain Saw_V02_240712.indd 39 7/12/24 3:15 PM...
