Delta Electronics Delphi Q48DV Datasheet

Delphi Series Q48DV, 40W Quarter Brick,
Dual Output DC/DC Power Modules
The Delphi Series Q48DV Quarter Brick, 48V input, dual output,
isolated DC/DC converters are the latest offering from a world leader in
power systems technology and manufacturing -- Delta Electronics, Inc.
This product family provides dual regulated outputs with a flexible
combination of output current and power up to 40W in a very cost
effective industry standard footprint. With creative design technology
and optimization of component placement, these converters possess
outstanding electrical and thermal performance, as well as extremely
high reliability under highly stressful operating conditions. All models
are fully protected from abnormal input/output voltage, current, and
temperature conditions. The Delphi Series Q48DV converters meet all
safety requirements with basic insulation.
DATABRIEF
DB_Q48DV_07172006
1
FEATURES
High efficiency: 86% @ 1.5V/8A, 3.3V/6A
Low profile: 2.28"×1.45"×0.33"
Flexible current allocation on each output
Low voltage output (O/P 1) starts up first
Fixed frequency operation
Input UVLO, Output OCP, OVP, OTP
Basic insulation
No minimum load required
ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing
facility
UL/cUL 60950 (US & Canada), TUV
(EN60950) and CE mark pending
OPTIONS
Positive On/Off logic
Short pin lengths
Heatsink available for extended
operation
APPLICATIONS
Telecom/DataCom
Wireless networks
Optical network equipment
Server and data storage
Industrial/Test Equipment
Delta Electronics, Inc.
