- Page 1 B AT TE RY C H AR G E R TE CH NI C AL M A NU AL M O D E L : U Y 9 0 0 - H M 6 0 1 0 - 1 V E R S I O N : V 1 . 0...
-
Page 2: Table Of Contents
Battery Charger Technical Manual Contents Revised History ............................１ Warning ..............................１ Notes ................................ １ Product Number System ........................２ Product Weight And Appearance ......................２ Indicator LEDs ............................３ Electronic Characteristics ........................３ Protect Characteristics .......................... ４ Output Over Voltage Protection ....................４ Output Over Current Protection .................... -
Page 3: Revised History
Battery Charger Technical Manual 1. Revised History Table 1. Revised History Version Detail Date V1.0 03/25/2014 The initial version Remark: This table will be updated for product upgrade. Users can download the latest version of the product technical manual at www.gdyunyang.com. 2. -
Page 4: Product Number System
Battery Type. F: 3.65V/cell. M: 4.2V/cell. A: For lead acid battery. Input voltage range. W: 100~240Vac. H: 200~240Vac. L: 100~120Vac, UY900 series charger 5. Product Weight And Appearance UY900 series charger is about 3kg without input AC wire. Charger appearance as figure 1 below. Size: 220mm×135mm×70mm Figure 1. Appearance... -
Page 5: Indicator Leds
Battery Charger Technical Manual 6. Indicator LEDs Green: Charge complete, standby Red: Charging 7. Electronic Characteristics Table 3. Electronic characteristics Item Unit Min. Typ. Max. Remark Input voltage Input power Constant charge 71.1 71.4 71.7 voltage Float voltage(for lead acid battery only) Constant charge 10.3... -
Page 6: Protect Characteristics
Battery Charger Technical Manual 8. Protect Characteristics 8.1 Output Over Voltage Protection When the charger output voltage exceeds the maximum charging voltage, the charger enters the standby state protection. Troubleshooting can be automatically restored to normal working condition. 8.2 Output Over Current Protection When the charger output current exceeds the maximum charging current, the charger enters the over current protection status. -
Page 7: Reliability
Battery Charger Technical Manual Reliability Table 4. Reliability Item Description Remark average operating life ≥ 30000h MTBF 25℃ Anti-vibration 5mm/50Hz/600s vibration test PASS Safety Insulation Characteristics 11.1 Table 5. Insulation characteristics DC500V 50MΩmin (25℃, Humidity≤70%) Input to output Insulation DC500V 50MΩmin (25℃, Humidity≤70%) Input to case resistant DC500V 50MΩmin (25℃, Humidity≤70%)
