EN
ORIGINAL INSTRUCTIONS
IMPORTANT - These instructions are for your safety.
Please read through them thoroughly prior to handling
the product and retain them for future reference.
V10624_BX220IM
MNL_ERT1037CHN/ERT1038CHN_36V 30/40cm chain saw_GB_V1_06272024.indd 1
EN Cordless Chain Saw 36V
30cm / 40cm
ERT1037CHN
5059340904931
(UK)
5059340904627
(EU)
ERT1038CHN
5059340904825
(UK)
5059340904603
(EU)
6/27/24 11:24 AM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Erbauer ERT1037CHN
Summary of Contents for Erbauer ERT1037CHN
- Page 1 EN Cordless Chain Saw 36V 30cm / 40cm ERT1037CHN 5059340904931 (UK) 5059340904627 (EU) ERT1038CHN ORIGINAL INSTRUCTIONS IMPORTANT - These instructions are for your safety. 5059340904825 Please read through them thoroughly prior to handling (UK) the product and retain them for future reference.
-
Page 2: Table Of Contents
EN Parts 01. x1 02. x1 03. x1 04. x1 EN You will need EN Contents Product description Safety information Technical specifications Before you start Assembly Functions & Settings Operation Care and maintenance Troubleshooting Guarantee Customer care and technical helpline Declaration of conformity MNL_ERT1037CHN/ERT1038CHN_36V 30/40cm chain saw_GB_V1_06272024.indd 2 6/27/24 11:24 AM... -
Page 3: Product Description
EN Product description 1. Rear handle b. Lubrication hole 16. Rear safeguard 2. Front handle c. Turning wheel* 17. Battery docking port 3. Front safeguard (chain brake 10. Chain tension wheel 18. Oil level window lever) 11. Locking wheel 19. Air vents 4. -
Page 4: Safety Information
NOTE: Parts marked with * are not shown in this overview. Please refer to the respective part in the instruction manual. EN Safety information General machine safety warning WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this machine. -
Page 5: Personal Safety
is an increased risk of electric shock if your body is earthed or grounded. c) Do not expose machines to rain or wet conditions. Water entering a machine will increase the risk of electric shock. d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the machine. - Page 6 Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
- Page 7 g) Use the machine, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the machine for operations different from those intended could result in a hazardous situation.
- Page 8 6) Service a) Have your machines serviced by a qualified repair person using only identical replacement parts. This will ensure that safety of the machine is maintained. b) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.
- Page 9 h) Use extreme caution when cutting brush and saplings. The slender material may catch the saw chain and be whipped toward you or pull you off balance. Carry the chain saw by the front handle with the chain saw switched off and away from your body. When transporting or storing the chain saw, always fit the guide bar cover.
- Page 10 Kickback is the result of chain saw misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below: a) Maintain a firm grip, with thumbs and fingers encircling the chain saw handles, with both hands on the saw and position your body and arm to allow you to resist kickback forces.
- Page 11 Additional safety warnings for battery pack a) Battery pack needs to be charged before use. Always refer to the charger’s instruction and charge it properly. b) Remove the battery pack from the product when not in use. c) Don’t maintain the battery pack on the charger when not in use.
-
Page 12: Vibration And Noise Reduction
VIBRATION AND NOISE REDUCTION To reduce the impact of noise and vibration emission, limit the time of operation, use low-vibration and low-noise operating modes as well as wear personal protective equipment. Take the following points into account to minimise the vibration and noise exposure risks: a) Only use the product as intended by its design and these instructions. -
Page 13: Residual Risks
RESIDUAL RISKS Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product: a) Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained. - Page 14 Always wear ear protection. Always wear eye protection. Wear a dust mask. Wear protective gloves. Wear face shield. Wear protective, slip-resistant footwear. Wear head protection, where there is a risk of falling objects. Wear tight-fitted protective clothes. Use appropriate protection for foot-leg and hand-arm. Switch the product off and remove battery pack before assembly, cleaning, adjustments, maintenance, storage and transportation.
-
Page 15: Technical Specifications
The product complies with the applicable European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed. Rating label explanation ERT1037CHN = Model number ERT1038CHN = Model number ERT = Erbauer (brand) ERT = Erbauer (brand) - Page 16 , 12 A > Ambient temperature range for machine charger and battery use : 5 - 40ºC NOTE: This equipment is compatible with the Erbauer EXT 18V/36V dual-voltage lithium-ion battery range. For optimal performance, use 1 x 4.0Ah battery for 36V tools.
-
Page 17: Before You Start
EN Before you start Unpacking 1. Unpack all parts and lay them on a flat, stable surface. 2. Remove all packing materials and shipping devices if applicable. 3. Make sure the delivery contents are complete and free of any damage. If you find that parts are missing or show damage do not use the product but contact your dealer. - Page 18 WARNING! Always use a saw chain designed as “low-kickback” or a saw chain which meets the low-kickback requirements! A standard saw chain (a chain which does not have the kickback reducing guard links) should only be used by an experienced professional operator. Nevertheless, a low-kickback saw chain does not completely eliminate kickback! A low-kickback or “safety”...
-
Page 19: Saw Chain Tensioning
Fig. 3 Fig. 4 8. Align and place the chain saw cover (12) over the mounting bolt (6); Flip the locking ring (11a) up and hold it, then slightly tighten the locking wheel (11) clockwise (Fig. 6, steps 1, 2, 3). Ensure that the spigot (12a) engages correctly in the slot. - Page 20 WARNING! Remove the battery pack (21) from the product before adjusting saw chain tension! The cutting edges of the saw chain (8) are sharp! Always wear protective gloves when handling chain! Always maintain proper chain tension! A loose chain increases the risk of kickback! A loose chain may jump out of the guide bar groove! This may injure the operator and damage the chain! A loose chain will cause rapid wear to the chain, guide bar and sprocket!
