Before installing, operating, and maintaining the micro- programmable control, be sure to
familiarize yourself with this user manual and other related manuals to ensure proper use.
Please use it after you are familiar with the operation method, safety information and all
precautions.
In this manual, safety precautions are classified into two categories: "warning" and "caution".
Before installation, operation, maintenance and overhaul of the product, please
be sure to read the user manual and other related manuals to ensure correct use.
Failure to follow the instructions in the manual may result in improper installation
, use and storage of the equipment, which may result in personal injury or even death, and
property damage.
Part 1 Design Precautions
To ensure safety system operation, please configure emergency braking circuit, positive
inversion circuit or other similar protection circuit for PLC, which protection circuit can prevent
the damage to PLC or other devices.
●External power supply would break down unexpectedly.
●All outputs are turned off, as an error be detected by PLC CPU during self- diagnosis, such
as a watch dog timer error. When error that cannot be detected, internal protection circuit may
be disabled.
●The output state of transistor in the PLC can't be controlled, when transistor is damaged.
Part 2 Installation Precautions
●Always make sure to install PLC on vertical plane, not on broadside.
●50mm safe distance must be kept with other devices, and far away
from the high-voltage power line, high-voltage device and the power
equipment.
●Never use the product on condition with dust, oily smoke, conductive dusts, corrosive gas,
flammable gas, vibration or impacts, or expose to high temperature, fire or rain.
●Do not leave anything in the vent. when installation or wiring is completed.
●Always make sure to remove the dust proof sheet from the PLC's vent when installation or
wiring is completed.
LX6 Series User Manual
Safety Precautions
WARNING
WARNING
CAUTION
LX6 Series User Manual V2.0
1
Advertisement
Table of Contents
Related Manuals for Econ LX6 Series
Summary of Contents for Econ LX6 Series
- Page 1 LX6 Series User Manual V2.0 LX6 Series User Manual Safety Precautions Before installing, operating, and maintaining the micro- programmable control, be sure to familiarize yourself with this user manual and other related manuals to ensure proper use. Please use it after you are familiar with the operation method, safety information and all precautions.
-
Page 2: Part 3 Wiring Precautions
LX6 Series User Manual V2.0 Part 3 Wiring Precautions WARNING ●Before installation and wiring, you must cut off the power. ●Before running, please make sure to attach the cover for terminal on PLC. ●That positive inversion contactor is worked on at the same time will be dangerous. - Page 3 LX6 Series User Manual V2.0 Part 6 Module & Product specification Main view Right View Top view Elevation view (1) Mounting hole (9) Function button (2) DIN rail mounting clips (10) USB communication port (3) I/O terminal (11) TF card socket...
-
Page 4: Part 7 Communication Interface
LX6 Series User Manual V2.0 Part 7 Communication Interface The PLC has two communication ports：COM1 RS485 and COM2 RS485. COM 1/COM2 (RS485)： Signal Description 485+ COM1 Received data (positive) 485- COM1 Received data (negative) Signal ground 485+ COM2 Received data (positive) -
Page 5: Part 11 Input Specifications
LX6 Series User Manual V2.0 Impact JISC0041 standard resistance Voltage AC1500V (1 minute) resistance Confirm with Insulation JEM- 1021 DC500V is more than 5MΩ resistance Grounding Environment No corrosive gas, combustible gas, or electrical dust. Part 11 Input Specifications Model... -
Page 6: Part 12 Output Specification
LX6 Series User Manual V2.0 Part 12 Output Specification Model LX6V series Output type Transistor Load Output circuit components Programmable Controllers External power supply Power supply DC5~30V Loop insolation Transformer isolation The LED lights up when the Action optocoupler is driven Resistive 1.6A/4 points,3.2/8 points... -
Page 7: Part 14 Installation
LX6 Series User Manual V2.0 ● The output contacts of the programmable control are best to use on the same phase side. phase ●Contactors of forward and reverse close very dangerous at the same time, like this load, except to use internal program to do interlock control, on the outside of the programmable controller must also set the interlock. - Page 8 LX6 Series User Manual V2.0 Use the M4 screw to install the PLC. The distance and the location refer to the figure above and the table below. Model W(mm) W1(mm) LX6V-0808MX 108.5 100.0 Part 15 Battery Installation Instructions Part 16 The arrangement of terminal for LX6V series Terminal arrangement of the LX6V series basic unit.
