Giant REVEL 0 Datasheet

108 revel
Specifications
siZes XS,S,M,L,XL,XXL
CoLour Black / Green
FrAme ALUXX-grade butted aluminum
Fork RockShox Dart 2, 100mm travel
shoCk N/A
hAnDLeBAr Giant Sport low-rise 31.8mm
stem Giant Sport
seAtpost Giant Sport 30.9x375mm
sADDLe Giant Sport MTB
peDALs Alloy platform
shiFters Shimano Alivio
Front DerAiLLeur Shimano Alivio
reAr DerAiLLeur Shimano Deore long cage
BrAkes Avid BB5 160mm ball-bearing disc
BrAke Levers Tektro Alloy
CAssette SRAM PG-830 11-32T 8SPD
ChAin KMC Z72
CrAnkset Shimano Alivio Octalink 22/32/42T
Bottom BrACket Shimano Octalink
rims Giant XC alloy double wall 32H
huBs Formula Alloy
spokes Stainless Steel 14g
tires Kenda Small Block 8 26x2.1"
extrAs
Specifications and availability subject to change without notice.
$
Spec Features
— RockShox Dart 2 fork w/ 100mm travel
— Shimano Alivio/Deore 8-speed drivetrain w/ triple crankset, Avid disc brakes
— Giant Sport handlebar, stem & seatpost
frame geometry
A B C
Actual part head seat
Frame size number Angle Angle*
inches degrees degrees
XS 14 2117200 69.0 72.5
S 16 2117201 69.0 72.5
M 18 2117202 69.0 72.5
L 20 2117203 69.0 72.0
XL 22 2117204 69.0 72.0
XXL 24 2117205 69.0 72.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
D E F
toptube** headtube Chainstay wheelbase
inches inches inches inches
21.3 4.7 16.7 40.6
22.4 5.1 16.7 41.6
22.8 5.7 16.7 42.4
23.3 6.3 16.7 42.9
24.3 7.1 16.7 43.5
25.0 7.9 16.7 44.1
G H
standover
height***
inches
28.5
28.8
30.2
31.4
31.9
32.4
