SPLIT TYPE ROOM AIR CONDITION
OPERATION MANUAL
AS20XCAHRA
AS25XCAHRA
AS35XCAHRA
AS42XCAHRA
AS50XCAHRA
AS71XCAHRA
Please read this operation manual before using the air
conditioner. Keep this operation manual for future reference
This appliance is filled with R32.
ER
AS20XCAHRA-MB
AS25XCAHRA-MB
AS35XCAHRA-MB
AS42XCAHRA-MB
AS50XCAHRA-MB
AS71XCAHRA-MB
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Haier AS20XCAHRA
Summary of Contents for Haier AS20XCAHRA
- Page 1 SPLIT TYPE ROOM AIR CONDITION OPERATION MANUAL AS20XCAHRA AS20XCAHRA-MB AS25XCAHRA AS25XCAHRA-MB AS35XCAHRA AS35XCAHRA-MB AS42XCAHRA AS42XCAHRA-MB AS50XCAHRA AS50XCAHRA-MB AS71XCAHRA AS71XCAHRA-MB Please read this operation manual before using the air conditioner. Keep this operation manual for future reference This appliance is filled with R32.
- Page 3 This appliance contains a UV-C lamp. WARNING: Read the maintenance instructions before opening the appliance. Eye or skin irritation may result from exposure from top air inlet and inner part. During air filter taking and putting for maintenance, please make sure that the power is cut off before approaching the product.
- Page 4 Contents PARTS AND FUNCTIONS OPERATION INDOOR UNIT INSTALLATION MAINTENANCE CAUTIONS TROUBLE SHOOTING...
-
Page 5: Drain Hose
1. QUIET button 2. I FEEL button 3. MODE button Display Inlet 4. HEALTH button QUIET board 5. TEMP+/- button 6. SWING left/right button HEALTH MODE I FEEL Air Purifying Filter AIRFLOW 7. ECOSENSOR button (inside) HEALTH SLEEP TURBO ON/OFF 8. - Page 6 Load the battery or press LOCK Button the"RESET" button LOCK RESET Used to lock buttons and LCD display. Press “ ” or “ ” to LIGHT Button set correct time QUIET LIGH T HEALTH MODE I FEEL QUIET Turn on and off the indoor display. To AIRFLOW HEALTH SLEEP...
-
Page 7: Fan Speed
Mode Note In AUTO mode, the air conditioner will automatically select Cool or Heat operation according to room AUTO temperature. When FAN is set to AUTO, the air con- ditioner automatically adjusts the fan speed accord- ing to room temperature. Unit start COOL Cooling only... - Page 8 Press HEALTH button Press I FEEL button HEALTH 1.For each press, is displayed. 1. Only for COOLING, HEATING or Air conditioner starts health function operation. implemented). 2.Press HEALTH button for twice 2. Place the remote controller within press, disappears, the operation the acceptable range of air condi- stops.
- Page 9 Temp. setting Unit stop Before going to bed, you can simply 1 hr Decreases 2 º press the SLEEP button and unit will operate in SLEEP mode and bring you a 1 hr sound sleep. Decreases 2 º 3 hrs Press SLEEP button SLEEP 3 hrs...
- Page 10 Press QUIET button QUIET Set health airflow function HEALTH AIRFLOW You can use this function when silence is 1.Press the button of HEALTH AIR- needed for rest or reading. FLOW, appears on the display. For each press, is displayed. Air Avoid the strong airflow blowing conditioner starts QUIET function oper- direct to the body.
- Page 11 Up and down air flow direction The purpose of this function is to clean the evaporator. SELF CLEAN For each press of the button, air If this function is needed, please select flow direction on remote controller in the hOn APP. displays as follows according to Press SELF CLEAN button to enter this different operation modes:...
- Page 12 Set Clock correctly before starting Timer operation. You can let unit start or stop ECOSENSOR Press ECO SENSOR button automatically at the following times: Before you wake up in the morning, For each press,changes as follows: get back from outside or after you fall cancel asleep at night.
- Page 13 The system architecture diagram Control Interaction Use this operation only when the remote controller is defective or Query lost, and with function of emergency running, air conditioner can run Service automatically for a while. Remind When the emergency operation switch is pressed, the "Pi" sound is heard once, which means the start of this operation.
- Page 14 Remove the battery cover; Introduction to Steri Clean Stage 1 - Self Clean: to remove dirt away. This function freezes the evaporator with moisture in the air, and removes dirt during the melting process.The hydrophilic aluminium coating with smaller Load the batteries as illustrated. 2 R-03 batter- helps increase water drainage efficiency.
-
Page 15: Disposal Requirements
IMPORTANT INFORMATION REGA- EUROPEAN REGULATIONS RDING THE REFRIGERANT USED CONFORMITY FOR THE MODELS Contains fluorinated greenhouse gases Climate:T1 Voltage:2 All the products are in conformity with the following European provision: - 2014/53/EU(RED) 1+2= - 2014/517/EU(F-GAS) This product contains fluorinated greenhouse gases . Do not vent - 2009/125/EC(ENERGY) into the atmosphere. -
Page 16: Indoor Unit Installation
Indoor Unit Installation Necessary Tools for Installation Power Source Torque wrench Driver Before inserting power into receptacle, check the voltage without (17mm,22mm,26mm) Nipper fail. Pipe cutter Hacksaw The power supply is the same as the corresponding nameplate. Flaring tool Hole core drill Install an exclusive branch circuit of the power. - Page 17 Indoor Unit Installation [ Left Left-rear piping ] Fitting of the Mounting Plate and Positioning of the wall Hole In case of left side piping, cut away, with a nipper, the lid for left piping. When the mounting plate is first fixed In case of left-rear piping, bend the pipes according to the piping direction to the mark of hole for left-rear piping which is marked on proper leveling...
- Page 18 Whe n connec ting the cable, the term inal number of indo or and out door units carefully. If wir ing i s not correct , proper opera tion ca n not be carried out and will cause defect.
- Page 20 Esay maintenance (Ask your dealer or qualified personnel to carry out installation work.)
-
Page 22: Troubleshooting
30 seconds later, cutting off the power. Are there too much heat sources or too many people in the room during cooling operation? Address:Haier Industrial Park, Haier Road, Hi-Technology Zone, Qingdao City, Shandong Province, P.R. China Contacts: TEL +86-532-8893-7937 Website: www.haierhvac.eu...
