MC25P
COLOR MONITOR
COLOR MONITOR
O P E R A T I O N
M A N U A L
This unit is with multi functions, so for better performance
please read the instructions carefully before your operation.
Advertisement
Table of Contents
Related Manuals for TCL MC25P
Summary of Contents for TCL MC25P
- Page 1 Product Standardization File No.: QB/44130033952-2005 4008-123456 This unit is with multi functions, so for better performance If you encounter any problem with your monitor, please call TCL nationwide customer service hotline 4008-123456 for assistance. please read the instructions carefully before your operation.
- Page 4 AV AV1,AV2) HDTV YPbPr (1)60Hz (2)75Hz (3)75Hz (4)100Hz NTSC (1)60Hz AV:PAL N358(NTSC3.58) N443(NTSC4.43) 1.0Vp-p 1.0Vp-p 0.7Vp-p HDTV YPbPr 1.0Vp-p 0.7Vp-p; HDTV 1920 1080P/60Hz 1920 1080i/60Hz 1920 1080i/50Hz 525P/625P(DVD ) 720P R G B 0.7Vp-p VGA 640 480 /60Hz SVGA 800 600 /60Hz XGA1024 768 /60Hz 160V-250V 50Hz...
- Page 5 7 1.5V VIDEO LOOP IN2&OUT2 VIDEO LOOP IN1&OUT1 YPbPr...
- Page 6 Y Pb Pr YPbPrH DTV REMOTE INPUT VIDEO OUT-2 VIDEO INT-2 VIDEO LOOP IN2&OUT2 POWER VGA IN VIDEO LOOP S-VIDEO 220V-50Hz IN2&OUT2 VIDEO OUT-1 VIDEO INT-1...
- Page 7 1. / 2.AV1/AV2/S-VHS AV2 S-VHS 3.HDTV/ VGA HDTV 4. HDTV 1080i 1080P 720P 16 9 16 9...
- Page 8 /N443/N358/PAL 100Hz /ENG. 100Hz/75Hz/P-75P/P-60P 100Hz 1 100 S-VHS S-VHS HDTV HDTV HDTV 1. HDTV...
-
Page 9: Table Of Contents
Contents Warnings and Precautions Features Specifications Remote Control External Schematic Connection Illustrations Basic Operations Turning on/off the Unit AV1/AV2/S-VHS Selection HDTV/VGA Selection Aspect Ratio Selection in HDTV Mode Picture Adjustments System Settings Geometrical Adjustments in HDTV and VGA mode Packing List Main Unit - one set Remote Control Handset - one set, including two AAA batteries and one remote control cable... -
Page 10: Warnings And Precautions
Warnings and Precautions Warnings High voltage inside! To Do not push objects of any The unit shall not be exposed reduce the risk of electric kindinto the unit as this may to dripping or splashing and shock, do not remove cover causefire or short circuit and no objects filled with liquids (or back). -
Page 11: Features
Features 2 AV (AV1, AV2) LOOP IN/OUT , 1 S-VIDEO Input 1YPbPr( HDTV) Input, 1 VGA (RGB) Input Multi Imaging Modes Imaging Modes of PAL Pictures: (1)60Hz Digital Progressive Scanning (2)75Hz Digital Progressive Scanning (3)75Hz Interlaced Scanning (4)100Hz Digital Double Frequency Imaging Mode of NTSC Pictures: (1)60Hz Progressive Scanning Specifications... -
Page 12: Remote Control
Remote Control Battery Installation Remove the battery compartment lid from the back of the MENU remote, insert the 2 x 1.5V AAA batteries, paying attention to the polarity, and then replace the cover. DOWN/AV button UP/VGA button Using the Remote Control RIGHT button LEFT button 1. -
Page 13: Connection Illustrations
Connection Illustrations Shooting Camera Y Pb Pr S-VIDEO REMOTE INPUT YPbPrH DTV VIDEO OUT-2 VIDEO INT-2 VIDEO LOOP IN2&OUT2 POWER VGA IN VIDEO LOOP S-VIDEO IN2&OUT2 220V-50Hz VIDEO OUT-1 VIDEO INT-1 Power Cord DVD Rewriter Computer Cassette Recorder... -
Page 14: Basic Operations
Basic Operations 1. Turning on/off the Unit Turning on: Press the "I" on the POWER button of the rear panel to turn on the unit, then the indicator lights. After a few seconds, the picture appears on the screen. Turning off: press the "O" on the POWER button of the rear panel to turn the unit off. 2.AV1/AV2/S-VHS Selection Press the DOWN/AV button on the remote repeatedly to toggle between AV1,AV2 and S-VHS. -
Page 15: System Settings
6.System Settings Press the MENU button to enter the SYSTEM menu. Press the UP/VGA button or DOWN/AV button to make the selection and press the LEFT or RIGHT button to make the adjustments. Item Explanation C.TEMP NORMAL C. SYS . AUTO C.TEMP NORMAL/WARM/COLD...
