Marmitek IP EYE ANYWHERE 21 Advanced Manual

Hide thumbs Also See for IP EYE ANYWHERE 21:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Software User Manual, User Manual
IP EYE
IP EYE
ANYWHERE
™

Network Camera

ADVANCED GUIDE
20240-20080117 • IP Eye Anywhere ™
ALL RIGHTS RESERVED MARMITEK ©

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP EYE ANYWHERE 21 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marmitek IP EYE ANYWHERE 21

Summary of Contents for Marmitek IP EYE ANYWHERE 21

  • Page 1: Network Camera

    IP EYE IP EYE ANYWHERE ™ ANYWHERE Network Camera ADVANCED GUIDE 20240-20080117 • IP Eye Anywhere ™ ALL RIGHTS RESERVED MARMITEK ©...

  • Page 2: P R E F Ac E

    REFACE Thank you for purchasing the Marmitek IP Eye Anywhere Network Camera, a powerful and high-quality image network camera. The camera can be installed as a standalone system within your application environment easily and quickly, and supports remote management function so that you can access and control it using a Web browser on your PC.

  • Page 3: Table Of Contents

    ..................45 LOSSARY OF ERMS IP A 10 ........... 54 ECHNICAL PECIFICATIONS NYWHERE IP A 11 ........... 55 ECHNICAL PECIFICATIONS NYWHERE IP A 20 ........... 56 ECHNICAL PECIFICATIONS NYWHERE IP A 21 ........... 57 ECHNICAL PECIFICATIONS NYWHERE - 2 - MARMITEK...

  • Page 4: C H Ap T E R 1

    1.1 Checking the Package Contents Check the items contained in the package carefully. You should have the following: One Marmitek IP Eye Anywhere Network Camera. One AC Power Adapter. One External Antenna (for IEA11 and IEA21 only). One Camera Stand.

  • Page 5: Getting To Know Your Camera

    USB storage device to the camera. NOTE After pressing the Unmount button for four seconds, the Power LED starts flashing. When the Power LED resumes the steady amber light, you can remove the USB device safely. - 4 - MARMITEK...

  • Page 6: Rear View

    External Antenna* Screw Hole is used to connect the camera stand. Ethernet Cable Connector DC Power Connector is used to connect the is used to connect the network cable, which supports AC power adapter, in the NWay protocol so that the order to supply power camera can detect the Reset Button will restart...

  • Page 7: Features And Benefits

    „ MPEG4/MJPEG Dual-codec Supported* The camera provides you with excellent images by the MPEG4/MJPEG dual-codec selectable technology, allowing you to adjust image size and quality, and bit rate according to the networking environment. „ 1-way Audio Capability* - 6 - MARMITEK...
  • Page 8 The built-in microphone of the camera provides on-the-spot audio via the Internet, allowing you to monitor the on-site voice. „ Supports Multiple Profiles* The camera supports multiple profiles simultaneously, so that you can separately set up different image settings (such as image quality and frame rate) for the three video types of the camera: MPEG4, MJPEG, and 3GPP.

  • Page 9: System Requirement

    9 ~ 16 cameras connected: Intel Pentium 4 3.4GHz; 2GB RAM Resolution: 1024x768 or above NOTE If you connect multiple cameras to monitor various places simultaneously, you are recommended to use a computer with higher performance. - 8 - MARMITEK...

  • Page 10: C H Ap T E R 2

    NSTALLATION 2.1 Installing the Camera Stand The Marmitek IP Eye Anywhere camera comes with a camera stand, which uses a swivel ball screw head to lock to the camera’s screw hole. When the camera stand is attached, you can place the camera anywhere by mounting the camera through the three screw holes located in the base of the camera stand.

  • Page 11: Connecting The Camera To Lan/Wlan

    2.2 Connecting the Camera to LAN/WLAN Use the provided Ethernet cable to connect the Marmitek IP Eye Anywhere camera to your local area network (LAN). When you connect the AC power adapter, the camera is powered on automatically. You can verify the power status from the Power LED on the front panel of the camera.

  • Page 12: Applications Of The Camera

    2.3 Applications of the Camera The Marmitek IP Eye Anywhere camera can be applied in multiple applications, including: „ Monitor local and remote places and objects via Internet or Intranet. „ Capture still images and video clips remotely. „ Upload images or send email messages with the still images attached.

