Summary of Contents for PCE Instruments PCE-LRF 500
- Page 1 User Manual PCE-LRF 500 Laser Distance Meter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 6 January 2021 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Getting started ..................4 Operation ....................5 Measurement information ....................5 Distance measurement ....................5 Continuous measurement ....................5 Mast measurement ......................5 Distance measurement in fog ................... 6 Speed measurement ......................6 Warranty ....................6 Disposal ....................6 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Specifications
Weight approx. 175 g Dimensions 106 x 82 x 40 mm Delivery scope 1 x laser distance meter PCE-LRF 500 1 x carrying strap 2 x 1.5 V AAA battery 1 x microfibre cloth 1 x user manual © PCE Instruments... -
Page 5: System Description
System description Device description ① ON key ⑤ Eyepiece with dioptre adjustment ② MODE key ⑥ Battery compartment ③ Lens / laser output ⑦ Tripod thread ④ Laser input © PCE Instruments... -
Page 6: Display Description
Measurement mode mast Angle measurement * Attention: The measuring modes marked with "*" are not available with the PCE-LRF 500. Getting started Open the battery compartment on the bottom side of the unit and insert two 1.5 V AAA batteries in the correct position. -
Page 7: Operation
Keep the "ON" key pressed during the measurement. • “SCAN" flashes in the display to confirm the continuous measurement. • Move the mast to the right and left in the viewfinder a few times. • Read the measurement result. © PCE Instruments... -
Page 8: Distance Measurement In Fog
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 9 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
