- Page 1 WF-120C Manual PROFESSIONAL WEATHER STATION...
- Page 2 WF-120C Manual Features: Perpetual calendar up to year 2099 Automatic calibration of network time service Day of week in 15 languages user selectable: English, German, French, Spanish, Italian, Dutch, Danish, Portuguese, Norwegian, Swedish, Polish, Finnish, Czech, Hungarian, and Slovak ...
-
Page 3: Weather Station Appearance
WF-120C Manual Weather Station Appearance... - Page 4 WF-120C Manual Part A-Positive LCD A1: Outdoor wireless channel A2: Outdoor temperature A3: Wind direction or gusts or average wind speed A4: Outdoor comfort icon A5: Outdoor humidity A6: Wind speed A7: Light intensity A8: UV index A9: Time A10: Calendar...
- Page 5 WF-120C Manual Multi-Combination Wireless Remote Sensor Appearance Part D –Exterior D1: Solar panel Rain funnel D3: Wind cups Bubble level D5: Temperature humidity induction box D6: Wind directional vane D7: Reset button D8: LED indicator D9: Manual transmit signal button...
- Page 6 WF-120C Manual Temperature | Humidity Wireless Remote Sensor Appearance (This sensor is not configured, please purchase separately if needed) Part E –Exterior E1: Hanging hole E2: LCD display LED indicator E4: Temperature Humidity sensing louver Manual transmit signal button “TX”...
-
Page 7: Setup Preparation
WF-120C Manual Setup Preparation Items you will need to setup your station (not included): 1. Crosshead screwdriver and hex driver for assembly. 2. Fresh Batteries: 2 (two) AA alkaline or lithium batteries for the weather station. 3 (three) AA alkaline or lithium batteries for the multi-combination sensor. - Page 8 WF-120C Manual 1. Log in or register an account 2. Click "My Profile", and then click "My Devices" to register your device after the drop-down menu pops up. 3. Click "Adding new devices" to add a new device 4. Select type "other" and click "Next"...
- Page 9 WF-120C Manual 5. Set the location of the device on the map and click "Next" 6. Follow the prompts for each item, set the correct items and click "Next". (Note: The items in red are required.)
- Page 10 WF-120C Manual 7. After the setup is completed, the website will automatically generate the device ID and KEY. Record the ID and KEY, which will be needed when pairing the weather station. Weathercloud Open the browser and go to the following website: "https://weathercloud.net", and follow the steps shown below to quickly register the device 1.
- Page 11 WF-120C Manual 2. Click Avatar in the upper right corner, and then click " Devices" to register your device after the drop-down menu pops up. 3. Click "+ New" to create a new device 4. Follow the prompts for each item, set the correct items and click "Create". (Note: The items with a red "*"...
- Page 12 WF-120C Manual 5. Click "SETTING" in the rightmost column of the corresponding device to pop up the drop-down menu, then click "Link device"...
-
Page 13: Wifi Pairing
WF-120C Manual 6. After clicking, the website will automatically pop up a pop-up window showing the ID and KEY of the registered device. Record the ID and KEY, which will be needed when pairing the weather station. WIFI Pairing After being turned on, the weather station will automatically enter AP pairing mode, at the same time, the time bar will display "AP". - Page 14 WF-120C Manual Note: The paired WIFI hotspot must be 2.4GHz, this product only supports 2.4GHz wireless network. Because werther's hotspot is paired with the weather station's hotspot, it will prompt that there is no network after connecting. This is normal. Make sure you don't disconnect.
- Page 15 WF-120C Manual In the "Time Zone Setup" column, select the time zone where the weather station is located and the time server you need to use. After completing the setup, click 'SAVE' and wait for the confirmation prompt. Once prompted, the pairing is complete, and the weather station will automatically connect to Wi-Fi and upload device data to 'wunderground.com' and/or 'weathercloud.net'.
- Page 16 WF-120C Manual column switches to one channel every 5 seconds, in the order CH1 CH2 CH3. If the channel has no signal, it will automatically skip during the loop. Note: In the loop mode, only the values of temperature and humidity are being converted, and the values of wind speed, wind direction, rainfall, etc.
- Page 17 WF-120C Manual Week language display Language Sunday Monday Tuesday Wednesday Thursday Friday Saturday ENGLISH MONDAY TUESDAY WEDNESDAY THURSDAY FRIDAY SATURDAY SUNDAY GERMAN MONTAG DIENSTAG MITTWOCH DONNERSTAG FREITAG SAMSTAG SONNTAG FRENCH LUNDI MARDI MERCREDI JEUDI VENDREDI SAMEDI DIMANCHE ITALIAN LUNEDI MARTEDÌ MERCOLEDÌ...
-
Page 18: Switching Off The Alarm Signal
WF-120C Manual Note: Wait for 20 seconds without pressing any buttons, or double-click on the “ ” touch position to exit the viewing modes. Alarm and Snooze Settings Press and hold the “ALARM” button for 3 seconds to enter the alarm and snooze setting mode. - Page 19 WF-120C Manual and wWind chill. Note: feels like temperature, dew point temperature, heat index and wind chill index is related to the value detected by the multi-combined wireless remote sensor. Note: After viewing, it will automatically return to the display of feels like temperature 20 seconds later ...
-
Page 20: Weather Forecast
WF-120C Manual accumulated rainfall Rainfall rate: average hourly rainfall of daily or current rainfall events RAIN Press and release the “ ” button to view the rain history, in order: EVENT HOURLY DAILY WEEKLY MONTHLY YEARLY TOTAL Note: EVENT: The cumulative value of the current rainfall event. If there is no rain for more than 30 minutes, it... -
Page 21: Low Battery
WF-120C Manual the backlight will always be bright. Press the “SET/ ” button to adjust the backlight brightness , you can adjust the 5 state: 4 different brightness backlight and close the backlight. When the backlight brightness is not at the maximum brightness, Press the “... - Page 22 WF-120C Manual Mounting Instructions (wireless sensor) Multi-Combination Wireless Remote Sensor Mount in an open area clear for 15 meters (50 feet) in all directions. The sensor needs to be mounted on a sturdy platform or bracket that is mounted 1.5 m (5 ft) above the ground.
- Page 23 WF-120C Manual Mount the mounting screws to the wall. Hang the wireless sensor on the screw. Option 2: Insert the mounting screws through the front of the wireless sensor into the wall. Tighten the screws to fit snugly (do not overtighten).
