SURFACE MOUNT FRAME
EAN
l x w x h [mm]
IP
Compatible units
(°C)
• MCU SELECT DALI-2
• MCU SELECT DALI-2 TW
• MCU SELECT DALI-2 EXC TW
SURFACE MOUNT FRAME
4058075843561
80 x 80 x 42
20
0...+50
• MCU TOUCH DALI-2
• MCU TOUCH DALI-2 TW
• MCU SELECT DIRECT 100-240 TW RGB ZB
Advertisement
Related Manuals for Ledvance SURFACE MOUNT FRAME
Summary of Contents for Ledvance SURFACE MOUNT FRAME
- Page 1 SURFACE MOUNT FRAME l x w x h [mm] Compatible units (°C) • MCU SELECT DALI-2 • MCU SELECT DALI-2 TW • MCU SELECT DALI-2 EXC TW SURFACE MOUNT FRAME 4058075843561 80 x 80 x 42 0...+50 • MCU TOUCH DALI-2 •...
- Page 2 SURFACE MOUNT FRAME Mounting / Montage Installation...
- Page 3 SURFACE MOUNT FRAME Device mounting / Geräte-Montage 3. Insert fixation screws 1. Insert at 45° orientation 2. Rotate by 45° (short wall elements of MCU hou- (until long wall elements of sing parallel to the fixation noses of MCU housing are parallel...
- Page 4 MCU estén en paralelo a las lengüetas de fijación del marco de la superficie); s upevňovacími držiakmi povrchového rámu); 6) Vložte upevňovacie skrutky; 7) Nasaďte kryt 6) Introducir los tornillos de fijación; 7) Fijar la cubierta del dispositivo zariadenia Asistencia técnica: www.ledvance.com Technická podpora: www.ledvance.com ...
