Reign 0
Specifications
SIZES XS,S,M,L,XL
COLORS White
ALUXX SL-Grade Aluminum,
FRAME
6.0" Maestro Suspension
Fox 32 Talas FIT RL w/ 15QR thru axle,
FORK
110/130/150mm travel
SHOCK Fox DHX 5.0, air
HANDLEBAR Giant Contact, low rise 31.8
STEM Giant Contact
SEATPOST Giant Connect SL, 30.9
SADDLE Fi'zi:k Nisene wingflex w/ K:ium rails
PEDALS Not Included
SRAM X9 trigger w/ Matchmaker
SHIFTERS
Clamp
FRONT DERAILLEUR Shimano Deore XT
REAR DERAILLEUR SRAM X0
BRAKES Avid Elixir CR 180F/180R
BRAKE LEVERS Avid Elixir R
CASSETTE Shimano Deore XT 11x34, 9-speed
CHAIN Shimano HG-73
CRANKSET Race Face Deus XC, 22/32/44
BOTTOM BRACKET Race Face X Type, External
RIMS Mavic EN521
[F] Giant Tracker Sealed/CNC w/ 15mm
HUBS
Axle, [R] Shimano Deore XT, 32h
SPOKES DT Competition 14/15g
TIRES Kenda Nevegal, 26x 2.35 Folding
EXTRAS
Specifications and availability subject to change without notice.
BEASTLY TRAILS DON'T DISCOURAGE YOU—THEY
TEMPT YOU. BABYHEADS, ROOTS, RUTS. THAT'S
WHY IT'S CALLED ALL MOUNTAIN.
Frame Technology
Hold your position against the rough stuff with Reign's solid support. 6 inches of aggressive
Maestro suspension give you maximum control when it's needed most. With a balanced ALUXX
SL aluminum frame, you'll master technical climbs and flow down rough descents.
Key Upgrades (over Reign 1)
— Full-featured Fox 32 Talas FIT RL w/ 15QR thru-axle,
110/130/150mm suspension fork, Fox DHX 5.0 air rear shock
— SRAM X.9 shifterS X.0 rear derailleur with Avid Elixir R disc brakes
— Lighter Giant Contact alloy handlebar, stem and seatpost
— Mavic EN521 rim/Giant Tracker (f) hub/ Shimano Deore XT
(r) hub/DT Competition spokes, wheelset
frame geometry
Actual Part Head Seat
Frame Size Number Angle Angle*
inches degrees degrees
XS 346552 68.0 73.5
S 346553 68.0 73.5
M 346554 68.0 73.5
L 346555 68.0 73.5
XL 346556 68.0 73.5
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Toptube** Headtube Chainstay Wheelbase
inches inches inches inches
21.5 4.7 17.2 42.5
22.0 5.1 17.2 43.1
23.0 5.7 17.2 44.1
24.0 6.5 17.2 44.9
25.0 7.5 17.2 46.0
Standover
Height***
inches
31.5
31.6
31.9
32.0
32.6
