HANECO LIGHTING EMERGENCY LED EXIT SURFACE MOUNTED
Thanks for choosing our ESD24M-SMT EMERGENCY EXIT products.
We strongly recommend that you read this manual carefully before installation.
Product Specifications
Max power
Product Code
consumption
when charging
ESD24M-SM
Ceiling Mount
1. Switch-off main power
2. Choose the direction of installation
3. Change the pictogram if necessary
LIGHT FITTING INSTALLATION GUIDE
ESODO 24M SURFACE MOUNT
IP Rating
4W
IP20
For more information
For more information
www.haneco.com.au
www.haneco.com.au
Operating
Input Rating
Temperature
220 – 240V AC
0-45°
50/60Hz
(08) 8297 6373
(08) 8297 6373
Electrical
EM Time
Classification
Class II
>2hr
