EN
ORIGINAL INSTRUCTIONS
IMPORTANT - These instructions are for your safety.
Please read through them thoroughly prior to handling
the product and retain them for future reference.
V10620_BX220IM
MNL_ERT1036CHN_36V 25cm chain saw_GB_V2_06252024.indd 1
EN Cordless Chain Saw 36V
25cm
ERT1036CHN
5059340904733
(UK)
5059340904573
(EU)
6/27/24 11:50 AM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Erbauer ERT1036CHN
Summary of Contents for Erbauer ERT1036CHN
- Page 1 EN Cordless Chain Saw 36V 25cm ORIGINAL INSTRUCTIONS ERT1036CHN IMPORTANT - These instructions are for your safety. 5059340904733 Please read through them thoroughly prior to handling the product and retain them for future reference. (UK) 5059340904573 V10620_BX220IM (EU) MNL_ERT1036CHN_36V 25cm chain saw_GB_V2_06252024.indd 1...
-
Page 2: Table Of Contents
EN Parts 01. x1 02. x1 03. x1 04. x1 EN You will need EN Contents Product description Safety information Technical specifications Before you start Assembly Functions & Settings Operation Care and maintenance Troubleshooting Guarantee Customer care and technical helpline Declaration of conformity MNL_ERT1036CHN_36V 25cm chain saw_GB_V2_06252024.indd 2 6/27/24 11:50 AM... -
Page 3: Product Description
EN Product description 1 2 3 1. Rear handle 11. Drive sprocket 19. Hanging loop 2. On/off switch 12. Saw chain 20. Oil level window 3. Lock-off button 13. Guide bar 21. Oil tank cap 4. Front handle a. Sprocket wheel a. -
Page 4: Safety Information
NOTE: Parts marked with * are not shown in this overview. Please refer to the respective part in the instruction manual. EN Safety information General machine safety warning WARNING! Read all safety warnings, instruc- tions, illustrations and specifications provided with this machine. Failure to follow all instructions listed below may re- sult in electric shock, fire and/or serious injury. -
Page 5: Personal Safety
is an increased risk of electric shock if your body is earthed or grounded. c) Do not expose machines to rain or wet conditions. Water entering a machine will increase the risk of electric shock. d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the machine. - Page 6 clothes, jewellery or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. h) Do not let familiarity gained from frequent use of machines allow you to become complacent and ignore machine safety principles.
- Page 7 g) Use the machine, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the machine for operations different from those intended could result in a hazardous situation.
- Page 8 6) Service a) Have your machines serviced by a qualified repair person using only identical replacement parts. This will ensure that safety of the machine is maintained. b) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.
- Page 9 h) Use extreme caution when cutting brush and saplings. The slender material may catch the saw chain and be whipped toward you or pull you off balance. Carry the chain saw by the front handle with the chain saw switched off and away from your body. When transporting or storing the chain saw, always fit the guide bar cover.
- Page 10 Kickback is the result of chain saw misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below: a) Maintain a firm grip, with thumbs and fingers encircling the chain saw handles, with both hands on the saw and position your body and arm to allow you to resist kickback forces.
- Page 11 Additional safety warnings for battery pack a) Battery pack needs to be charged before use. Always refer to the charger’s instruction and charge it properly. b) Remove the battery pack from the product when not in use. c) Don’t maintain the battery pack on the charger when not in use.
-
Page 12: Vibration And Noise Reduction
VIBRATION AND NOISE REDUCTION To reduce the impact of noise and vibration emission, limit the time of operation, use low-vibration and low-noise operating modes as well as wear personal protective equipment. Take the following points into account to minimise the vibration and noise exposure risks: a) Only use the product as intended by its design and these instructions. -
Page 13: Residual Risks
RESIDUAL RISKS Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product: a) Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained. - Page 14 This chain-saw is for use by trained tree service operators only. See instruction handbook. Always wear ear protection. Always wear eye protection. Wear a dust mask. Wear protective gloves. Wear face shield. Wear protective, slip-resistant footwear. Wear head protection, where there is a risk of falling objects. Wear tight-fitted protective clothes.