-
Page 21: Chain Lubrication
Chain lubrication WARNING! The product is not filled with chain oil. It is essential to fill the product with chain oil before using it! Never operate the product without chain oil as this will result in extensive damage to the product! Operating the saw chain dry or with too little chain oil will decrease cutting efficiency, shorten the product life span and cause rapid wear to the saw chain and guide bar from overheating! - Page 22 Check the oil level window (18) prior to start-up and regularly during operation. Refill oil when the oil level is close to the bottom of the oil level window (18). Wipe up spilled lubricant with a soft cloth and refit the oil tank cap (13) (Fig. 9, step 3). NOTE: Always dispose of lubricant, used oil and objects contaminated with them in accordance with local regulations.
-
Page 23: Functions & Settings
. It is designed only to be used with the battery pack which is listed in the chapter of “Technical specifications”. The product is intended for cutting logs and limbs with a thickness of max. 26 cm (ERT1037CHN) or 35 cm (ERT1038CHN). -
Page 24: Chain Brake Test
Fig. 16: Disengage the chain brake Fig. 17: Engage the chain brake Chain brake test WARNING! Before operating this product, always check that the chain brake is in perfect working condition! The following function check should be carried out before each use. The purpose of the chain brake testing is to reduce the possibility of injury due to kickback. -
Page 25: Low Voltage Protection
3. Press the lock-off button (14), then squeeze the on/off switch (15) to restart the product. If the product is not switched on, replace / recharge the battery pack and repeat the action. Low voltage protection When the product fails to be switched on; or the product runs intermittently afterward, the battery pack may have been at low voltage level. - Page 26 Basic operating / cutting procedure WARNING! Chainsaws by their very nature are extremely dangerous machines and should be handled with respect! We strongly recommend that before use of this product, you attend a chainsaw training course to familiarise yourself with the maintenance and usage of these products! Thoroughly read this manual and adhere to all safety instructions at all times.
- Page 27 Kickback may occur when the nose or tip of the guide bar touches an object, or when wood pinches the saw chain in the cut. In some cases, contact with the tip of the guide bar (9) may cause a lightning-fast reverse reaction, kicking the guide bar up and back toward the operator (Fig.
-
Page 28: Felling A Tree
Felling a tree WARNING! Before commencing work or attempting to fell any tree, check with your Local Council to ensure you have permission! Even in your own garden you may be in a conservation area, the tree you wish to fell may have a conservation order against it or the tree may be visible on the plans of your house –... -
Page 29: Limbing And Pruning
Limbing and pruning Limbing is removing the branches from a fallen tree. When limbing leave larger lower limbs to support the log off the ground. Remove the small limbs in one cut (Fig. 28). Branches under tension should be cut from the bottom up to avoid binding the product. -
Page 30: Care And Maintenance
Fig. 33 Fig. 34 Fig. 35 After use 1. Switch the product off, remove the battery pack (21) and let it cool down. 2. Attach the guide bar cover (20) to the saw chain (8) if necessary. 3. Check, clean and store the machine as described below. EN Care and maintenance The golden rules for care WARNING! Always switch the product off, remove the battery pack (21) and let... -
Page 31: Maintenance
Maintenance Before and after each use, check the product and accessories (or attachments) for wear and damage. If required, exchange them for new ones as described in this instruction manual. Observe the technical requirements. Sprocket wheel NOTE: It is not necessary to remove the saw chain (8) to lubricate the sprocket wheel (9a). - Page 32 3. Check the drive sprocket (7). If it is worn or damaged due to strain, have it replaced by an authorised service agent or a similarly qualified person. 4. Clear residue from the rails on the guide bar (9) by using a screwdriver, putty knife, wire brush or other similar tool.
- Page 33 5. File at an angle perpendicular to the bar, and at an angle of 25° to the direction of travel (Fig. 41). Sharpening angle 6. File each tooth from the inside towards outside only. 25° File one side of the chain first than turn the saw around Left-hand File and repeat the process.
-
Page 34: Troubleshooting
EN Troubleshooting Suspected malfunctions are often due to causes that the users can fix themselves. Therefore check the product using this section. In most cases the problem can be solved quickly. WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself! Problem... -
Page 35: Guarantee
EN Guarantee At Erbauer we take special care to select high quality materials and use manufacturing techniques that allow us to create ranges of products incorporating design and durability. We carry out stringent testing procedures on all our machines and are confident that the can provide regular, sustained daily use during the period covered. -
Page 36: Customer Care And Technical Helpline
EN Customer care and technical helpline A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the guarantee, the Customer Care and Technical Helpline can support with technical assistance or if required, arrange a free courier collection from your home, assess your garden power tool for fault, repair it, and return it. -
Page 37: Declaration Of Conformity
EN Declaration of conformity MNL_ERT1037CHN/ERT1038CHN_36V 30/40cm chain saw_GB_V1_06272024.indd 37 6/27/24 11:24 AM... - Page 38 Manufacturer : EN www.diy.com UK Manufacturer : International Products Limited, To view instructio n manuals online, 1 Paddington Square, London, W2 1GG, United Kingdom EU Manufacturer : International Products B.V. Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands MNL_ERT1037CHN/ERT1038CHN_36V 30/40cm chain saw_GB_V1_06272024.indd 38 6/27/24 11:24 AM...