  • Page 13: C H Ap T E R 3

    CCESSING THE AMERA 3.1 Using IPFinder The Marmitek IP Eye Anywhere camera comes with a conveniently utility, IPFinder, which is included in the Installation CD-ROM, allowing you to search the camera on your network easily. 1. Insert the Installation CD-ROM into your computer’s CD-ROM drive to initiate the Auto-Run program.

  • Page 14: Accessing To The Camera

    3.2 Accessing to the Camera Whenever you want to access the Marmitek IP Eye Anywhere camera: 1. Open the Web browser on your computer (for example, Microsoft Internet Explorer in this guide) 2. Type the default IP address (192.168.0.30) or the IP address found by IPFinder in the Address bar, and then press [Enter].

  • Page 15: Camera Information

    & time. The information can be modified in the Web Configuration. „ Live View Image – Displays the real-time image of the connected camera. „ Live View/Setup Switch – Click Setup to configure the camera. For details, see Chapter 4. - 14 - MARMITEK...
  • Page 16 „ Compression Buttons* – Select to transmit and record the video using MPEG4 or MJPEG compression. „ Function Buttons – Use these buttons to control the video functions. z Manual Record allows you to record and save a video clip. z Snapshot allows you to capture and save a still image.

  • Page 17: Configuring The Ip Address Of The Pc

    Use the following IP address option. Then, enter an IP address into the empty field. The suggested IP address 192.168.0.x (x is 0~254 except 30), and the suggested Subnet mask is 255.255.255.0. 7. When you are finished, click OK. - 16 - MARMITEK...

  • Page 18: C H Ap T E R 4

    ONFIGURING THE AMERA 4.1 Using the Web Configuration You can access and manage the Marmitek IP Eye Anywhere camera through the Web browser and the provided software application UltraView. This chapter describes the Web Configuration, and guides you through the configuration of the camera by using the web browser.

  • Page 19: Using Smart Wizard

    4.2 Using Smart Wizard The Marmitek IP Eye Anywhere camera’s Smart Wizard lets you configure your camera easily and quickly. The wizard will guide you through the necessary settings with detailed instructions on each step. To start the wizard, click Smart Wizard in the left menu bar.
  • Page 20 Step 3. Email Settings Enter the required information to be able to send email with image. Step 4. Wireless Networking (Supported by IEA11 and 21 only) Complete the required settings. IP Eye Anywhere - 19 -...
  • Page 21 Apply to finish the wizard and reboot the camera. Otherwise, click Prev to go back to the previous step(s) and change the settings; or click Cancel to end the wizard and discard the changes. - 20 - MARMITEK...

  • Page 22: Basic Setup

    4.3 Basic Setup The Basic menu contains three sub-menus that provide the system settings for the camera, such as the Camera Name, Location, Date & Time, and User management. Basic >> System „ Basic - Camera Name: Enter a descriptive name for the camera. - Location: Enter a descriptive name for the location used by the camera.

  • Page 23: General User

    Function buttons of the camera’s Web Configuration; the “Guest’ can only view the live view image from the main page of the Web Configuration while accessing the camera. Only the “Administrator” is allowed to configure the camera through the Web Configuration. - 22 - MARMITEK...

  • Page 24: Network Settings

    4.4 Network Settings The Network menu contains three sub-menus that provide the network settings for the Marmitek IP Eye Anywhere camera, such as the IP Setting, DDNS Setting, IP Filter, and Wireless network (IEA11 and 21 only). IP Eye Anywhere...
  • Page 25 Once the camera get an IP address from the ISP as starting up, it automatically sends a notification email to you. Therefore, when you select PPPoE as your connecting type, you have to set up the email or DDNS configuration in advance. - 24 - MARMITEK...
  • Page 26 DDNS Setting With the Dynamic DNS feature, you can assign a fixed host and domain name to a dynamic Internet IP address. Select the Enable option to enable this feature. Then, select the Provider from the pull-down list and enter the required information in the Host Name, User Name, and Password boxes.
  • Page 27 SSID to match with the computer’s configuration. Click Site Survey to display the available wireless networks, so that you can easily connect to one of the listed wireless networks. - 26 - MARMITEK...
  • Page 28 List of searching results - Wireless Mode: Select the type of wireless communication for the camera: Infrastructure or Ad-Hoc. - Channel: Select the appropriate channel from the list. - Authentication: Select the authentication method to secure the camera from being used by unauthorized user: Open, Shared- key, WPA-PSK, and WPA2-PSK.
  • Page 29 Pre-Shared Key: This is used to identify each other in the network. Enter the name in the box, and this name must match the Pre-shared key value in the remote device. - 28 - MARMITEK...

