Summary of Contents for SISCO ETCR7000
-
Page 2: Table Of Contents
CONTENT Precaution For Use ..................1 1. Introduction ....................2 2. Model ......................2 3. Electrical Symbols ..................2 4. Technical Specification ................3 5. Instrument Structure ..................4 6. LCD Display ....................4 7. Operation Method ..................5 7.1. Startup & Shutdown ................. 5 7.2. -
Page 3: Precaution For Use
Precaution For Use Thank you for purchasing our ETCR7000 series Large Caliber Leakage Current Clamp Meter, In order to better for use of the product, please be certain: -- Read this user manual carefully. -- Comply with the operating cautions in this manual. -
Page 4: Introduction
ETCR7000 series Large Caliber Leakage Current Clamp Meter iron core select and make with special alloy, adopts magnetic shielding technology, almost unaffected by the external magnetic field, ensures long time continuous measurement of strong anti-interference ability, ensure high accuracy, high stability and high reliability. -
Page 5: Technical Specification
4. Technical Specification Function Measurement of AC leakage current, current Power Supply DC6V Alkaline dry battery (LR6 1.5VX4PCS) Test Method Clamp CT, integration method 80mmX80mm (an clamp φ80mm cable, or 96mmX4mm CT Size grounding flat steel) 0.00mA~300A: ±1.5%rdg±3dgt Measure Accuracy ℃±... -
Page 6: Instrument Structure
Data Hold Data hold function: “HOLD” symbol display Overflow Display Exceed measure range overflow function: “OL” symbol display Start up for about 5 minutes without operation, backlight automatically shut down; After starting up for about 15 minutes Automatic without any operation. The meter flash screen about 10s and Shutdown automatically shuts down to reduce battery consumption. -
Page 7: Operation Method
6.4. Storage data serial No. 6.5. Current symbol (mA or A) 6.6. Data lock symbol 6.7. Measurement value display 6.9. AC symbol 7. Operation Method 7.1. Startup & Shutdown Press POWER key to start up, LCD display and enter into test mode; Press the POWER key once again to shut down. -
Page 8: Data Delete
data storage, take the longer time to reading. Historical data can be saved in Txt text or Excel format. 7.6. Data Delete At the test mode, press CLEAR key enter into all data delete options, then press “◁ ”or “▷ ” keys to choose “YES”... -
Page 9: Battery Replacement
When testing the current, should try to make the measured conductor in the center of the clamp. If the measured wire deviates from the center of the clamp, the error may increase by 1%~4%. 8. Battery Replacement Warning! The meter cannot test in the situation of the battery cover plate is not covered properly,, otherwise it is dangerous Please pay attention to the polarity of battery, or will damage the leaker. - Page 10 The company is not responsible for other losses caused by use. The contents of this user manual cannot be used as a reason to use the product for special purposes. ETCR reserves the rights to change specifications or designs described in this manual without notice and without obligations.
