Giant REIGN 0 - DATASHEET 2 Datasheet

90 Reign *

Specifications

siZes
XS,S,M,L,XL
CoLour
Black / Bright Green
ALUXX SL-grade aluminum,
FrAme
6.0" Maestro suspension
FOX 32 TALAS 150 FIT RL, tapered,
Fork
15QR, 120-150mm travel
shoCk FOX RP23 BV, XV sleeve
hAnDLeBAr Giant Contact SL/R low-rise 31.8mm
stem Giant Contact
Crank Brothers Joplin-4 30.9x398mm,
seAtpost
remote
sADDLe Fi'zi:k Gobi XM w/ K:ium rails
peDALs Not included
shiFters Shimano Deore XT
Front DerAiLLeur Shimano Deore XT
reAr DerAiLLeur Shimano Deore XT Shadow long cage
Avid Elixir CR F:185mm / R:160mm
BrAkes
hydraulic disc
BrAke Levers Avid Elixir CR
CAssette Shimano Deore XT 11-36T 10SPD
ChAin Shimano HG74
CrAnkset Shimano Deore XT 24/32/42T
Bottom BrACket Shimano internal press fit
rims DT Swiss TRICON M 1700
huBs DT Swiss TRICON, F:15QR
spokes DT Swiss TRICON
tires Kenda Nevegal 26x2.35"

extrAs

Specifications and availability subject to change without notice.
$

Spec Features

— FOX 32 TALAS 150 FIT RL tapered 15QR fork w/ 120-150mm travel, FOX RP23 shock
— Shimano Deore XT 10-speed component group, Avid Elixir CR disc brakes
— Giant Contact SL/R composite handlebar, Contact stem & Crank Brothers Joplin-4 seatpost
— Wheelset: DT Swiss TRICON M 1700 tubeless-compatible disc

frame geometry

A B C
Actual part head seat
Frame size number Angle Angle*
inches degrees degrees
XS 14.5 2112200 67.5 73.5
S 15 2112201 67.5 73.5
M 17 2112202 67.5 73.5
L 19 2112203 67.5 73.5
XL 20 2112204 67.5 72.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
*available in limited quantities
D E F
toptube** headtube Chainstay wheelbase
inches inches inches inches
21.7 4.6 17.2 42.9
22.2 4.6 17.2 43.5
23.2 5.0 17.2 44.5
24.2 5.9 17.2 45.4
25.2 7.5 17.2 46.4
G H
standover
height***
inches
31.4
31.6
31.9
32.0
32.6