  • Page 30: Setting Up Video

    4.5 Setting up Video The Video menu contains two sub-menus that provide the video settings for the camera. IP Eye Anywhere - 29 -...

  • Page 31: Image Setting

    (VGA) obtains better video quality while it uses more resource within your network. - Video Quality: Select the desired image quality from five levels: Lowest, Low, Medium, High, and Highest. - Frame Rate: Select Auto or a proper setting depending on your network status. - 30 - MARMITEK...
  • Page 32 NOTE The IEA 20 and 21 supports both MPEG4 and MJPEG compression. MJPEG capture the images in JPEG format, which require higher bandwidth to view smooth video. The administrator can control the bandwidth of each connection well through the setting options above. „...
  • Page 33 Video & Audio >> Audio „ Camera Microphone In (supported by IEA20 and 21 only) Select the Enable option to enable the camera’s audio function, so that you can receive the on-site sound and voice from the camera. - 32 - MARMITEK...

  • Page 34: Event Server Configuration

    4.6 Event Server Configuration The Event Server menu contains sub-menus that allow you to upload images to FTP, and send emails that include still images. The IEA 20 and 21 can also store the images to a NAS system. When you complete the required settings for FTP, or Email, click Test to test the related configuration is correct or not.
  • Page 35 - Receiver #1 Email Address: Enter the first email address of the user who will receive the email. - Receiver #2 Email Address: Enter the second email address of the user who will receive the email. - 34 - MARMITEK...
  • Page 36 Event Server Setting >> Network Storage* „ Net Storage - Samba Server Address: Enter the IP address of the Network Storage server. - Share: Assign the folder on the Network Storage server to share the files to users. - Path: Assign the path for uploading the files on the Network Storage server.

  • Page 37: Motion Detect

    - Name: Assign a name to the detecting area. - Threshold: Move the slide bar to adjust the level for detecting motion to record video. - 36 - MARMITEK...

  • Page 38: Event Config

    4.8 Event Config The Event Config menu contains four sub-menus that provide the commands to configure event profiles. Event Configuration >> General Setting - Snapshot/Recording Subfolder: You can assign a given sub- folder for captured file. Otherwise, leave this option blank to use the default setting.
  • Page 39 - Time List: Display the time period that you have assigned within the selected weekday. To assign the same time period to every weekday, click Add this to all weekdays; click Delete this from - 38 - MARMITEK...
  • Page 40 Event Configuration >> Schedule Trigger You can separately configure the schedule for trigger function of the Marmitek IP Eye Anywhere camera by Email, or FTP. Select the Enable option on each item, and then select a Schedule Profile from the pull-down list and set the Interval time.

  • Page 41: Tools

    4.9 Tools The Tools menu provides the commands that allow you to restart or reset the Marmitek IP Eye Anywhere camera. You can also backup and restore your configuration, and upgrade the firmware for the camera. - 40 - MARMITEK...

  • Page 42: Factory Reset

    „ Factory Reset Click Reset to restore all factory default settings for the camera. „ System Reboot Click Reboot to restart the camera just like turning the device off and on. The camera configuration will be retained after rebooting. „ Configuration You can save your camera configuration as a backup file on your computer.

  • Page 43: Usb

    4.10 USB* The USB menu provides the information and controls of the connected USB device. - 42 - MARMITEK...
  • Page 44 „ USB Dismount To safely remove the connected USB device, you can press the Unmount button for four seconds on the camera or click Dismount from this item. „ USB Information Display the Total space and Free space of the USB device. „...

  • Page 45: Information

    The Information menu displays the current configuration and events log of the camera. „ Device Info Display the Basic, Video, Network, and Wireless settings of the camera. „ System Log The Logs table displays the events log recorded by the system. - 44 - MARMITEK...

