Gefen CAT5-9000I Specifications

The ex•tend•it CAT5•9000I extends VGA, PS/2, USB, RS-232 and audio up to
330 feet.

How it works

The CAT5•9000I sender sits next to your computer. Cables supplied with the
CAT5•9000I connect your CPU to the sender. The CAT5•9000I receiver sits
next to the monitors, keyboard/mouse, RS232 and audio devices - up to 330
feet away. Monitors, keyboard, mouse, audio and RS232 plug into the back of
the receiver. Three CAT-5 extension cables connect the CAT5•9000I send and
the CAT5•9000I receive unit to each other.
The CAT5•9000I uses "Extreme USB" technology.

Package Includes:

CAT5•9000IS Sender Unit
CAT5•9000IR Receiver Unit
One 6ft VGA cables
One 6ft USB cable
Two PS/2 (m-m) cables
One 6ft Audio cable
Two 5 VDC power supply

Features:

• Saves money on cable and hardware costs
• Saves space on your desktop
• Convenient, flexible and expandable
• Eliminates computer noise where you work
• Maintain high resolution video
• Supports any type of CRT or LCD analog monitor
• USB supports high powered 4 port HUB
• Ideal for Mac or PC computers using USB or RS232 peripherals
• Extends two audio outputs for multimedia applications
• Extends RS-232 tablets & touchscreens
• Rackmountable

Specifications:

• Video Amplifier Bandwidth: 350 MHz
• Actual Bandwidth: 120 MHz
• Input Video Signal: 1.2 Volts p-p
• Horizontal Frequency Range: 15-70 KHz
• Vertical Frequency Range: 30-170 Hz
• Focus Adjustment: Internal
• Brightness Adjustment: Adjustable
• CAT-5 Connector: RJ-45