-
Page 15: Technical Specifications
The product complies with the applicable European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed. Rating label explanation ERT1036CHN = Model number ERT = Erbauer (brand) 1036 = Sequential code CHN = Chain Saw... - Page 16 , 12 A > Ambient temperature range for machine charger and battery use : 5 - 40ºC NOTE: This equipment is compatible with the Erbauer EXT 18V/36V dual-voltage lithium-ion battery range. For optimal performance, use 1 x 4.0Ah battery for 36V tools.
-
Page 17: Before You Start
EN Before you start Unpacking 1. Unpack all parts and lay them on a flat, stable surface. 2. Remove all packing materials and shipping devices if applicable. 3. Make sure the delivery contents are complete and free of any damage. If you find that parts are missing or show damage do not use the product but contact your dealer. - Page 18 WARNING! Always use a saw chain designed as “low-kickback” or a saw chain which meets the low-kickback requirements! A standard saw chain (a chain which does not have the kickback reducing guard links) should only be used by an experienced professional operator. Nevertheless, a low-kickback saw chain does not completely eliminate kickback! A low-kickback or “safety”...
-
Page 19: Saw Chain Tensioning
Fig. 3 Fig. 4 8. Screw the tension screw (8) clockwise to adjust the tension pin (9) / guide bar (13) towards the right to tighten the saw chain (12) with a suitable screwdriver (Fig. 5, steps 1, 2). 9. Align and place the chain saw cover (15) over the mounting bolt (10). Refit the chain saw cover (15) and slightly tighten the locking wheel (14) clockwise (Fig. -
Page 20: Chain Lubrication
WARNING! Remove the battery pack (23) from the product before adjusting saw chain tension! The cutting edges of the saw chain (12) are sharp! Always wear protective gloves when handling chain! Always maintain proper chain tension! A loose chain increases the risk of kickback! A loose chain may jump out of the guide bar groove! This may injure the operator and damage the chain! A loose chain will cause rapid wear to the chain, guide bar and sprocket! - Page 21 1. Place the product on a stable, level surface with the oil tank cap (21) facing upward. We recommend laying a non-flammable sheet under the product. 2. Lift the locking ring (21a) and hold it, then unscrew it anticlockwise and remove the oil tank cap (21) (Fig. 9, steps 1, 2).
-
Page 22: Functions & Settings
EN Functions & Settings Intended use This cordless chain saw ERT1036CHN is designated with a rated voltage of 36 V . It is designed only to be used with the battery pack which is listed in the chapter of “Technical specifications”. -
Page 23: Chain Brake
However, when following the instructions within section 'Working with tree service chain-saws from rope and harness'. This must only be conducted by a trained professional. Chain brake The chain brake is a safety mechanism activated by the front safeguard (chain brake lever) (5). When kickback occurs the chain stops immediately. -
Page 24: Overload Protection
WARNING! The motor will not start if the chain brake is in the engaged position. WARNING! If the saw chain (12) and motor fail to stop when the chain brake is engaged, take the product to the nearest authorised service centre or a similarly qualified person! Do not use the product if the chain brake is not in working properly! The chain brake should not be used for starting and stopping the product during... -
Page 25: General Operation
EN Operation General operation 1. Check the product, its battery pack and charger as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. Take care of any problem you find or have the product checked by qualified specialist. - Page 26 1. To become proficient attend a recognised chain saw training course to learn how to operate chain saws safely and effectively. Familiarise yourself with all the controls and switches. Practise all movements with the product switched off. 2. Always hold the product firmly with both hands; front handle (4) with the left hand and rear handle (1) with the right hand.
- Page 27 Kickback may occur when the nose or tip of the guide bar touches an object, or when wood pinches the saw chain in the cut. In some cases, contact with the tip of the guide bar (13) may cause a lightning-fast reverse reaction, kicking the guide bar up and back toward the operator (Fig.
