Installation & Operation Manual
Fig. 7907, type ELA80 - 3000
ELA80, 100, 150, 200, 300, 500, 600, 800, 1200, 2000, 2700 & 3000
ECON actuator Fig 7907, type ELA80 – 3000
Rev.13 – January 7, 2019
ECON ELECTRIC ACTUATOR
Installation and operation Manual for actuator type:
Proven Quality since 1892
Compact quarter turn actuator
Mechanical position indicator
High output torque
Multi mounting base
Manual override
o, Republic :
www.eriks.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELA80 and is the answer not in the manual?

Questions and answers

Related Manuals for Econ ELA80

Summary of Contents for Econ ELA80

  • Page 1 High output torque Multi mounting base Manual override Installation and operation Manual for actuator type: ELA80, 100, 150, 200, 300, 500, 600, 800, 1200, 2000, 2700 & 3000 o, Republic : ECON actuator Fig 7907, type ELA80 – 3000 www.eriks.com...

  • Page 2: Table Of Contents

    4.10.2 Setting PCU Functions 4.11 AC/DC Multi-Board (Optional) 4.12 Rechargeable Battery Pack – RBP (Optional) 4.12.1 General 4.12.2 Features 4.12.3 Specifications 4.12.4 PCB Layout 4.12.5 Operations ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 3 Electrical Connections and Preliminary Test 7. MAINTENANCE Maintenance Tools 8. TROUBLE SHOOTING 9. INSTALLATION AND MAINTENANCE TIPS APPENDIX I : Wiring Diagram APPENDIX II : Grounding ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 4: Introduction

    Note: Information in this manual is critical to the user’s understanding of the actuator’s installation and operation ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 5: Product Identification

    ECON logo (trade mark)  CE ATEX and IECEx mark  Model  Motor specification  Ambient temperature  Production date  Serial number  Manufacturer’s address  Warning ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 6: Applied Standards

    Actuators must be stored in a clean, cool and dry area. The unit should be stored with the cover installed and the conduit openings sealed. Storage must be off the floor, covered with a sealed dust protector. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 7: General Information And Features

    2. 24VAC actuators have 24VDC motors. 3. 115VAC and 230VAC ±5% according to IEC 60034-1 4. Duty ratings: ELA80 and ELA100 in 380 VAC/3Ph – S4-70% and 440 VAC/3Ph - S4-40%. 5. Maximum power at 3 Phase: S4-70%: 164 W and S4-40%: 348 W.

  • Page 8: Ela-Series Options

    Ceramic housing with thermostat to prevent over heating with 60℃ set temperature. Heating Element Self-regulating 115V 5W 4.5KΩJ Voltage Range (ELA80~100) (based on the power supply) 230V 5W 18KΩJ 24V DC 5W 200ΩJ 12V DC 5W 47ΩJ...

  • Page 9: Lubrication

    3.2.2 ELA2000 - 3000 (Actuator + Gear Box) Top cover Window & Indicator Handwheel Body Lever Actuator base Mechanical travel stops Gear box including Driving bushing ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 10: Internal Parts For Standard Models

    ELA80 - 3000 Motor Limit switch Terminal assembly block Motor Motor Capacitor Torque switch assembly Note: ELA80 and ELA100 do not have a torque switch provision! ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 11: Installation

    CAUTION: Do not attempt to work on your ECON actuator without first shutting off the power supply Do not attach ropes or hooks to the hand wheel for lifting purposes ECON actuator Fig.

  • Page 12: Actuator Mounting Base Details (Iso 5211)

    4x  ELA1200 DS 27mm DS 22-30mm  ELA2000 DS 36mm DS 27-46-55mm  ELA2000 DS 36mm DS 27-46-55mm  ELA3000 DS 46mm DS 27-36-55mm Pitch ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 13: Limit Switch Setting

    Rotate the OPEN cam CCW until the limit switch ‘clicks’ (see Figure 2) Tighten the set screw with the Allen key.  DANGER: HAZARDOUS VOLTAGE. Make sure all incoming power is disconnected before setting the limit switches ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 14: Torque Switch Setting

    The torque switches are set by manufacturer on the production site. If re-setting is necessary, please contact the ECON actuator distributer before setting the torque switch. CAUTION: Do not reset the torque switch to a setting higher than the maximum setting stated by the manufacturer.

