- Page 1 User manual Gebruikershandleiding Manuel de l’utilisateur Návod k obsluze Návod na používanie Bedienungsanleitung Manuale dell'utente Manual de utilizador Käyttöopas Manual del usuario Brukerhåndbok Felhasználói kézikönyv Brugervejledning Brukerhåndbok Manual de utilizare www.tcl.com...
-
Page 2: Table Of Contents
Table of Contents Important Information Using the Monitor ………………… 3 ……………………… 16 Important Safety Instructions …………… 3 Connections ………………………………… 16 Using Electrical Power ……………………… 5 Connect to the monitor …………………… 16 Advice on Eye Health Monitor terminal description ……………………… 5 ……………... -
Page 3: Important Information
When the equipment is not used for a long period of time, disconnect the power supply to prevent damage from electric shock and TCL King Electrical Appliances (Huizhou) Co., Ltd. bears no abnormal power supply voltage during thunderstorms. responsibility for accidents or damages caused by unauthorized •... - Page 4 Important Safety Instructions ESD regulation CAUTION RISK OF ELECTRIC SHOCK DO This apparatus meets ESD performance criteria. In case the apparatus does NOT OPEN not recover due to electrostatic discharge, user intervention is required. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
-
Page 5: Using Electrical Power
Using Electrical Power This product should be used with the type of power supply speci ed on Place the Monitor at a distance of 20~28 inches (approximately • 50~70 cm) from your eyes. the label. If you are uncertain about the type of power supply available, check with your dealer or local power supply company. -
Page 6: Product Disposal And Recycle
Product Disposal and Recycle Information on Disposal of Old Product [Other Countries outside the European Union] These symbols are only valid in the European Union. If you Your product is designed and manufactured with high-quality materials wish to dispose of these items, please do so in accordance with and components, which can be recycled and reused. -
Page 7: Preparing And Assembling
- For the damage or injury by unauthorized components, the product warranty will not cover. - If using generic cables not certi ed by TCL, the screen may not display or there may be image noises. - Illustrations in this user manual represent typical procedures, there may be di erences among varying monitors Do not use excessive force to tighten screws, otherwise damage may cause to the monitor. -
Page 8: What's In The Box
What's in the Box Please check the following items when you unpack the box, and keep the package in case you need to transport or ship the monitor in future. 比例 比例 $ $ Accessories may vary by country and model. -
Page 9: Installing The Monitor
Installing the Monitor Setup stand & base... - Page 10 Setup stand & base...
-
Page 11: Connect To Power And Turn On Monitor
Connect to the power and turn on monitor... -
Page 12: Adjusting Viewing Angle
Adjusting viewing angle -5~15˚ ±90˚ 125mm ±20˚ Attention:When using the Pivot as shown in Figure ③ ,it is necessary to rotate the Tilt angle of 15°to avoid contact with the chassis. - Page 13 Adjusting viewing angle 27G64&27G74...
-
Page 14: Wall Mounting
Wall mounting Warning Never place a monitor set in an unstable location. A monitor set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as: - Check if the wall can support the weight of the monitor and wall mount assembly. - Follow the mounting instructions provided with the wall mount. - Page 15 Wall mounting VESA Screws Torque M4x10mm--4pcs < 1.2N.m 27'' 100mm 100mm...
-
Page 16: Using The Monitor
Using the Monitor Connections To connect the monitor to the computer/ laptop 1. Before connecting to the monitor, ensure that your computer/laptop on the state of o 2. Connect the monitor cable to the compatible port of your computer/ laptop. 3. - Page 17 Connections Monitor Terminal Description 25G64 / 27G64 Note: Button and connector locations may vary according to monitor model. Monitor power input port HDMI signal access port DisplayPort (DP) signal access port Audio output port...
-
Page 18: Monitor Terminal Description
Connections Monitor Terminal Description 27G74 Note: Button and connector locations may vary according to monitor model. Monitor power input port A port that can transmit data from USB-B to your computer/laptop Universal Serial Bus(USB) port HDMI signal access port DisplayPort (DP) signal access port... -
Page 19: Joystick Button
Joystick Button Function description Here are the navigation direction buttons and the Power button on the bottom of the monitor that you may use frequently. Instructions Press the joystick button in the middle. Turn On Turn O Press it twice quickly or hold it for 3 seconds. Light o when turning o the monitor Indicator Light Light turns orange when monitor on standby mode... - Page 20 • When the monitor is on (with signal): Open navigation menu by pressing button once. • When menu is open,select the item to the left to go Left key back or exit. (Toggle joystick button to • In navigation menu,short/long press to the left to enter the left) OSD menu.
-
Page 21: Osd Function Menu
OSD function menu Game mode/ Display 25G64 / 27G64 This section describes how to optimise the screen display better for playing games. This section allows you to adjust basic settings or more options of picture. Level 1 Menu Level 2 Menu Level 3 Menu FreeSync On/Off... - Page 22 OSD function menu Color 25G64 / 27G64 This section allows you to adjust basic settings or more options of picture. Level 1 Menu Level 2 Menu Level 3 Menu Standard Mode Office Mode FPS Mode RPG Mode Scene Mode RCG Mode Movie Mode Eye Care Mode E-book Mode...
