Summary of Contents for Giant Propel series
- Page 3 Your best resource for service and technical assistance is your local Giant retailer. To find one, or to learn more about Giant, go Clean before installation of carbon fiber composite parts to giant-bicycles.com.
- Page 4 1/2-inch bottom bearings and provides up to 30 percent more torsional steering stiffness. weight and optimized stiffness. Please contact your authorized Giant dealer to modify the steerer length to your preference. If you are a qualified professional mechanic, please follow these instructions: Once the headset assembled, make sure that some play exists between: ‡...
- Page 5 Install the saddle onto the seatpost using the included saddle clamp mechanism. The Giant SpeedControl Brake is optimized for the Propel and Envie series bikes. It’s designed to Put the saddle in a horizontal position and then determine the length to be cut.
- Page 6 Step 2: Disassembling for cutting Follow this table to determine the appropriate washer combination: Loosen the saddle clamp bolt and remove the saddle. WASHER Step 3: Cutting the seatpost 10mm 10mm NOTE: A professional saw guide for seatpost cutting is must to be used. For example: PARK TOOL Oversized Adjustable Saw Guide CAUTION: Use a fine-tooth (32-tooth) saw blade to avoid fraying the composite fibers.
- Page 7 The saddle clamp can be assembled forward or backward. So you can compensate with a +5mm or -25mm position. The Giant Vector Seatpost is built with Giant Composite Technology for lightweight, aerodynamic performance. To achieve the best riding experience and proper saddle height, the seatpost may WARNING: Saddle clamps must be assembled as illustrated.
- Page 8 Note: In original condition, the seatpost length against frame sizes is as follows: Cut the seatpost at a 45-degree angle so that the bottom of the post slopes downward from the rear Frame size Minimum saddle height(mm) side to the front side. This will help prevent damage to the frame if the seatpost is pushed too far down.
- Page 9 Note: This manual is designed to provide information for installation of a bottom bracket into a modification will affect the bottom bracket interface and will void the warranty. Giant composite frameset. Please refer to the specific manufacturer’s enclosed guide for final crankset installation details.
- Page 10 Alternate tightening between the two fasteners until the torque measurement is achieved. Giant Contact SLR Aero Integrated Handlebar Cable Routing Holes CAUTION: It is possible to crush the steerer tube if fasteners are tightened Top Angle View beyond the recommended torque values.
- Page 11 1, 2), and pass the cable(s) through the downtube and thread out from the bottom bracket. Fig. Rear derailleur cable hole ROUTING REAR BRAKE CABLE Giant aluminum Shimano Di2 cable stopper grommet Start out rear brake cables from the CONTACT SLR AERO HANDLEBAR inner route. (Refer...
- Page 12 Series Propel Advanced SL 516B Head Parts Diameter ¢42/¢47 Toptube cable stopper / Di2 1472-CC516B-301 1472-CM297A-401 Seatpost Diameter Giant Aero ISP grommet 297A Front Derailleur Diameter Braze on Rear O.L.D Cable clip / bottle 147-9109-7 mount Max Tire Type 700Cx23C...
