- Page 1 FM-120KS-HC SELF-CONTAINED ICE MAKER FM-120KS-HCN FM-120KS-50-HC FM-120KS-50-HCN CM-110KS-HC CM-100KS-50-HC INSTRUCTION MANUAL (original instructions) FOR END USER No.15 Qingqiu Street,Suzhou Industrial Park,Suzhou,215126 China L1F300101(061025)
-
Page 2: Table Of Contents
IMPORTANT SAFETY INFORMATION ............................1 I. INSTALLATION INSTRUCTIONS ............................3 1. CONSTRUCTION ................................3 2. ACCESSORIES .................................. 3 3. LOCATION ..................................4 4. ELECTRICAL CONNECTIONS ............................4 5. WATER SUPPLY AND DRAIN CONNECTIONS ........................ 5 II. OPERATING INSTRUCTIONS ..............................5 1. -
Page 3: Important Safety Information
ENGLISH IMPORTANT SAFETY INFORMATION Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. Indicates a hazardous situation which, if not avoided, could result in death or WARNING serious injury. - Page 4 * If the supply cord is damaged, it must be replaced by a replacement cord available from Hoshizaki Parts/Service Centres. * Do not touch the electrical parts or operate the switches with damp hands. * This appliance is not intended for use by persons (including children) with reduced physical,...
-
Page 5: Installation Instructions
Top Panel Storage Bin Operation Panel Front Panel (Left) Door Louver Air Filter Front Cover 2. ACCESSORIES FM-120KS- FM-120KS- CM-110KS-50- FM-120KS-HC FM-120KS-HCN CM-110KS-HC 50-HC 50-HCN SCOOP INLET HOSE OUTLET HOSE COVER - CONNECTOR POWER CORD SCOOP INLET HOSE OUTLET HOSE... -
Page 6: Location
ENGLISH 3. LOCATION WARNING This icemaker is not intended for outdoor use. The icemaker should not be located next to ovens, grills or other high heat producing equipment. This appliance is not suitable for installation in an area where a water jet could be used. CAUTION The location should provide a firm and level foundation for the icemaker. -
Page 7: Water Supply And Drain Connections
* Icemaking water must be potable water. Where scaling can be caused by water quality, installation of an external filter or softener is recommended. Contact your local water treatment professional or Hoshizaki service agent. * A plumbing permit and services of a licensed plumber may be required in some areas. -
Page 8: Start Up
ENGLISH 1. START UP The installer will normally commission the icemaker to start the automatic icemaking process. To ensure continuous operation, make sure that: * The water supply tap is on, and * The icemaker is connected to the power supply. To start the icemaking process, check the position of the operation switch on the operation panel: “OFF”... - Page 9 5) Either mix 5 litres of water with 18 ml of 5.25% sodium hypochlorite solution in a suitable container, or the recommended Hoshizaki sanitiser as directed. 6) Soak a clean sponge or cloth with the solution, and wipe the bin liner surfaces, slope and drain cap.
-
Page 10: Inspection And Maintenance
Once the unit shuts down after 500 hours, the operation can be resumed by turning off the operation switch and turning it back on. But the unit shuts down again after 500 hours. To resume the operation, contact your local Hoshizaki service agent for the required replacement. -
Page 11: Before Calling For Service
If the icemaker does not work properly or does not work at all and no error code is indicated on the display, before calling for service, check that: * The power is supplied to the unit. * The water is turned on. * The air filter is clean. For further assistance or advice, contact your local Hoshizaki service agent. -
Page 12: Disposal
5. WARRANTY Hoshizaki warrants to the original owner/user that all Hoshizaki branded products shall be free of defects in material and/or workmanship for the duration of the “warranty period”. The warranty shall be effective for two years from the date of installation. -
Page 13: Specifications
ENGLISH SPECIFICATIONS Model FM-120KS-HC FM-120KS-HCN Type Air-cooled, flake ice Air-cooled, nugget ice Power Supply 1 phase 220-240V 50Hz 1 phase 220-240V 50Hz Electric Consumption 353W 353W Ice Production per 24h 137kg 118kg (ambient 10°C, water 10°C) (ambient 10°C, water 10°C) - Page 14 ENGLISH SPECIFICATIONS Model FM-120KS-HC FM-120KS-HCN Type Air-cooled, flake ice Air-cooled, nugget ice Power Supply 1 phase 220V 60Hz 1 phase 220V 60Hz Electric Consumption 335W 335W Ice Production per 24h 138kg 124kg (ambient 10°C, water 10°C) (ambient 10°C, water 10°C)
- Page 15 ENGLISH Model CM-110KS-HC CM-110KS-50-HC Type Air-cooled, cubelet ice Air-cooled, cubelet ice Power Supply 1 phase 220V 60Hz 1 phase 220V 60Hz Electric Consumption 335W 335W Ice Production per 24h 121kg 121kg (ambient 10°C, water 10°C) (ambient 10°C, water 10°C) Dimensions 640mm(W) x 600mm(D) x 800(798-833) 940mm(W) x 600mm(D) x 800(798-833) mm(H)
