Summary of Contents for PCE Instruments PCE-VE 200-KIT2
- Page 1 USER MANUAL BORESCOPE PCE-VE 200 User manuals in various languages (français, italiano, español, português, nederlands, türk, polski) can be found via our product search on: www.pce-instruments.com...
-
Page 2: Safety Notes
Please read this manual carefully and completely before you use the device for the first time. The device may only be used by qualified personnel and repaired by PCE Instruments personnel. There is no warranty of damages or injuries caused by non-observance of the manual. -
Page 3: Specifications
SPECIFICATIONS Console Display 3.5” TFT LCD Video resolution AVI (640 x 480) Image resolution JPEG (1600 x 1200) Image rotation 180 ° rotation / mirror image Freeze frame Possible Zoom 4 x variable digital zoom Menu languages English, Simplified Chinese, French, German, Spanish, Japanese, Russian Interface Micro USB 2.0 / TV out / card slot... - Page 4 Insertion probe further versions PCE-VE 200 –S PCE-VE 200 –S3 PCE-VE 200 –SV1 PCE-VE 200 –SV3 Cable length Diameter 3.7 mm 3.7 mm 9 mm 9 mm Camera Front Front Front / side Front / side * To switch the camera from front to side, use the control handle at the camera cable. Environmental conditions Operating temperature Operating temperature...
-
Page 5: System Description
SYSTEM DESCRIPTION Power on / off Down / image rotation Setting Preview / playback Video recording Photo taking LED at tip of cable Zoom Frame freeze LED at console Tripod thread Battery cover screw Probe Startup / shutdown indicator Charging indicator Micro SD card slot TV out 20 Micro USB interface... - Page 6 INSTRUCTIONS How to insert the micro SD card » Remove the dust cover at the right side and insert the micro SD card. » Please use a C4 micro SD card or above and make sure you format the card before use. To do so, connect the device with a computer or laptop, using the USB cable that comes with the device.
-
Page 7: Troubleshooting
Charging Charging via a 230 V outlet: » Use the included mains adaptor / USB cable and connect it to a power outlet Charging per USB » Use the USB cable and connect it to a computer or power bank. »... - Page 8 We either re-use them or give them to a recycling company which disposes of the devices in line with law. For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. PCE INSTRUMENTS CONTACT INFORMATION...
