- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. ASKO D5122XLS Owner's Manual Shop genuine replacement parts for ASKO D5122XLS Find Your ASKO Dishwasher Parts - Select From 210 Models -------- Manual continues below part list --------...
- Page 2 Available Replacement Parts for ASKO D5122XLS 428814 SPACERS...
- Page 3 These are the hallmarks for all of our products and this is why they are so highly appreciated all over the world. To get the most out of your new ASKO product, we recommend that you read the installation and operating instructions before using the machine.
-
Page 4: Table Of Contents
Contents Before doing your first wash Fragile dishes Cleaning Important safety instructions Coarse filter Fine filter Child safety Drain pump Spray arms Parts of the dishwasher* Door Rinse aid Technical data Fault indications Baskets* Troubleshooting Control panel The dishes are not clean Stains or a film on the china Detergent Dispenser The china has a whitish-blue sticky film 23... -
Page 5: Before Doing Your First Wash
Before doing your first wash Read through the directions for use Read through the directions for use before starting to use your machine, especially the Safety, Child Safety, and Basic Course sec- tions. Take care with certain materials Read the Fragile Dishes section before washing china with unglazed decoration or other household goods made of plastic, wood, or crystal requiring careful treatment. -
Page 6: Important Safety Instructions
Important safety instructions This manual does not cover all possible • When removing an old dishwasher from service or discarding it, remove the door conditions and situations that may occur. to the washing compartment. Common sense and caution should always •... -
Page 7: Child Safety
Child safety Child safety tips Engaging the Child Safety Lock Dishwasher detergents and rinse aids are This model has a child safety lock on the left of corrosive, so always keep them out of reach the door handle. To activate the lock, press in of children. -
Page 8: Parts Of The Dishwasher
Parts of the dishwasher* 1. Upper basket 2. Spray arms 3. Cutlery basket 4. Lower basket 5. Dishwasher detergent compartment 6. Main power switch 7. Rinse Aid Compartment 8. Filter 9. Serial tag and rating plate *Details may differ depending on the model and market! Technical data Height... -
Page 9: Baskets
Baskets* 1. Wine glass shelf Upper basket 2. Cup rack 3. Knife stop 4. Cutlery basket with door and folding handle Lower basket Cutlery basket *Details may differ depending on the model and market! Customer Care Center 1-800-898-1879 www.askousa.com... -
Page 10: Control Panel
Control panel P R O G R A M P R O G R A M S T A R T S T A R T S T O P S T O P 1. Program selector 5. Rinse & Hold 2. -
Page 11: Basic Course
Basic Course Below are step-by-step instructions to help you The cutlery basket has a folding flap in the achieve the best possible dishwashing results. middle for small items or narrow shafts, such as electric whisks. Load the baskets correctly! Thanks to Self Cleaning System, you Place long cutlery and carving knives in the do not need to rinse the dishes under special knife box (if present) or in the upper... -
Page 12: Switch On The Main Switch
Twelve grains and higher is extremely hard Dishwasher tablets water and detergent alone may not be Halve the tablet if it is difficult to close the enough. You may need to use a water soft- dispenser cover. There is a risk that the ener to maximize the performance of your dishwasher detergent will not break down dishwasher. -
Page 13: Press Start
Press start Standby mode The dishwasher will now start. It man- Once the machine has finished, it is drawing ages the entire wash automatically. Ensure a very small amount of power. Disconnect that the door is properly closed or the ma- the power by switch off at the main switch. -
Page 14: Programs
Programs Select a program by pressing the program selector one or more times until the required program symbol lights up. See the Program guide below. Heavy wash The Heavy Wash program should be used for heavily soiled dishes, e.g. saucepans, pots and gratin dishes. -
Page 15: Program Description
Program Description Programview Programs Heavy Normal Quick Rinse & Hold Program For heavily For nor- For lightly To rinse info soiled loads, mally soiled soiled loads dishes that such as pots, loads such that are you plan to pans, casse- as plates, washed wash later... -
Page 16: Options