-
Page 28: Felling A Tree
Felling a tree WARNING! Before commencing work or attempting to fell any tree, check with your Local Council to ensure you have permission! Even in your own garden you may be in a conservation area, the tree you wish to fell may have a conservation order against it or the tree may be visible on the plans of your house –... -
Page 29: Limbing And Pruning
Limbing and pruning Limbing is removing the branches from a fallen tree. When limbing leave larger lower limbs to support the log off the ground. Remove the small limbs in one cut (Fig. 28). Branches under tension should be cut from the bottom up to avoid binding the product. -
Page 30: Working With Tree Service Chain-Saws From Rope And Harness
1. Follow the simple directions for easy cutting. When the log is supported along its entire length (Fig. 30), it is cut from the top (overbuck). 2. When the log is supported on one end (Fig. 31), cut 1/3 the diameter from the underside (underbuck). - Page 31 2. preparations for using a tree service chain saw from a rope and harness, and 3. use of a tree service chain saw for pruning and dismantling, including secure work positioning for two- handed use, starting the chain saw, cutting with the chain saw, restrictions on one-handed use and freeing a trapped saw.
- Page 32 1. hip level, when cutting horizontal sections, and 2. solar-plexus level, when cutting vertical sections. Where the operator is working close into vertical stems with low lateral forces on the work position, secure footing could be all that is needed for maintaining a secure work position. However, as operators move away from the stem, they will need to take measures to remove or counteract increasing lateral forces by, for example, redirecting the main line via a supplementary anchor point or using an adjustable strop direct from the harness to a supplementary anchor point (Fig.
-
Page 33: After Use
2. pull the saw from the kerf while lifting the branch as necessary, and 3. if necessary, use a handsaw or second chain saw to release the trapped saw by cutting a minimum of 30 cm away from the trapped saw. Whether a handsaw or a chain-saw is used to free a trapped saw, the release cuts should always be outboard (toward the tips of the branch), in order to prevent the saw being taken with the section and further complicating the situation. - Page 34 Sprocket wheel NOTE: It is not necessary to remove the saw chain (12) to lubricate the sprocket wheel (13a). Lubrication can be done on the job. 1. Clean the sprocket wheel (13a). 2. Using a disposable lube gun, insert the needle nose into the lubrication hole (13b) (Fig.
- Page 35 6. Turn the guide bar 180° to allow even wear, thereby extending the life span of the guide bar (13). 7. Check the saw chain for possible wear and damages. Replace it with a new one if required. Experienced user can sharpen a dull saw chain (see section “Saw chain sharpening” below). 8.
-
Page 36: Troubleshooting
Cutting tip File position Top plate Cutter length Depth gauge setting 0.025” Depth gauge Fig. 47 Spare parts / Replacement parts Spare parts are available at an authorised dealer or through our customer service. Repair This product does not contain any parts that can be repaired by the consumer. Contact an authorised service centre or a similarly qualified person to have it checked and repaired. -
Page 37: Recycling And Disposal
Problem Possible cause Solution 1. Product does not 1.1. Battery pack is not properly 1.1. Attach properly start attached 1.2. Battery pack is discharged 1.2. Remove and charge battery pack 1.3. Battery pack is hot 1.3. Remove and let it cool 1.4. -
Page 38: Guarantee
EN Guarantee At Erbauer we take special care to select high quality materials and use manufacturing techniques that allow us to create ranges of products incorporating design and durability. We carry out stringent testing procedures on all our machines and are confident that the can provide regular, sustained daily use during the period covered. -
Page 39: Customer Care And Technical Helpline
EN Customer care and technical helpline A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the guarantee, the Customer Care and Technical Helpline can support with technical assistance or if required, arrange a free courier collection from your home, assess your garden power tool for fault, repair it, and return it. -
Page 40: Declaration Of Conformity
EN Declaration of conformity MNL_ERT1036CHN_36V 25cm chain saw_GB_V2_06252024.indd 40 6/27/24 11:51 AM... - Page 41 Manufacturer : EN www.diy.com UK Manufacturer : International Products Limited, To view instructio n manuals online, 1 Paddington Square, London, W2 1GG, United Kingdom EU Manufacturer : International Products B.V. Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands MNL_ERT1036CHN_36V 25cm chain saw_GB_V2_06252024.indd 41 6/27/24 11:51 AM...
