8653196WCOM
End Table/Coffee Table/TV Console
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B348653196WCOM00KX
Easy
Assembly Difficulty Meter
People needed for assembly: 2
Follow Ameriwood Home
You
Tube
Tough

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8653196WCOM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mainstays 8653196WCOM

Summary of Contents for Mainstays 8653196WCOM

  • Page 1 8653196WCOM End Table/Coffee Table/TV Console Date of Purchase ___ / ___ / ___ B348653196WCOM00KX Lot Number: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Call us! 1-800-489-3351 Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 - Open your item in the area you plan to keep it to avoid excessive heavy lifting. - Identify, sort and count the parts before attempting assembly.

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: #2 Phillips Head Screwdriver Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.

  • Page 4: Board Identification

    Board Identification Not Actual Size Table Leg Frame End Table Panel End Table Shelf T8653196010KX T8653196020KX T8653196030KX Coffee Table Coffee Table Coffee Table Top Shelf Support Tube Panel T8653196050KX T8653196060KX T8653196040KX Coffee Table Console Top Panel Console Leg Frame Support Foot T8653196090KX T8653196080KX T8653196070KX...
  • Page 5 Board Identification Not Actual Size Console Top Console Shelf Console Back Panel Support Tube T8653196100KX T8653196110KX T8653196120KX Console Middle Console Support Support Tube Foot T8653196130KX T8653196140KX ameriwoodhome.com Tube...
  • Page 6 Board Identification Not Actual Size Set of 2 End Tables ameriwoodhome.com Tube...
  • Page 7 Board Identification Not Actual Size Coffee Table ameriwoodhome.com Tube...
  • Page 8 Board Identification Not Actual Size TV Console ameriwoodhome.com Tube...

  • Page 9: Part List

    Part List For any replacement hardware, order Hardware Bag Number: 28653196WCOM0KX Set of 2 End Tables Coffee Table Console Table Actual Size: Actual Size: Actual Size: M7X 50 mm M7X 50 mm M7X 50 mm × 16 × 8 × 12 Bolt Bolt Bolt...
  • Page 10 STEP 1 - End Table (set of 2) × 16 End Table Assembly: Each panel is reversible. Select either the black or accent finish and position the End Table Panel (B) and End Table Shelf (C) so that the preferred side will be visible. Connect to the Table Leg Frames (A) using eight Bolts (1), as illustrated.
  • Page 11 STEP 2 - Coffee Table Coffee Table Assembly: Each panel is reversible. Select either the black or accent finish and position Coffee Table Shelf (E) so that the preferred side touches Coffee Table Support Tube (F). Insert the threading of Coffee Table Support Foot (G) and attach as illustrated. Secure by turning clockwise and hand tightening.
  • Page 12 STEP 3 - Coffee Table × 08 Each panel is reversible. Select either the black or accent finish for the top surface. Attach Table Leg Frames (A) to Coffee Table Top Panel (D) and Coffee Table Shelf (E) using eight Bolts (1) as illustrated. Customize the appearance of your Coffee table.
  • Page 13 STEP 4 - TV Console TV Console Assembly: Each panel is reversible. Select either the black or accent finish and position so that the preferred surface of Console Shelf (J) touches Console Top Support Tube (L). Insert the threading of Console Middle Support Tube (M) and attach as illustrated. To secure, hand tighten by turning TV Console Middle Support Tube (M) clockwise.
  • Page 14 STEP 5 - TV Console Each panel is reversible. Ensure that the preferred side of the lower Console Shelf (J) is positioned facing Console Middle Support Tube (M). Connect Console Support Foot (N) through Console Shelf (J) and attach as illustrated. Hand tighten by turning clockwise. Back Back Suction cup...
  • Page 15 STEP 6 - TV Console × 08 Attach Console Leg Frames (H) to Console Shelves (J) using eight Bolts (1), four on each side. Back Back Suction cup Back ameriwoodhome.com Tube...
  • Page 16 STEP 7 - TV Console × 04 With two people, turn the TV Console upright. Attach Top Panel (I) by inserting four Bolts (1) through Console Leg Frames (H) as illustrated. Suction cup Back Back Customize the appearance of your TV Console. The accent and black finishes of the top serve as reversible boards.
  • Page 17 STEP 8 - TV Console × 6 With two people, carefully turn the unit over to lay on its front side, exposing the predrilled holes in the backs of the shelves. Each Console Back Panel (K) is reversible. Position these so that the preferred finish faces the interior of the console.
  • Page 18 STEP 9 - TV Console WARNING Risk of death or serious injury. This unit must be placed against a fixed in place wall at least as tall as television. × 1 Please apply the TV Warning Label (4) to the Top (H) in a visible location. This label is a reminder of the maximum weight this product can support.
  • Page 19 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. Coffee Table End Tables Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
  • Page 20 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. WARNING ADVERTENCIA AVERTISSEMENT Certificate of Conformity 1. This certificate applies to the Dorel Home Furnishings, Inc. product identified by this instruction manual. 2.
  • Page 21 Register your product to receive the following: * New trend details - sneak peek on what's new * Surveys - have a voice within our community * Exclusive deals and discount codes * Quick and easy replacement part service To register your product, visit ameriwoodhome.com Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You"...
  • Page 22 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
  • Page 23 Español Lista de Piezas (Página 9) Identificación de los Paneles (Página 4-8) Este no es el tamaño real Este no es el tamaño real Tamaño real (A) MARCO DE LA PATA DE LA MESA (4) Etiqueta de advertencia (1) Cerrojo (B) PANEL DE MESA AUXILIAR (2) Tornillo (C) ESTANTE DE LA MESA AUXILIAR...
  • Page 24 Español Página 13 Conjunto de consola de TV: Cada panel es reversible. Seleccione el acabado negro o acentuado y colóquelo de manera que la superficie preferida del estante de la consola (J) toque el tubo de soporte superior de la consola (L). Inserte la rosca del tubo de soporte medio de la consola (M) y fíjelo como se ilustra.
  • Page 25 Español Página 19 CARGA MAXIMA Esta unidad ha sido diseñada para soportar la carga máxima anotada. El exceder estos límites puede causar inestabilidad, colapsarse y/o causar serias lesiones. ADVERTENCIA: Riesgo de lesiones a las personas - no coloque un televisor sobre muebles. Este mueble no está...
  • Page 26 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) - Visitez: www.ameriwoodhome.com ATTENTION Le meuble peut basculer et causer des blessures graves ou la mort.
  • Page 27 Français Identification des matériaux Liste des pièces (Page 9) (Page 4-8) Pas de taille réelle Taille réelle Pas de taille réelle (A) CADRE DU PIED DE TABLE (1) Boulon (4) Étiquette d'avertissement (B) PANNEAU DE TABLE DE BOUT (2) Vis (C) TABLETTE DE TABLE DE BOUT (3) Clé...
  • Page 28 Français Page 13 Assemblage de la console TV : chaque panneau est réversible. Sélectionnez la finition noire ou accentuée et positionnez-la de manière à ce que la surface préférée de l'étagère de la console (J) touche le tube de support supérieur de la console (L). Insérez le filetage du tube de support central de la console (M) et fixez-le comme illustré.
  • Page 29 Français Page 19 CHARGES MAXIMALES Ce meuble a été conçu pour supporter les charges maximales indiquées. En excédant ces limites de charge, le meuble pourrait devenir instable, s'effondrer, et/ou causer des blessures graves. AVERTISSEMENT : Risque de blessure corporelle - ne pas placer une télévision sur ce meuble. Ce meuble n'est pas approuvé...
