SISCO AZSH-200cN Instruction Manual

Digital Tension Meter Instruction Manual
I. Introduction
1.1 Main use and scope of application
Hand-hold digital tension meter is a portable electronic digital measuring instrument that can
measure the tension of filamentous and linear materials. It is widely used in wire and cable, textile
and chemical fiber, metal wire, carbon fiber and other industries. It can accurately measure tension
and systematically process data.
1.2 Product features
1.2.1 Three working modes——Real-time, Hold, and Peak can be switched at will.
1.2.2 cN, gf, OZ, Kgf, N, lb can be set 5000CN range below.
1.1.3 OZ, Kgf, N, lb four units can be set 100N range below.
1.2.3 Accuracy is 2.5% of full scale.
1.2.4 Can accurately measure the tension of 10 different materials.
1.2.5 Has USB communication function.
1.2.6 Has a thickness adjustment function.
1.2.7 Easy to store, and can store 41 sets of data.
II. Product model specifications
Model AZSH-200cN
Tension
4~200.0 （cN） 10~500.0 （cN） 20~1000（cN） 40~2000（cN） 50~2500（cN）
range
* Measuring
head width 65
(mm)
**
Calibration
φ0.12mm
material
textile PA
monofilament
Size (mm)
Net weight
(g)
Power supply
AZSH-500cN AZSH-1000cN
65 65
φ0.12~0.20mm φ0.20~0.40mm φ0.40~0.70mm φ0.40~0.70mm φ0.60~1.20mm φ0.80~1.40mm
AZSH-2000cN AZSH-2500cN
65
270*118*55
About 640g
3.7V lithium battery*2
1
AZSH-5000cN
100~5000
（cN）
116 116
AZSH-100N
2~100N
116
