TWL 4 Regulation Use The temperature sensors of series TWL are suitable for all applications where processes involving fluids, solid bodies or materials, or gases, require temperature recording and measurement. Our temperature sensors are suitable for use in the following industrial areas: chemicals, petrochemicals, water, feed, food, sanitary, etc.
5 Operating Principle Resistance thermometers work by using the continuous change of resistance of metals subject to temperature rising and decreasing. The most common resistance material used is platinum, as it is very stable and has very good repeatability. The temperature coefficient of platinum is positive, so its resistance increases as the temperature rises.
This measuring principle acts to check and measure the temperature also in explosion-proof areas. TWL devices can be with a standard 4 to 20 mA signal transmitter, Hart protocol, Profibus/Fieldbus or with direct access to the sensor. They are appropriate for use in Group IIC and Categories 2G/D explosion-proof atmospheres.
- Do not install the device near material airflows or near steam outlets 7.5 Maintenance and repairs The instrument does not require maintenance or servicing. Repairs must be only carried out by Kobold Mesura (manufacturer) 7.6 Storage Measuring instruments should be protected against humidity and dust.
8 Description of the Factory Label Installation in the classified area Examples of installation in explosion-proof areas conform to the protection type “Ex d” DT0454 page 9...
9 Installation in the classified area 9.1 Examples of installation in explosion-proof areas conform to the protection type “Ex d” Hazardous area Safe area page 10 DT0454...
10 Technical Details 10.1 Sensor wiring - 2 wires Error due to the lead resistance of the sensor - 3 wires With connecting wires up to 25 m, lead resistance is negligible. - 4 wires The lead resistance of the connecting wires is negligible Sensor according to IEC 60751 -Class B -Class A...
9…32 Vdc for transmitter with PROFIBUS ® /Fieldbus Note For programming of transmitter please refer to their separate programming manual. Sensors model TWL-SN and TWL-SA have not head transmitter, you must use remote transmitter. Transmitter 5333D Ambient temperature: -40...+85 ºC Power supply: 8...35 V...
11 Dimensions 11.1 Sensors Dimensions Temperature Sensor TWL-1 Dimensions Temperature Sensor TWL-2 HL: Neckpipe length 130 mm TWL-1 (other on request) U: Immersion length thermowell (see drawing thermowell) 150 mm TWL-2 (other on request) H: Length thermowell (see drawing thermowell) LN: Screw-in-length by hand (approx.
11.2 Thermowells Dimensions Thermowell Model TWL-…B… Nominal pressure: max. PN25 at 20ºC Cylindrical thermowell, welded with process connection G-thread Process Max. Total Connection length G ½ B G-thread 5000 mm G ¾ B 31.7 G 1 B Nominal pressure: max. PN25 at 20ºC...
Page 16
DIN DN 25 10/12 12/14 DIN DN 32 DIN DN 40 DIN DN 50 Dimensions Thermowell Model TWL-…G… Nominal pressure: max.PN100 at 20ºC Cylindrical thermowell out of solid material with stepped shaft and process connection G-thread Process Max. Total Connection...
Page 17
Nominal pressure: max. PN100 at 20ºC Cylindrical thermowell out of solid material with stepped shaft and process connection NPT-thread Process Max. Total Connection Length 7-8-9 17.5 ½ NPT 10-12 17,5 17,5 7-8-9 NPT-thread 1000mm ¾ NPT 10-12 7-8-9 1 NPT 10-12 Nominal pressure: as flange rating ( max.
Page 18
DN ¾” 26,9 10-12 For weld-on 1000 7-8-9 DN 1” 33.4 10-12 Dimensions Thermowell Model TWL-…D… Nominal pressure: PN250 at 20ºC Conical thermowell out of solid material with process connection G-thread Process Max. Total Connection Length 7-8-9 G ¾ B 31.7...
