thomann 605808 Assembly Instructions Manual

Overview
* .
)
+
ö
$
( /
Assembly material
A B
88 ×
G H
M6×10 26 ×
M N
4 ×
- *
'
'
&
%
(
C
54 ×
I
8 ×
O
2 ×
M6×16
Sturdy and ergonomic work table for recording and production
ƒ
studios with two integrated 19" racks with 2 RU
Stepless rack strips
ƒ
Cable holder under the worktop and on the sides
ƒ
PET absorber can be mounted under the worktop
ƒ
PET strips on the sides
ƒ
Material: Chipboard (25 mm, 18 mm), melamine-coated
ƒ
Colour: Black (item no. 605808), oak (item no. 605637)
ƒ
Total dimensions (W × H × D):
ƒ
2,600 mm × 940 mm × 1,025 mm
Dimensions of left/right monitor shelf (W × H × D):
ƒ
570 mm × 18 mm × 410 mm
Dimensions of front worktop (W × H × D):
ƒ
1,243 mm × 25 mm × 406 mm
Dimensions of rear worktop (W × H × D):
ƒ
1,502 mm × 25 mm × 483 mm
Dimensions of worktop left/right (W × H × D):
ƒ
552 mm × 25 mm × 419 mm
Max. load capacity of monitor shelf: 35 kg each
ƒ
Max. load capacity of front worktop: 30 kg
ƒ
Max. load capacity of rear worktop: 30 kg
ƒ
Max. load capacity of worktop left/right: 30 kg each
ƒ
Height of monitor shelf: 940 mm
ƒ
Height of worktop: 790 mm
ƒ
Weight: approx. 107 kg
ƒ
)
,
$
#
/
D
54 × M6×25 24 ×
J
2 × 8 ×
P
36 × 36 ×
Creative Desk Double
0
E F
M6×40 2 ×
K L
3 × M4×12
Q R
2 ×
EN
2 ×
12 ×
2 ×
