- Page 1 LED Outdoor Wall Light SKU: HOWL22A [Instruction Manual] Please pay attention to the warning signs Read the instructions with caution before operating and keep it properly V31222...
-
Page 2: Packing List
Warning: Risk of fire. Min 75°C supply conductors. Consult a qualified electrician to ensure correct installation.Before installation, please turn off the main power of the circuit breaker to prevent possible electric shock. Packing list Part Quantity LED Wall light 2 pcs Wire connectors 6 pcs Mounting screw... -
Page 3: Step 01: Power Off
NOTE: PLEASE INSTALL THIS WALL LANTERN 1.2 METERS 3.94 FEET ABOVE THE GROUND FIG.3 FUSE BOX STEP 01: POWER OFF FIG.1. Turn the wall switch to the “OFF” position. Depending on which type of fuse box in your home; FIG.2. Either turn the main (Master) switch to the "OFF" position to cut off the power supply of the entire home, or turn off the individual switch that supplies power to the fixture installation location. -
Page 4: Step 05: Power On
STEP 04: FIX THE LIGHT Secure the LIGHT(7) to the MOUNTING PLATE(2) and tighten the canopy screws(8)on both sides. Make sure that the LIGHT(7) is perfectly fixed and that the wires are not pinched between the mounting plate and the fixture. STEP 05: POWER ON Turn on the main (Master) switch to get the power back, the light will turn on automatically. - Page 5 List of compatible dimmers Brand Model number DVCL-153PR（15%） MACL-153MLH-WH（10%） Lutron P-PKG1W-WH-R（7.5%） STCL-153PH-WH（5%） R11-DSL06-1TW（15%） Leviton R00-RNL06-0TW（10%） R02-DW6HD-2RW（5%） R68-06674-P0T（2.5%） Legrand RHCL453PNICCV4（10%） TP-link HS220（5%） Commercial Electric HPDA311CWB（15%） Compatible with most dimmers on the market, e.g： LUTRON: DVELV-300P, DVCL-153P, SCL-153PH, S-600P, PD-6WCL, MACL-153M, AYLV-600P COOPER: SAL06P LEGRAND: RHCL, 453P, TCCCV6 One Year Limited Warranty...
