- Page 1 SERIES SERIES IP Eye Anywhere - 10 - 11 - 20 - 21 IP RoboCam - 10 - 11 - 21 ULTRAVIEW Software User Guide 20244 / 20080709 • IP Eye Anywhere™ / IP RoboCam™ ALL RIGHTS RESERVED MARMITEK ©...
-
Page 2: Table Of Contents
Contents INTRODUCTION ............2 INSTALLATION .............3 USING ULTRA VIEW ..........6 ............6 O LAUNCH THE PROGRAM ................7 TEM FEATURES ....12 IP E O ADD A ARMITEK NYWHERE CAMERA .... 15 IP E O REMOVE A ARMITEK NYWHERE CAMERA ......15 O LINK TO THE EB PAGE OF THE CAMERA .............. -
Page 3: Introduction
Ultra View, a customized software application with a user-friendly interface allowing you to access and control your Marmitek IP Eye Anywhere and IP Robocam camera(s). You can connect up to 16 cameras to monitor different places and record events for each camera. With Ultra View, you can also change some basic settings of the camera, such as schedule profiles and motion detecting. -
Page 4: Installation
NSTALLATION Firstly, insert the Installation CD-ROM into the CD drive of your computer to initiate the Auto-Run program. The Auto-Run screen provides the following buttons: z Quick Guide z Advanced Guide z Software Manual z IP Finder z Install Software z Browse z Exit To start installing:... - Page 5 2. On the welcome screen, click Next. 3. Click Browse to select the destination location to install the software; otherwise, leave the default setting and click Next. MARMITEK - 4 -...
- Page 6 4. Click Next again to confirm installation. The setup wizard starts to install the software and the progress bar indicates the installation is proceeding. 5. Installation is completed. Click Close. SOFTWARE USER GUIDE - 5 -...
-
Page 7: Using Ultra View
Programs > UltraView > UltraView, and the main screen will appear as below: NOTE Please set the resolution to 1024x768 or above on your computer while using Ultra View; otherwise, the displayed main screen may be distorted. MARMITEK - 6 -... -
Page 8: Item Features
Item features The following describes the function of each item on the main screen: „ CONTROLS Panel - SETTING: Click to enter the Setting screen of Ultra View. Click again to return to the main screen of Ultra View. - PLAY: Click to play the recorded video file using the media player on the computer (for example, Windows Media Player by default). - Page 9 - View mode buttons: Ultra View provides multiple view modes, including 1/4/9/16 windows and Full screen mode. - SCAN: When you connect multiple Marmitek IP Eye Anywhere or IP Robocam cameras, click this button to display the video views as the main window in turn.
- Page 10 Robocam 21 camera. This button is available only when the connected camera supports 2-way audio function. - LISTEN: Click to receive the on-site sound and voice from the Marmitek IP Eye Anywhere 20, 21 or IP Robocam 21 camera. SOFTWARE USER GUIDE...
- Page 11 „ SYSTEM Panel This panel displays the current date and time. „ PAN-TILT CONTROL Panel (optional) When you connect a pan/tilt Marmitek IP Robocam camera, the system will detect the camera’s function automatically and the PAN-TILT CONTROL buttons will become functional.
- Page 12 Video View Window Camera List - Video View Window: This window displays the video view of the selected Marmitek IP camera, which can be divided into 4/9/16 windows according to your selection in VIEW SELECTION panel. - Camera List: This list displays the information of the connected Marmitek IP camera(s).
-
Page 13: T O Add A Marmitek Ip Eye Anywhere Camera
To add a Marmitek IP camera 1. Click SETTING in the CONTROLS panel to display the Setting screen. 2. Click Add New Camera. MARMITEK - 12 -... - Page 14 3. In the pop-up Add New Camera dialog window, you can: z Select the Search tab if you are not sure of the camera’s IP address. Click Search camera to search the available camera within the network. Once the camera is found and is shown in the list, select it and click Add Camera.
- Page 15 4. Enter the User name and Password for the camera, and then click OK. The connected camera will be displayed in the Camera List. 5. Click SETTING to return to the Video View Window. The video view of the selected camera will be displayed now. MARMITEK - 14 -...
-
Page 16: T O Remove A Marmitek Ip Eye Anywhere Camera
To remove a Marmitek IP camera 1. Click SETTING in the CONTROLS panel to display the Setting screen. 2. Select a camera from the list and click Delete Camera. Select a camera To link to the Web page of the camera Click SETTING >... -
Page 17: To Record Video
Click SETTING > Motion Configuration, and then select the Recording option to enable the selected camera to record by motion detection. z Schedule recording MARMITEK - 16 -... - Page 18 This recording method will work after you have completed the required settings in Schedule Recording Configuration. The recording schedule can be defined by Dates or Days. - Dates: First, select the camera from the pull-down list. Then, click Add to set the Start/Stop date and time and then click OK to add the recording schedule to the list.
-
Page 19: To Configure The Recording Settings
Each Recording File Size: This option allows you to select from 20 to 200 MB so that the video will be recorded as another file automatically when the recording file reaches the specified size limit. MARMITEK - 18 -... - Page 20 z Reserved HDD space for each camera: This option allows you to set to reserve the storage space on the hard disk drive for the recording of each camera. Before setting the reserve space on the hard disk drive, you can check the available storage space that is displayed in the HDD Free space field.
-
Page 21: To Playback The Recorded Video
Select the recorded video file under the [camera] path and then click Open to launch the media player to playback. NOTE If your player on the computer don’t have video codec to playback the recorded video. You can download video codec from http://www.xvid.org/downloads.15.0.html support. MARMITEK - 20 -... -
Page 22: To Set Up Motion Detection Options
To set up motion detection options When the motion detection function of the selected Marmitek IP camera is enabled, you can set the Motion Options by selecting Alarm, Recording, Send e-Mail, and Trigger Out under SETTING > Motion Configuration. z Alarm: Select Beep or Music to alert you for the motion detected. - Page 23 - Password: Enter the password to login the mail server. - Subject: Enter a subject for the notification email. z Trigger Out: If the selected camera supports Trigger Out connector, select this option to enable the Trigger Out function. MARMITEK - 22 -...
-
Page 24: Information
Information Click SETTING > About to display the information of the software application. SOFTWARE USER GUIDE - 23 -...