Options Select options To select an option, press one of the option buttons. Temperature selection * * With the temperature option but- ton you can select the wash temperature yourself. You can vary the temperatures as follows: Normal Economy Heavy: 160°F (70°C) 130°F (55°C) Normal: 150°F (65°C) 130°F (55°C) -
Page 17: Eco-Dishwashing
Eco-dishwashing Only wash full loads Waiting to run the wash until the machine is full saves energy. Wash at a lower temperature If the dishes are only lightly soiled you can run a Quick wash program and reduce the temperature to 86°F (30°C). Select a program with Economy dry To save energy, select Economy dry. -
Page 18: Fragile Dishes
Fragile dishes A number of household goods are not suit- Plastic able for machine washing. This can be due Certain types of plastic cannot withstand to a variety of reasons. Certain materials the high temperature generated in machine cannot withstand intense heat; others can dishwashing. -
Page 19: Cleaning
Cleaning The dishwasher’s inner container is made of Spray arm stainless steel and is kept clean through nor- mal use. However, if you have calciferous (hard) water, lime deposits can form in the dishwasher. In this case, run a normal wash program with two tablespoons of citric acid in the dishwasher detergent compartment. -
Page 20: Drain Pump
2. Lift the coarse filter and the pipe section straight up by the handle. 3. Remove the fine filter. 4. Clean the fine filter and the pipe section with a washing-up brush. Replace in reverse order. Make sure the edges seal properly when replacing the fine filter. -
Page 21: Spray Arms
If you still cannot start the machine and a humming noise can be heard, then the over- filling protection has been activated. • Shutoff the water • Remove the plug from the wall socket • Call Service CAUTION! Do not forget to replace the small pump ac- cess plug. -
Page 22: Rinse Aid
Rinse aid Select dosage Adding rinse aid The dispenser is usually set at 1= soft water. In some cases, drying can be made more ef- However, depending on the water hardness, ficient by using rinse aid. you may need to change the dosage. To fill with rinse aid: Open the rinse aid cover. -
Page 23: Fault Indications
Fault indications Indication Type of fault Action L2 flashing Too much water in the dishwasher Phone service P R O G R A M P R O G R A M S T A R T S T A R T S T O P S T O P Customer Care Center... -
Page 24: Troubleshooting
Troubleshooting Problems Possible causes Action • Lift off the arms and clean. The dishes are not clean • The spray arms are not rotating. • Avoid large packs. • Old dishwasher detergent. NB! Detergent is a perishable. • Dispense according to the •... -
Page 25: The China Has A Whitish-Blue Sticky Film
Problems Possible causes Action • Reduce dosage. See the The china has a whitish- • Too high dosage of rinse chapter on rinse aid. If the blue sticky film aid. water is very soft, you could try diluting the rinse aid (1 part rinse aid, 1 part water). -
Page 26: Water Remains In The Machine
Problems Possible causes Action Water remains in the • Disconnect the drain hose • Obstruction in the drain machine where it is connected to the hose. sink’s water trap. Check that no debris has become stuck. Is the cone-shaped part of the pipe cut so that the diam- eter is at least 16 mm? •... -
Page 27: Performance Information
Performance information Energy standard USA: ANSI/AHAM DW-1-2005 Technical data Height: 34-3/8” - 36-1/2” 874-927mm Width: 24” (610mm) Depth: 24” (610mm) Weight: 105.8 lbs (48 kg)* Water pressure 4.2 - 140 0.03 - 1.0 MPa 0.3-10(Bar) Electrical connection: See serial tag/rating plate Rated power: See serial tag/rating plate *The weight can vary due to varying specifications. -
Page 28: Service And Guarantee
• Repair damage due to shipment, deliv- United States. ery, installation, misuse or abuse. 6. Pickup and delivery. ASKO washers are • Instruct how to use the appliance. designed to be repaired in the home. • Replace house fuses or correct house wiring. - Page 29 ASKO service agent. For warranty service, contact our Customer Care Center at the number listed below. Before calling for service or contacting Asko Appliances Inc. regarding a warranty issue, make a note of the model, type name, and serial number.
-
Page 30: Quick Guide
Quick Guide 1. Load the baskets correctly! Thanks to the Self Cleaning System you don’t need to rinse the dishes, simply scrape large food particles and debris. 2. Dispensing dishwasher detergent The detergent compartment has a small compartment for pre-wash and one for main wash. 3.