  • Page 15: Setting Potentiometer (Optional)

    1 s at (Rated VAC x 2 + 1000) x 1.2 (from Input to power ground) Insulation Resistance Above 500V DC 30MΩ Vibration 10g, 0~34Hz 14 | P a g e ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 16: Calibration Of Zero And Span - Cpt

    When the actuator is in the fully open position, adjust the SPAN open setting on the CPT board until an output value of 20mA is achieved. Zero dial Span dial ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 17: Pcu-A Proportional Control Unit Alternating Current (Optional)

    However, we strongly recommend that input power, signal input selection and DIP switches are to be verified prior to the actuator start up. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 18: Pcu-D Proportional Control Unit Direct Current (Optional)

    However, we strongly recommend that input power, signal input selection and DIP switches are to be verified prior to the actuator start up. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 19: 4.10.1 Led Signal Indication

    60 Hz (not applicable for PCU-D) 50 Hz (not applicable for PCU-D) Note: If not specified, the factory setting of the input signal is 4 - 20mA. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 20 17 and 18, while opening and closing the actuator. If necessary adjust the potentiometers “zero” and “span” on the bottom of the circuit board until the output values are correct. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 21 Fully Closed Auto-Full Switch (Switch 3) On (up) Signal: 19.7~20mA Fully Open Auto-Full Switch Signal: 4mA Fully Closed (Switch 3) Off (down) Signal: 20mA Fully Open ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 22 LED will be lit off to indicate the termination of the Manual Operation Mode. Note: During the Manual Operation mode, the input signal is ignored. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 23  Turning the Delay Time Dial in clockwise direction will increase the deadtime time (Range 0.05 to 7.5 seconds). Dial 0.05 Dial ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 24: Ac/Dc Multi-Board (Optional)

    A) Power Open-Close Terminal block Power 24V AC/DC (DC + signal block) None None Open signal Close signal Power 24V AC/DC (DC – signal block) B) Power Input Switch ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 25 C) Motor Terminal Block Red motor wire must be connected to block # 1  Black motor wire must be connected to block # 2  ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 26: Rechargeable Battery Pack - Rbp (Optional)

    The battery must be discharged and charged regularly every 2 to 3 months. 4.12.1 General The ECON actuator with Rechargeable Battery Pack (RBP) can be operated in Local or Remote mode by using two selector switches on the local control unit. During power failure the actuator can be operated 5 times by the battery pack.

  • Page 27: 4.12.2 Features

    Fault Contact Normal Close Actuator functions by DIP Power Fail action switch settings DIP switch 3 DIP switch 4 FUNCTION STOP CLOSE OPEN NO POWER FAIL ACTION ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 28: 4.12.4 Pcb Layout

    If the actuator does not work on battery power, despite of a fully charged battery and a jumper has been placed on terminal strip connection number 1 and number 4, please press the battery active switch (12). ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 29 BLINK OPENING 4.RED FULLY OPEN NO ERROR/FAULT 5. AMBER ERROR message GREEN HIGH CHARGING 6.BATTERY BLUE MIDDLE CHARGING (BLINKING) LOW CHARGING RED STEADY ON NO BATTERY ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 30: 4.12.5 Operations

    3. REMOTE MODE: During power failure, the actuator will follow the power failure settings (DIP switch settings – see paragraph 4.12.4) 4. NO FAIL ACTION : The actuator will operate the same way as if there was not power failure. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 31: Fieldbus Communication Protocols (Optional)

    Function Code, the slave returns a message (a ‘response’).  The slaves shall not communicate with each other without the request of the master. Since the ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 32: Specification

    Supported Baud Rates: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200  Supported Parity Bit: Odd, Even, None  Supported Stop Bit: 1, 2 For more detail information, please refer to separate ModBus operation manual. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 33: Operation

    Once the power is supplied to the actuator, precautions must be taken if the cover is not mounted. Note: For more information, refer to Appendix II ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 34: Maintenance

    In case a PCU-A or –D board has been mounted: DC signal generator (4-20mA DC) x 1  In case a PCU and CPT board has been mounted: mA Meter (0~25mA) x 1 ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 35: Trouble Shooting

    Check the board for any damage 2) Current Position Transmitter  Verify the input signal  Check the configuration of the dip switches  Check the board for any damage ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 36: Installation And Maintenance Tips

     Any kind of coating for sealing surfaces is not permitted.  When replacing parts, seals, etc., only original spare ones must be used. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 37: Appendix I : Wiring Diagram

    Proven Quality since 1892 APPENDIX 1 : Wiring Diagrams DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 38 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 39 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 40 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 41 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 42 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 43 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 44 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 45 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 46 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 47 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 48 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 49 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 50 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 51 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 52 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 53 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 54 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 55 Installation & Operation Manual Proven Quality since 1892 DANGER: HAZARDOUS VOLTAGE. Electrical power must not be connected until all wiring and limit switch adjustments have been completed. ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...

  • Page 56: Appendix Ii : Grounding

    Internal Ground External Ground Terminal Block #1 should be used for internal ground DANGER: Flameproof Enclosure! Before opening, ensure that there is no explosive gas or voltage ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com Rev.13 - January 7, 2019...
  • Page 57 You can find them on www.eriks.com ERIKS Flow Control Cypresbaan 63, 2908 LT Capelle aan den IJssel, The Netherlands Phone: +31 (0)10 284 1100 56 | P a g e ECON actuator Fig. 7907, type ELA80 – 3000 www.eriks.com REV.13 - January 7, 2019...