Page 19
Nominal pressure: PN250 at 20ºC Conical thermowell out of solid material with process connection NPT-thread Process Max. Total Connection Length 7-8-9 ¾ NPT 10-12 NPT-thread 1000mm 7-8-9 1 NPT 10-12 Nominal pressure: as flange rating (max. PN250 at 20ºC) Conical thermowell out of solid material with process connection flange acc, DIN or ANSI Process Max.
Page 20
Conical thermowell out of solid material with process connection flange acc. DIN or ANSI Process Max. Total Connection Length 7-8-9 DN 1” 33.4 10-12 For weld-on 1000mm 7-8-9 DN 1 ¼” 38.1 10-12 page 20 DT0454...
11.3 Lagging extension at thermowell “T”. In case of ordering with lagging extension at thermowell please see drawing and specify length “T” (total length is “T”+”H”). “H” is fix. DT0454 page 21...
12 Order details Order Details (example: TWL-113LGBG4AA0) Sensor specification Model Sensor type Sensor type/cat. Sensor wiring Connection head/transmitter Sensor connection 0 = without 0 = without 0 = without 0 = without 1= 1 x Pt100 cat B -30…+550ºC 2= 2 x Pt100 cat B -30…+550ºC...
Page 23
“U“ and hole dia. “i“ (when ordering a/with thermowell) or “EL“ (when ordering without thermowell), neckpipe length “HL“ (when different from stdd. i.e. for TWL-1 stdd. Is 130 mm, for TWL-2 standard is150 mm), lagging extension “T“ (when ordering) and measuring insert length “ML“ (when ordering TWL-3) must be specified in clear text when ordering.
Certificazione per esame di tipo CE Marcatura LOM 08ATEX2016 X II 2 GD Exd IIC T6 / Ex tD A21 IP65 T85 ºC Fabricado en KOBOLD MESURA SLU Avda. Conflent 68 nave 15 08915 BADALONA (Spain) Made in: Hergesteltlt in: Fabriqué dans: Fabbricato in:...
The standard delivery includes: Device model: TWL 4. Regulation Use The temperature sensors of series TWL are suitable for all applications where processes involving fluids, solid bodies or materials, or gases, require temperature recording and measurement. Our temperature sensors are suitable for use in the following industrial areas: chemicals, petrochemicals, water, feed, food, sanitary, etc.
5. Operating Principle Resistance thermometers work by using the continuous change of resistance of metals subject to temperature rising and decreasing. The most common resistance material used is platinum, as it is very stable and has very good repeatability. The temperature coefficient of platinum is positive, so its resistance increases as the temperature rises.
Page 35
Sensor wiring diagram without head 2 wire 3 wire 4 wire DT0390 page 5...
6.1 Head model D wiring diagram With transmitter 5333D With transmitter 5337D 6.2 Head model R wiring diagram With transmitter 5333D With transmitter 5337D Note: For electrical connection of transmitter please refer to their separate manual. DT0390 page 7...
This measuring principle acts to check and measure the temperature also in Ex areas. TWL devices can be with a standard 4 to 20 mA signal transmitter, protocol Hart, Profibus/Fieldbus or with direct access to the sensor. They are appropriate for use in Group IIC and Categories 1G/D Atex atmospheres.
- Do not install the device near material airflows or near steam outlets 7.5 Maintenance and repairs The instrument does not require maintenance or servicing. Repairs must be only carried out by Kobold Mesura (manufacturer) 7.6 Storage Measuring instruments should be protected against humidity and dust.
9. Installation in the classified area Examples of installation in explosion-proof areas conform to the protection type “intrinsically safe”: “Ex ia” Hazardous area Safe area DT0390 page 11...
