Thanks for choosing our ESD24M-IP65 EXIT products.
We strongly recommend that you read this manual carefully before installation.
Product Specifications
MAX POWER
PRODUCT
CONSUMPTION
CODE
( WHEN CHARGING )
ESD24M-IP65
4.5W
Installation Instructions
1
Switch-off main power.
Remove screws on both sides to
3
open up the fitting.
HANECO VANDAL PROOF LED EXIT
ESODO
IP
IK
RATING
RATING
IP65
10
2
Choose the direction of installation.
Straight
4
Knock out the cable entry on the side.
For more information
www.haneco.com.au
1300 001 LED (533)
INPUT
OPERATING
RATING
TEMPERATURE
220 – 240Va.c.
0-45°
50/60Hz
Right
ELECTRICAL
EM
CLASSIFICATION
TIME
Class II
>1.5hr
Left
