Ledvance SYLVANIA LEDlescent LED T8 Installation Manual

www.ledvanceUS.com
SYLVANIA Lamps
Installation Guide –LEDlescent
UL Type B Lamps
LED T8, AC Line Voltage, ballast-free lamps for use in fixtures where fluorescent lamps are used.
For warranty coverage, please register at www.ledvanceUS.com/warrantyregistration.
PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus complies with Canadian ICES-005.
www.ledvanceUS.com/fccpart15b
Parts/Components included:
• Installation Manual
• UL Type B - LED T8 Lamps
• Luminaire marking labels to be affixed to each luminaire when installing these lamps and
shall be visible by the end user during re-lamping.
The products covered in this report are intended to retrofit surface mount, Type IC or non-IC
recessed mount Listed fluorescent luminaires that use maximum 4 tubular lamps, the minimum
lamp compartment dimensions are tabulated below:
Model
LED9T8L24FG8XXBFG2
LED12T8L36FG8XXBFG2
LED9.5T8L48FG8XXBFG2
LED12T8L48FG8XXBFG2
LED15T8L48FGDIM8XXBFG2
4092469-1
LED T8
TM
MINIMUM LAMP COMPARTMENT
DIMENSIONS
[Length X Width X Height] [cm]
65.44 X 56 X 7.5
95.91 X 56 X 7.5
126.28X 56 X 7.5
126.28X 56 X 7.5
126.28X 56 X 7.5
Maximum
Lamp
Quantity
4
4
4
4
4
