- Page 1 LED DRIVER DR EXT DALI-P l x w x h [mm] (°C) V AC DR EXT DALI-P-1x15-37W 220-240 4058075730632 286 x 31 x 21 15 - 37 < 0.21 -20...+50 220-240 V 0/50-60 DR EXT DALI-P-2x15-26W 220-240 4058075730656 360 x 31 x 21 2x15-26 <...
- Page 2 Guide ext-system Anleitung The LEDVANCE DR EXT DALI driver hereafter referred to as DRIVER EXT is designed to power below stated LEDVANCE LEDTUBE EXT. LEDTUBE T5 EXT HE35 P 1449 18W 840 LEDV EAN10: 4058075730519 LEDTUBE T5 EXT HE35 P 1449 18W 865 LEDV...
-
Page 3: Current Setting
DRIVER EXT. It is not allowed to operate the LED TUBE EXTERNAL outside the specified operation current. Current setting at DR EXT DALI-P-1x15-37W 220-240 - EAN10: 4058075730632 picture only for reference, valid print on product... -
Page 4: Installation
LED DRIVER DR EXT DALI-P Dimensions DR EXT DALI-P-1x15-37W 220-240 DR EXT DALI-P-2x15-26W 220-240 2. INSTALLATION Installation must be executed by a qualified electrician. All wires need to be approved for the existing voltages and protection classes. Hot plug in/out of the LED TUBE is not allowed. Do not use DALI and PUSH DIM application at the same time. - Page 5 After rewiring, only LED TUBE EXT can be used in this luminaire. The use of traditional fluorescent tubes or other LEDTUBEs is not permitted anymore. LEDVANCE does not accept any responsibility, warranty or liability when us- ing other types of light sources.
-
Page 6: Technical Table
Treibern betrieben wird, die nicht für die LED TUBE EXT non progettati per LED TUBE EXT. LEDVANCE non si assume alcuna responsa- bilità legale e di altro genere in caso di utilizzo di altri driver LED. LEDVANCE non entwickelt wurden. LEDVANCE übernimmt keine Verantwortung, Garantie oder può... - Page 7 LEDVANCE LEDTUBE EXT. voor gebruik door de dip-schakelaar op de DRIVER EXT. Het is niet toegestaan 2) A LEDVANCE não pode garantir o desempenho do LED TUBE EXT, quando ali- om de LED TUBE EXTERNAL te bedienen buiten de gespecificeerde werkstroom.
- Page 8 ON/OFF-versjon. LED TUBE EXT er en ensidig LED TUBE, og må 2) Podjetje LEDVANCE ne more jamčiti za delovanje LED TUBE EXT, če se napa- kun kobles til (kables) på den aktive siden (merket med «DC input»). «DC in- ja z različnimi gonilniki, ki niso zasnovani za LED TUBE EXT.
