Alinx FH9712 User Manual

16-channel gmsl2 on-board camera acquisition module

Advertisement

Quick Links

16-channel GMSL2 On-board
Camera Acquisition Module
FH9712
User Manual
Rev 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the FH9712 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alinx FH9712

  • Page 1 16-channel GMSL2 On-board Camera Acquisition Module FH9712 User Manual Rev 1.0...
  • Page 2 4-in-1 FAKRA coaxial connector. The four MAX96712 chips are converted into four 4-LANE MIPI signals to connect to the FPGA development board of ALINX through FMC interface to realize the conversion and transmission of video images. The FMC interface is a standard LPC interface that meets the VITA 57.1 standard.
  • Page 3 FH9712 User Manual 1.1 Parameters of Module FH9712 1) Support multi-channel GMSL1/2 camera input It supports 16-channel cameras, 8MP resolution cameras as the highest 2) Cable length Up to 40m (3Gbps) in GMSL1 mode Up to 20 m (6Gbps) in GMSL2 mode...
  • Page 4 FH9712 User Manual 1.2 Structure Diagram of Module FH9712 FH9712 Structure Diagram www.alinx.com 4 / 9...
  • Page 5 FH9712 User Manual Part 2: Functions of Module FH9712 2.1 Schematic diagram of the module FH9712 The schematic design diagram of the module FH9712 is as follows: MIPI 4Lane COAXA~ COAXD MAX96712 GPIO/I2C (I2C ADR:0x52) MIPI 4Lane COAXA~ COAXD MAX96712...
  • Page 6 Design diagram of POC power supply 2.2 Pin assignment of Module FMC LPC Only the signals are listed below, and the power and GND signals are not listed. The following figure is the pin assignment of FH9712 and Z7-P development board. FMC Pin No.
  • Page 7 FH9712 User Manual G2_CKAN AE19 -channel MIPI clock N G2_DA0P AA18 -channel MIPI data 0P G2_DA0N AB18 -channel MIPI data 0N G2_DA1P AC18 -channel MIPI data 1P G2_DA1N AD19 -channel MIPI data 1N G2_DA2P AD20 -channel MIPI data 2P G2_DA2N...
  • Page 8 FMC_SDA I2C data of FMC Part 3: Installation of FMC Module At present, FH9712 module can only be adapted to three development boards: Z7-P, Z19 and Z19-P. The following is the installation diagram of FH9712 module and Z7-P. The images acquired by 16-channel videos are transmitted through PCIE, displayed and analyzed by AI on the computer interface.
  • Page 9 FH9712 User Manual www.alinx.com 9 / 9...
