Operating Instructions
for
Temperature Sensor
Model: TWL
Explosion Proof Protection Ex d

Advertisement

Table of Contents
loading

Summary of Contents for Kobold TWL

  • Page 1: 1Contents

    Operating Instructions Temperature Sensor Model: TWL Explosion Proof Protection Ex d...
  • Page 2: Table Of Contents

    1 Contents 1Contents ........................2 2Note ..........................4 3Instrument Inspection ....................4 4Regulation Use ......................4 5Operating Principle ...................... 5 6Electrical connection ....................5 7Use in hazardous Areas ....................8 7.1Area of validity ...................... 8 7.2Guidelines ......................8 7.3General ......................... 8 7.4Protection against E.S.D.
  • Page 3 Manufactured by: Kobold Mesura S.L.U Avda Conflent Nº68 Nave 15 08915 Badalona Tel.: +34 93 460 38 83 Fax: +34 93 460 38 76 E-Mail: info.es@kobold.com www.kobold.com Edition May 2022 DT0454 page 3...
  • Page 4: 2Note

    TWL 4 Regulation Use The temperature sensors of series TWL are suitable for all applications where processes involving fluids, solid bodies or materials, or gases, require temperature recording and measurement. Our temperature sensors are suitable for use in the following industrial areas: chemicals, petrochemicals, water, feed, food, sanitary, etc.
  • Page 5: 5Operating Principle

    5 Operating Principle Resistance thermometers work by using the continuous change of resistance of metals subject to temperature rising and decreasing. The most common resistance material used is platinum, as it is very stable and has very good repeatability. The temperature coefficient of platinum is positive, so its resistance increases as the temperature rises.
  • Page 6 6.2 Transmitter wiring diagram page 6 DT0454...
  • Page 7: 7Use In Hazardous Areas

    This measuring principle acts to check and measure the temperature also in explosion-proof areas. TWL devices can be with a standard 4 to 20 mA signal transmitter, Hart protocol, Profibus/Fieldbus or with direct access to the sensor. They are appropriate for use in Group IIC and Categories 2G/D explosion-proof atmospheres.
  • Page 8: Protection Against E.s.d. (Electrostatic Discharge)

    - Do not install the device near material airflows or near steam outlets 7.5 Maintenance and repairs The instrument does not require maintenance or servicing. Repairs must be only carried out by Kobold Mesura (manufacturer) 7.6 Storage Measuring instruments should be protected against humidity and dust.
  • Page 9: 8Description Of The Factory Label

    8 Description of the Factory Label Installation in the classified area Examples of installation in explosion-proof areas conform to the protection type “Ex d” DT0454 page 9...
  • Page 10: 9Installation In The Classified Area

    9 Installation in the classified area 9.1 Examples of installation in explosion-proof areas conform to the protection type “Ex d” Hazardous area Safe area page 10 DT0454...
  • Page 11: 10Technical Details

    10 Technical Details 10.1 Sensor wiring - 2 wires Error due to the lead resistance of the sensor - 3 wires With connecting wires up to 25 m, lead resistance is negligible. - 4 wires The lead resistance of the connecting wires is negligible Sensor according to IEC 60751 -Class B -Class A...
  • Page 12: Process Connection

    9…32 Vdc for transmitter with PROFIBUS ® /Fieldbus Note For programming of transmitter please refer to their separate programming manual. Sensors model TWL-SN and TWL-SA have not head transmitter, you must use remote transmitter. Transmitter 5333D Ambient temperature: -40...+85 ºC Power supply: 8...35 V...
  • Page 13: Display

    Transmitter 5337D Ambient temperature: -40...+85 ºC Power supply: 8...35 V Accuracy: Absolute accuracy ≤ ±0.1 ºC Temp. Coefficient (≤ ±0.005 ºC /ºC) Current Output: 4...20 mA HART® Load resistance: ≤ (V supply - 8) / 0.023 Sensor error detection: Programmable 3.5…23 mA NAMUR NE43 Upscale and NAMUR NE43 Downscale Transmitter 5350D...
  • Page 14: 11Dimensions

    11 Dimensions 11.1 Sensors Dimensions Temperature Sensor TWL-1 Dimensions Temperature Sensor TWL-2 HL: Neckpipe length 130 mm TWL-1 (other on request) U: Immersion length thermowell (see drawing thermowell) 150 mm TWL-2 (other on request) H: Length thermowell (see drawing thermowell) LN: Screw-in-length by hand (approx.
  • Page 15: Thermowells