  • Page 46: C H Ap T E R 5

    HAPTER PPENDIX Glossary of Terms NUMBERS 10BASE-T 10BASE-T is Ethernet over UTP Category III, IV, or V unshielded twisted-pair media. 100BASE-TX The two-pair twisted-media implementation of 100BASE-T is called 100BASE-TX. ADPCM Adaptive Differential Pulse Code Modulation, a new technology improved from PCM, which encodes analog sounds to digital form.
  • Page 47 IP addresses. Since domain names are alphabetic, they're easier to remember. The Internet however, is really based on IP addresses every time you use a domain name the DNS will translate the name into - 46 - MARMITEK...
  • Page 48 the corresponding IP address. For example, the domain name www.network_camera.com might translate to 192.167.222.8. Enterprise An enterprise network consists of collections of networks network connected to each other over a geographically dispersed area. The enterprise network serves the needs of a widely distributed company and operates the company’s mission- critical applications.
  • Page 49 IP address is a 32-binary digit number that identifies each sender or receiver of information that is sent in packets across the Internet. For example 80.80.80.69 is an IP address. When you “call” that number, using any connection methods, you get connected to the computer - 48 - MARMITEK...
  • Page 50 that “owns” that IP address. ISP (Internet Service Provider) is a company that maintains a network that is linked to the Internet by way of a dedicated communication line. An ISP offers the use of its dedicated communication lines to companies or individuals who can’t afford the high monthly cost for a direct connection.
  • Page 51 Internet through a common broadband medium, such as DSL or cable modem. All the users over the Ethernet share a common connection. Protocol Communication on the network is governed by sets of rules called protocols. Protocols provide the guidelines - 50 - MARMITEK...
  • Page 52 devices use to communicate with each other, and thus they have different functions. Some protocols are responsible for formatting and presenting and presenting data that will be transferred from file server memory to the file server’s net work adapter Others are responsible for filtering information between networks and forwarding data to its destination.
  • Page 53 IP in the TCP/IP suite User Name The USERNAME is the unique name assigned to each person who has access to the LAN. Utility It is a program that performs a specific task. - 52 - MARMITEK...
  • Page 54 Unshielded twisted-pair. UTP is a form of cable used by all access methods. It consists of several pairs of wires enclosed in an unshielded sheath. Wide-Area Network. A wide-area network consists of groups of interconnected computers that are separated by a wide distance and communicate with each other via common carrier telecommunication techniques.

  • Page 55: Technical Specifications Ip Anywhere 10

    Technical data IP Eye Anywhere 10 Image Sensor Image Sensor 1/4” Color CMOS Sensor Resolution 640 x 480, 320 x 240, 160 x 120 Ligh Minimum Illumination 0.5 LUX Lens Aperture (F/No.) Focus Length 4.6mm 60 degree View Angle(Diagonal) Image Processing Compression MJPEG Auto Exposure Control...

  • Page 56: Technical Specifications Ip Anywhere 11

    Technical data IP Eye Anywhere 11 Image Sensor Image Sensor 1/4” Color CMOS Sensor Resolution 640 x 480, 320 x 240, 160 x 120 Ligh Minimum Illumination 0.5 LUX Lens Aperture (F/No.) Focus Length 4.6mm View Angle(Diagonal) 60 degree Image Processing Compression MJPEG Auto Exposure Control...

  • Page 57: Technical Specifications Ip Anywhere 20

    Technical data IP Eye Anywhere 20 Image Sensor Image Sensor 1/4” Color CMOS Sensor Resolution 640 x 480, 320 x 240, 160 x 120 Ligh Minimum Illumination 0.5 LUX Lens Aperture (F/No.) Focus Length 4.5 mm View Angle(Diagonal) 60 degree Image Processing Compression MPEG4/MJPEG dual streaming...

  • Page 58: Technical Specifications Ip Anywhere 21

    Technical data IP Eye Anywhere 21 Image Sensor Image Sensor 1/4” Color CMOS Sensor Resolution 640 x 480, 320 x 240, 160 x 120 Ligh Minimum Illumination 0.5 LUX Lens Aperture (F/No.) Focus Length 4.5 mm View Angle(Diagonal) 60 degree Image Processing Compression MPEG4/MJPEG dual streaming...