-
Page 23: Input Setting
OSD function menu Input / Setting 25G64 / 27G64 This section allows you to select input sources/ This section allows you to select setting mode.. Level 1 Menu Level 2 Menu Level 3 Menu HDMI1 None HDMI2 None Input Source None On/O Auto Input... - Page 24 OSD function menu Setting 25G64 / 27G64 This section allows you to select setting mode. Level 1 Menu Level 2 Menu Level 3 Menu 0 ～ 100 Volume On/O DDC/CI Horizontal OSD Position Vertical Rotation 0/90/270 5s ～ 60s OSD Display Time On/O Settings Quick Boot...
- Page 25 OSD function menu Display 27G74 This section allows you to adjust basic settings or more options of picture. Level 1 Menu Level 2 Menu Level 3 Menu High, Medium, Standard Mini LED Control 0 ～ 100 Brightness 0 ～ 100...
- Page 26 OSD function menu Color 27G74 This section allows you to adjust basic settings or more options of picture. Level 1 Menu Level 2 Menu Level 3 Menu Standard Mode Office Mode MAC Mode Scene Mode Movie Mode Eye Care Mode...
- Page 27 OSD function menu Input / Setting 27G74 This section allows you to select input sources/ This section allows you to select setting mode.. Level 1 Menu Level 2 Menu Level 3 Menu HDMI1 None HDMI2 None None Input Source TYPE-C...
- Page 28 OSD function menu Setting 27G74 This section allows you to select setting mode. Level 1 Menu Level 2 Menu Level 3 Menu 0 ～ 100 Volume Auto,USB-B,TYPE-C Standby Power Supply Enable / Disable On/O DDC/CI Horizontal OSD Position Vertical Rotation...
-
Page 29: Specification
Specification General Specification Model 27G64 27G74 25G64 Product Type MiniLED O ce MNT MiniLED Gaming MNT MiniLED Gaming MNT Panel Active Size(Inch) Visual Range(mm) 596.736(H)×335.664(V) 596.736(H)×335.664(V) 543.744 (H) × 302.616 (V) Pixel Pitch(mm) 0.0777(H)×0.2331(V) 0.0528(H)×0.1554(V) 0.0944 (H) × 0.2802 (V) Color 1.07B (8 bit + FRC) - Page 30 Specification General Specification Model 27G64 27G74 25G64 HDMI, DP , Headphone HDMI, DP , TYPE-C,Headphone HDMI, DP ,Headphone Terminals¹ Power Consumption 0.5W/0.3W (Sleep/O ) Dimensions with Stand 615x524x228 556x501x226 WxHxD (mm) Vertical Adjustable Height 125mm -5°~15°(typical) Tilt Angle Pivot 90°...
-
Page 31: Standard Signal Mode
Specification Standard Signal Mode 25G64 832x624 1024x768 1280×720 640×480 720×400 720×576 800×600 （75Hz) （60/75Hz) (50/60Hz) (60/75Hz) (70Hz) (50Hz) (60/75Hz) HDMI 1280×800 1280x960 1280x1024 1680x1050 1920x1080 (60Hz) (60Hz) (60/75Hz) (60Hz) (50/60/120/144/240Hz) 832x624 1024x768 1280×720 1280×800 640×480 720×400 800×600 （75Hz) （60/75Hz) (60Hz) (60Hz) (60/75Hz) (70Hz) - Page 32 Specification Standard Signal Mode 27G64 1024×768 1152×864 1280×720 1280×1024 640×480 720×400 800×600 （75Hz) (60/70/75Hz) (60Hz) (60/75Hz) (60/72/75Hz) (70Hz) (60/72/75Hz) HDMI 1440×900 1920×1080 2560×1440 3840×2160 (60Hz) (50/60/100/120Hz) (60/120/144Hz) (60Hz) 640×480 720×400 800×600 1024×768 1152×864 1280×720 1280×1024 (60/72/75Hz) (70Hz) (60/72/75Hz) (60/70/75Hz) (75Hz) (60Hz) (60/75Hz) 2560×1440...
- Page 33 Specification Standard Signal Mode 27G74 1024×768 1152×864 1280×720 1280×1024 640×480 720×400 800×600 （75Hz) (60/70/75Hz) (60Hz) (60/75Hz) (60/72/75Hz) (70Hz) (60/72/75Hz) HDMI 1440×900 1689×1050 1600×900 1600×1200 1920×1080 2560×1440 3840×2160 (60Hz) (60Hz) (60Hz) (60Hz) (60Hz) (60Hz) (60Hz) 640×480 720×400 800×600 1024×768 1152×864 1280×720 1280×1024...
-
Page 34: Other Information
Other Information Troubleshooting The colour or sound is abnormal: Please check the following list before requesting service. • Reset colour or sound to factory default settings in Setting. The power indicator is o : • Make sure the power button is pressed properly to switch the monitor Note: I f the above suggestions do not solve your technical issue, please refer to the warranty card for service information. -
Page 35: Legal Statement
Third party services may be changed, suspended, removed, terminated or INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY interrupted, or access may be disabled at any time, without notice, and TCL FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR makes no representation or warranty that any content or service will remain IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS A available for any period of time.
