- Page 1 PROGUARD PROGUARD800 SERIES ™ QUICK INSTALLATION GUIDE ENGLISH 20213 / 20100604 • PROGUARD800 © ALL RIGHTS RESERVED MARMITEK ®...
- Page 3 Short installation manual If you follow the installation procedure mentioned below, you should not hear a siren. Just to be sure, we recommend you to wear hearing protection during the installation. This to prevent hearing impairment. Quick installation of your ProGuard800 set This manual is meant to install your ProGuard800 without having to read the regular installation manual completely.
- Page 4 Drill the holes in the wall and place the enclosed plugs. Place the two screws in the upper holes and let them stick out 5 mm. Hang the panel at these upper screws. Now place the lower two screws, do not tighten them too much. © MARMITEK...
- Page 5 Turning on ProGuard800 for the first time Place the battery in the panel, but do not connect it yet. Put the plug in the socket. Because the tamper contact now is open, the panel immediately generates an alarm warning. The siren is disconnected, so the sound level is very low.
- Page 6 The ProGuard800 has 33 protected zones. Zones 1-32 are meant for wireless sensors. Per zone 1 sensor can be registered. The Marmitek ProGuard800 supports various wireless components like PIR sensors, magnet contacts and smoke detectors. Each zone can be set to be a normal zone, or a zone with an entrance delay, or else.
- Page 7 Press 9 to confirm. Now you will hear a long beep. 10. If you not wish to register any other sensors, press 5 times to leave the programming menu. 11. The DS831 is now registered and is default set with an entrance delay of 30 sec. 12.
- Page 8 MS845 by generating some movement; when the central unit receives a notification from the sensor, it disappears from the list. When all sensors have disappeared from the list, the display shows: End walk test. © MARMITEK...
- Page 9 Placing sensors Placing the DS831 The housing of the DS831 is still open after registering. If you want to mount the housing with screws you have to remove the PCB now. To remove the PCB you push the PCB removal tab and carefully lift it from its holder. Mount the back plate to the doorframe with the enclosed countersunk head screws or double sided foam tape.
- Page 10 Making a call The ProGuard800 can make a call to an emergency centre or any number you choose. In this manual we explain how you can set the ProGuard800 so it will call the number you have chosen. © MARMITEK...
- Page 11 Setting a private number Log in to the programming menu by pressing 9 followed by 1111 (the display now shows: MAIN MENU 1.STOP COMM.). Press 9 (the display now shows: 9.PROGRAMMING 1.DEVICES). Press 5 (the display now shows 5.COMMUNICATIONS 1.ACCOUNTS). Press 9 (the display now shows: 1.ACCOUNTS 1.CS ACCOUNT 1).
- Page 12 The system is armed. Flashing An alarm has occurred. Alarm indication is cleared the next time that an arming sequence is initiated or after the relevant event has been viewed in the event log. Table 3.1: Alarm status indicators -11- © MARMITEK...
- Page 13 The alarm warning does not appear on the display when a panic alarm is triggered. If the Power LED is… a It means… Both AC and Battery power are disconnected. System Power is OK. Flashing (slow) Backup battery low or low battery from transmitters. Flashing (fast) AC loss.
- Page 14 -13- © MARMITEK...
- Page 15 Important default settings User codes You can program up to 32 different user codes in to your ProGuard800 system. A user code has four numbers. For most system functionalities you have to enter your user code. User Code USER 1 MASTER 1234 USER 32 INSTALL.
- Page 16 9 DISABLED 6.PERIPHERALS 9 1.RAPPORTAGE 9 DISABLED d 2.RAPPORT HERST. 9 DISABLED 9 1.RAPPORTAGE 9 DISABLED 7.RF JAMMING d 2.RAPPORT HERST. 9 DISABLED 9 1.RAPPORTAGE 9 ENABLED 8.MEDICAL d 2.RAPPORT HERST. 9 ENABLED d 3.TWO-WAY AUDIO 9 DISABLED -15- © MARMITEK...
- Page 17 Marmitek B.V. Any use of the Content, but without limitation, distribution, reproduction, modification, display or transmission without the prior written consent of Marmitek is strictly prohibited. All copyright and other proprietary notices shall be retained on all reproductions.
- Page 18 -17- © MARMITEK...
- Page 19 ProGuard800™ - 18 -...
- Page 20 ZI0488B (1-09)