    11.2 Thermowells Dimensions Thermowell Model TWL-…B… Nominal pressure: max. PN25 at 20ºC Cylindrical thermowell, welded with process connection G-thread Process Max. Total Connection length G ½ B G-thread 5000 mm G ¾ B 31.7 G 1 B Nominal pressure: max. PN25 at 20ºC...
  • Page 16 DIN DN 25 10/12 12/14 DIN DN 32 DIN DN 40 DIN DN 50 Dimensions Thermowell Model TWL-…G… Nominal pressure: max.PN100 at 20ºC Cylindrical thermowell out of solid material with stepped shaft and process connection G-thread Process Max. Total Connection...
  • Page 17 Nominal pressure: max. PN100 at 20ºC Cylindrical thermowell out of solid material with stepped shaft and process connection NPT-thread Process Max. Total Connection Length 7-8-9 17.5 ½ NPT 10-12 17,5 17,5 7-8-9 NPT-thread 1000mm ¾ NPT 10-12 7-8-9 1 NPT 10-12 Nominal pressure: as flange rating ( max.
  • Page 18 DN ¾” 26,9 10-12 For weld-on 1000 7-8-9 DN 1” 33.4 10-12 Dimensions Thermowell Model TWL-…D… Nominal pressure: PN250 at 20ºC Conical thermowell out of solid material with process connection G-thread Process Max. Total Connection Length 7-8-9 G ¾ B 31.7...
  • Page 19 Nominal pressure: PN250 at 20ºC Conical thermowell out of solid material with process connection NPT-thread Process Max. Total Connection Length 7-8-9 ¾ NPT 10-12 NPT-thread 1000mm 7-8-9 1 NPT 10-12 Nominal pressure: as flange rating (max. PN250 at 20ºC) Conical thermowell out of solid material with process connection flange acc, DIN or ANSI Process Max.
  • Page 20 Conical thermowell out of solid material with process connection flange acc. DIN or ANSI Process Max. Total Connection Length 7-8-9 DN 1” 33.4 10-12 For weld-on 1000mm 7-8-9 DN 1 ¼” 38.1 10-12 page 20 DT0454...
  • Page 21: Lagging Extension At Thermowell "T

    11.3 Lagging extension at thermowell “T”. In case of ordering with lagging extension at thermowell please see drawing and specify length “T” (total length is “T”+”H”). “H” is fix. DT0454 page 21...
  • Page 22: 12Order Details

    12 Order details Order Details (example: TWL-113LGBG4AA0) Sensor specification Model Sensor type Sensor type/cat. Sensor wiring Connection head/transmitter Sensor connection 0 = without 0 = without 0 = without 0 = without 1= 1 x Pt100 cat B -30…+550ºC 2= 2 x Pt100 cat B -30…+550ºC...
  • Page 23 “U“ and hole dia. “i“ (when ordering a/with thermowell) or “EL“ (when ordering without thermowell), neckpipe length “HL“ (when different from stdd. i.e. for TWL-1 stdd. Is 130 mm, for TWL-2 standard is150 mm), lagging extension “T“ (when ordering) and measuring insert length “ML“ (when ordering TWL-3) must be specified in clear text when ordering.
  • Page 24: 13Eu-Certificates

    Certificazione per esame di tipo CE Marcatura LOM 08ATEX2016 X II 2 GD Exd IIC T6 / Ex tD A21 IP65 T85 ºC Fabricado en KOBOLD MESURA SLU Avda. Conflent 68 nave 15 08915 BADALONA (Spain) Made in: Hergesteltlt in: Fabriqué dans: Fabbricato in:...
  • Page 25: 14Atex-Certificates

    14 ATEX-Certificates DT0454 page 25...
  • Page 26 page 26 DT0454...
  • Page 27 DT0454 page 27...
  • Page 28 page 28 DT0454...
  • Page 29 DT0454 page 29...
  • Page 30 KOBOLD MESURA S.L.U Avda. Conflent 68 Nave 15 08915 Badalona Tel.: +34 93 460 38 83 Fax: +34 93 460 38 76 E-Mail: info.es@kobold.com www.kobold.com Technical data Subject to change without prior notice page 30 DT0454...
