- Page 1 SG-114 中文 Version 1...
- Page 2 VERY IMPORTANT PLEASE READ Sangean suggest that you keep your AC Adapter at least 12 inches away from the radio while listening to the AM Band. Your Sangean Radio is powered by an AC adapter which is a “switching” or “switch-mode” type.
- Page 3 AC Adapter are stated on the final page of the manual, or please contact Sangean for the correct AC Adapter and specifications. For customers in the US and Canada, please call 562-941-9900 or 888-726-4326. For all other areas, please contact us via contact@sangean.com...
- Page 4 Controls Top view Speaker Band button Preset button HD Seek / APS button Alarm 1 button Alarm 2 button Tuning up / down / Snooze button Alarm 3 button Front view Nap timer button Sleep timer button Info / Menu button Select button Power button Right view...
-
Page 5: Using The Ac Power Adaptor
Using the AC power adaptor The AC power adaptor required for this unit should be 6 volts DC at 2A center pin positive. Insert the adaptor plug into the DC socket on the rear of the radio. Plug the adaptor into a standard AC outlet. -
Page 6: Setting The Clock Manually
Setting the clock manually When choosing manual setting as the clock time setting of your radio, the “RBDS Auto CT” function will be disabled. Press and hold the Menu button to enter the menu setting and then press the Tuning up / down button to select “Clock”. -
Page 7: Manual Tuning - Fm / Am
Tuning region Your radio can be configured for any one of the four international tuning regions. Press the Power button to switch on your radio. Press the Band button to select your required frequency band. Press and hold the Menu button to enter the menu setting and then press the Tuning up / down button to select “Region”. -
Page 8: Presetting Stations
Presetting stations There are 20 presets each for FM and AM radio. They are used the same way for each operating mode. Press the Power button to switch on your radio. Tune to the required radio station as previously described. To store the station as a preset, press and hold the Preset button and then press Tuning up / down button to select the required preset number. - Page 9 Receiving HD Radio stations When the radio is tuned to an HD Radio station, the HD Radio logo will flash in the display, indicating that the signal is blending from analog to digital. Once the receiver acquires the HD Radio signal, the HD Radio logo will remain solid on the screen.
- Page 10 Emergency alert (EA) Emergency Alerts (EA) is a warning system used by broadcasters to notify listeners about potential hazardous situations related to extreme weather, floods, and infrastructure failures, amber alerts (child abductions), and more. Your Radio must be in a location that allows for adequate reception of audio and data services and tuned to a station that provides the Emergency Alerts.
- Page 11 If Zip was selected: The first digit of your US Zip code will flash on the display. Press the Tuning up / down button to select the desired digit and press the Select button to cause the next digit to flash on the display. Continue to change all the digits in your Zip code.
-
Page 12: Display Options
Indicators for Emergency alerts Your radio may display various EA indicators on the display. Emergency Alerts indicator Emergency Alerts feature is disabled Exclamation mark (!) Symbol (a) Current station supports Emergency Alerts Symbol (i) Emergency Alerts message “ignored” Symbol (s) Emergency Alerts message “snoozed”... -
Page 13: Setting The Alarm Clock
b. HD Radio status Press and release the Info button to cycle through the various options. Plus (+) indicator: additional HD Radio stations are available Current station supports Multicast set index Emergency Alerts HD Radio indicator Time Station name Preset number Frequency band Station frequency Date... -
Page 14: When The Alarm Sounds
Press the Tuning up / down button to select “On” or “Off”. If “Off” is selected any current setting for that alarm will be cancelled. With “On” selected, press and release the Select button to enter the “A1 time” (for example) setting. The alarm hour digits will flash on the display. Press the Tuning up / down button to choose the desired hour for the alarm and press the Select button to cause the minute digits to flash on the display. -
Page 15: Sleep Timer
Disabling / canceling alarm setting To cancel the alarm setting before the alarm sounds, press and release the corresponding alarm button to select “Off”. The alarm indicator will disappear from the screen and the chosen alarm will now be disabled. Snooze The buzzer or radio alarm can be silenced for 5 minutes by pressing tuning up / down button. -
Page 16: Dimmer Control
Dimmer control The brightness of the display may be adjusted. Press and hold the Menu button to enter the menu setting. To adjust the brightness level of the LCD display when the radio is in power on mode or standby mode, press the Tuning up / down button to select “Power On Dimmer”... -
Page 17: Auxiliary Input Socket
Auxiliary input socket A 3.5mm Auxiliary input socket is provided on the right hand side of your radio to permit an audio signal to be fed into the unit from an external audio device such as an iPod, MP3 or CD player. Press the Power button to switch on your radio. -
Page 18: Charging With Usb Socket
Charging with USB socket Your radio has a USB socket which is intended for charging an iPhone, smart phone or similar devices. Charge time may vary and in some cases may take longer to charge than when using the manufacturers charging unit supplied with the smart phone. The radio can charge the iPhone, smart phone or similar devices when the radio is in power on or standby mode. -
Page 19: Specifications
Production year Product code Sangean reserves the right to amend the specifications without notice. If at any time in the future you should need to dispose of this product please note that: Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
