Quick Recovery Electric (QRE) - Vitreous Enamel
Operation & Installation Manual
QREVE340L336
QREVE340L336H
QREVE340L348
QREVE340L348H
QREVE340L360
QREVE340L360H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QRE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Rinnai QRE Series

  • Page 1 MODELS QREVE60L336 QREVE340L336 QREVE340L336H QREVE60L348 QREVE340L348 QREVE340L348H QREVE60L336H QREVE340L360 QREVE340L360H QREVE60L348H Quick Recovery Electric (QRE) - Vitreous Enamel Operation & Installation Manual...
  • Page 2 This appliance must be installed, maintained and removed ONLY by an Authorised Person. For continued safety of this appliance it must be installed and maintained in accordance with the manufacturer’s instructions. Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 3: Table Of Contents

    Water Quality ����������������������������������������������������������������������������������������������������������������������������������������������������������������������� 15 Mains Pressure �������������������������������������������������������������������������������������������������������������������������������������������������������������������� 15 Thermostat Setting �������������������������������������������������������������������������������������������������������������������������������������������������������������� 16 Reducing the Risk of Scalding ��������������������������������������������������������������������������������������������������������������������������������������������� 16 Plumbing Connections ��������������������������������������������������������������������������������������������������������������������������������������������������������� 16 Connections to the water heater ������������������������������������������������������������������������������������������������������������������������������������� 16 Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 4 Electrical Connections ��������������������������������������������������������������������������������������������������������������������������������������������������������� 18 Commissioning Wiring Diagram - 60L & 340L ����������������������������������������������������������������������������������������������������������������������������������������������� 19 To fill & turn ‘ON’ the water heater ��������������������������������������������������������������������������������������������������������������������������������������� 20 To turn ‘OFF’ the water heater ��������������������������������������������������������������������������������������������������������������������������������������������� 20 Contacts Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 5: Warnings & Safety

    WARNINGS & SAFETY REGULATORY INFORMATION The Rinnai Quick Recovery Electric, Mains Pressure Vitreous Enamel Commercial Electric Storage Water Heater has been certified by relevant plumbing and electrical authorities and the details are shown on the data plate. WARNING GENERAL SAFETY INFORMATION This appliance must be installed, commissioned and serviced only by a authorised person.
  • Page 6: Water Temperature

    Never…. Leave a toddler in the care of another child. They may not understand the need to have the water temperature set at a safe level. Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 7: Safety Devices

    If the valve dribbles or leaks continuously, operate the easing gear for a few seconds. This may dislodge any foreign matter and stop leakage. If leakage does not stop Contact Rinnai to arrange inspection by a qualified person.
  • Page 8: Important Information

    Undo the cold water inlet union. Attach a hose to the water heater side of the union. Let the other end of the hose go to a drain. Operate the PTR valve easing gear again. This allows air into the water heater and will result in water draining through the hose. Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 9: Care & Maintenance

    Rinnai service network personnel are fully trained and equipped. If your Rinnai appliance requires servicing contact Rinnai as per the details on the back page of this manual. Rinnai recommends that this commercial appliance be inspected and serviced by a qualified person every 12 months.
  • Page 10: Specifications

    92540129 Anode AL 340L only 95110423 Valves with pressure ratings other than specified are unsuitable and MUST NOT be used. Components MUST BE replaced with those specified by Rinnai. NOTE Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 11 A PLV MUST BE fitted if the supply pressure exceeds the limits shown. If the mains pressure is within the limits shown fitment of the PLV is optional. Valves with pressure ratings other than specified are unsuitable and MUST NOT be used. NOTE Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 12: InstallationConfigurations

    When multiple systems are installed, they MUST BE equal length and plumbed (see example figure above) to ensure pressure drops are balanced. WARNING For multiple systems and tanks, ensure the connecting pipework is configured to balance system pressure drop. Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 13: Hot Water Plumbing System Example - No Tld

    It may be a requirement that the hot and cold water supply pressures to a Temperature Limiting Device (TLD) are equal. If this is the case, a PLV with the same pressure rating as the PLV for the hot water is required for the TLD as shown. Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 14: Installation

    This schematic is an example only, variations may also be suitable. CAUTION Tempered water from a TLD CANNOT be re-circulated. The TLD MUST BE positioned in a dead leg, branching off the circulated hot water flow and return pipe. Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 15: Location

    This appliance is NOT suitable for use as a spa or swimming pool heater. LOCATION The Rinnai QRE storage water heater range have an ingress protection rating of IPX4 making them suitable for internal or external installation. The water heater should be placed as close as practicable to the most frequently used hot water outlet point or points to minimize the delay time for hot water delivery.
  • Page 16: Thermostat Setting

    Rinnai recommend that an approved TLD is fitted into the hot water pipe work from the water heater to areas used primarily for personal hygiene such as bathrooms and ensuites to reduce the risk of scalding.
  • Page 17: Pressure And Temperature Relief (Ptr) Valve

    It is recommended that the anode be inspected at least every 5 years. The factory fitted Rinnai anode is Magnesium based. This anode is suitable when the total dissolved solids (TDS) content in the water supply does not exceed 600 mg/L, which is the case in most areas. In areas where the total dissolved solids (TDS) content in the water supply exceeds 600 mg/L the Rinnai aluminium based anode is required.
  • Page 18: Electrical Connections

    The thermostat is adjustable from 60°C to 80°C. Turning the adjustment knob anticlockwise decreases the temperature setting and turning it clockwise increases the temperature setting. Rinnai advise that the thermostat be set at 70°C as this temperature is sufficient for most commercial applications.
  • Page 19: Commissioning

    Number of Poles Single Number of Throws Single Dial Colour Pink Temp Range 60 to 80°C Dial Set At 70°C Cut Off 60°C ± 3 Differential 8°C ± 4 Reset Manual Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 20: To Fill & Turn 'On' The Water Heater

    Isolate or turn 'OFF' the water heater at the electricity supply. Close the cold water isolation valve at the inlet to the water heater. Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 21 NOTES Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 22 NOTES Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 23 NOTES Rinnai QRE – Vitreous Enamel – OIM – Issue 1...
  • Page 24: Contacts

    Tel: 1800 000 340* *Cost of a local call may be higher from a mobile phone. (National calls from public phones in Australia are free.) For further information visit www.rinnai.com.au or email enquiry@rinnai.com.au innai has a Service and Spare Parts network with...