( other on request ) Operating pressure: Max. 30 bar (depending on model, see order details) Connection head: Form G with chain. Aluminium or polycarbonate head on model TWL-T Without head on models TWL-S, TWL-N, TWL-T, TWL-I and TWL-P Materials Sensor: Stainless steel 1.4404 (others on request)
Page 43
9…32 Vdc for transmitter with PROFIBUS /Fieldbus Note For programming of transmitter please refer to their separate programming manual. Sensors model TWL-SN and TWL-SA have not head transmitter, you must use remote transmitter. Transmitter 5333D Ambient temperature: -40...+85 ºC Power supply: 8...35 V...
Page 44
Max. Voltage 60 Vp Max. Load current 75 mA Note For programming of transmitter please refer to their separate programming manual. Sensors model model TWL-S, TWL-N, TWL-I and TWL-P have not head transmitter, you must use remote transmitter. page 14 DT0390...
11. Trouble Shooting Faults Possible Causes Corrective actions No signal/line breakage Mechanical load too high or Replace probe or measuring over temperature. insert. Line breakage. Check wiring. Wrong measured values Sensor drift caused by over Replace probe or measuring temperature insert.
Residual media in dismounted instruments can result in a risk to persons, the environment and equipment. Take sufficient precautionary measures. All instruments delivered to KOBOLD must be free from any kind of hazardous substances (acids, bleaches, solutions, etc.). 12.2 Disposal Incorrect disposal may endanger the environment 13.
LOM 08ATEX2015 X Ex II 1GD Ex ia IIC T4…T6 Ex iaD 20 IP65 T85ºC -20ºC ≤ Ta ≤ +60ºC Fabricado en KOBOLD MESURA SLU Avda. Conflent 68, nave 15 08915 BADALONA (Spain Made in: Hergesteltlt in: Fabriqué dans: Fabbricato in:...
If you need an instruction manual that correspond to the purchased product version, you can request it from us free of charge by email (info.de@kobold.com) in PDF format, specifying the relevant invoice number and serial number. If you wish, the operating instructions can also be sent to you by post in paper form against an applicable postage fee.
Display 5. Technical data and wiring display mod. LPI02 5.1 Performances Reference operating condition: 25ºC Max. measurement error: 0,1% of the programmed range ±1 digit Influence of ambient temperature: 20ppm/ºC of measuring range at 20ºC as reference temperature Output signal: 4...20 mA Supply voltage: Voltage drop out:...
Display 5.7 Programming 1. Enter the Menu: i. Press "E" button for to 2 seconds to access the menu. 2. Set Decimal Point (dP): i. Press the "E" button to select. ii. Use the Up/Down buttons to change decimal position point. iii.
Display 6. Technical data and wiring display mod. ST0028 6.1 Performances Reference operating condition: 23ºC Max. measurement error: 0,1% of the programmed range ± 1 digit Influence of ambient temperature: 100ppm / ºC measured range Input signal: 4...20 mA Loop drop out: max.
Display 6.7 Programming 1. Enter the Configuration Menu: • Press and hold the "F" key for 3 seconds. • The first configuration item, Decimal Point [dP], will appear on the display. Use the Up (↑) and Down (↓) keys to cycle through the configuration •...
Display This number indicates the smallest change between consecutive readings. Use higher values for large engineering ranges or when the input signal is unstable. • Default: 1. 8. Transfer Function Selection [Lin] / [root] (*): Use the Up (↑) and Down (↓) keys to select the desired transfer function: •...
Display Error/warning indication: Individually configurable display and backlight indication in white, green or red colour, steady or flashing light. Configurable limits between 3.5 and 23 mA Zoom on range: Minimum 2 mA of input span Damping: 0…30 seconds Linearization table: 2 to 30 points Measuring unit: °C, °F, K...
Display 8. Disposal Note! Avoid environmental damage caused by media-contaminated parts Dispose of the device and packaging in an environmentally friendly manner Comply with applicable national and international disposal regulations and envi- ronmental regulations. Batteries Batteries containing pollutants are marked with a sign consisting of a crossed-out garbage can and the chemical symbol (Cd, Hg, Li or Pb) of the heavy metal that is decisive for the classification as containing pollutants: 1.
